Page 1: User Manual
ZTE MF60 3G Global Mobile Hotspot User Manual ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Tel: (86) 755 26779999 URL: http://www.zte.com.cn E-mail: mobile@zte.com.cn Confidential and Proprietary Information of ZTE CORPORATION... - Page 2 ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice.
-
Page 3: Table Of Contents
Access the WebGUI Configuration Page................ 16 Login ..........................17 Quick Setup ........................19 Settings ..........................21 3G Settings ........................21 Wi-Fi Settings ......................24 Firewall ........................27 Advanced ........................30 Phonebook ........................33 Adding new contact ....................33 Confidential and Proprietary Information of ZTE CORPORATION... - Page 4 Using Battery ........................40 Limited Warranty ......................40 Limitation of Liability ..................... 41 FCC Compliance ......................41 Radio Frequency (RF) Energy ..................41 Troubleshooting ........................43 Technical Parameters ......................45 Glossary ..........................47 Confidential and Proprietary Information of ZTE CORPORATION...
-
Page 5: Getting Started
C h a p t e r Getting Started ZTE MF60 is a 3G mobile hotspot device, working in EDGE/WCDMA/HSPA network. The client devices can connect to the device via USB or Wi-Fi interface; the device supports data and SMS services, enabling you to communicate anytime and anywhere. -
Page 6: Indicators
Wi-Fi status and number of the connected users. New incoming message indication. Battery power indication. Hardware Installation Inserting SIM Card and Battery 1. Use the thumb catch at the bottom of the device to open the battery cover. 6 Confidential and Proprietary Information of ZTE CORPORATION... -
Page 7: Inserting Microsd Card
3. Insert the battery as shown with the contacts located against the gold springs. 4. Line the battery cover up correctly and press gently to close the case. Inserting microSD Card 1. Pull the microSD cover out of the card slot. Confidential and Proprietary Information of ZTE CORPORATION 7... -
Page 8: Switching On/Off Your Device
2. The plug only fits one way. Do not use excessive force to insert the plug. 3. Check the plug is the right way round and lined up correctly and insert it gently. 8 Confidential and Proprietary Information of ZTE CORPORATION... -
Page 9: Microsd Card
SIM card away from electrical and magnetic appliances. If you cannot get service, make sure that： • You are in an area which has network coverage. You are using the correct SIM card. • Confidential and Proprietary Information of ZTE CORPORATION 9... -
Page 10: Working Mode
If the system does not launch installation automatically, you can run the installation program in path of My Computer > Portable Hotspot > Setup.exe. The following installation interface will show how to start installation. And the first screen you see as following: Confidential and Proprietary Information of ZTE CORPORATION 10... - Page 11 Strongly recommend you to exit Windows programs, and click Next, Select the folder that you want to install the software, and you can select a different path by pressing Change, and then click Next. Confidential and Proprietary Information of ZTE CORPORATION 11...
- Page 12 ZTE MF60 User Manual Click Install. Click Finish to complete the installation. 12 Confidential and Proprietary Information of ZTE CORPORATION...
-
Page 13: Wi-Fi Mode
ZTE MF60 User Manual After the installation, select Start > Programs and there will be a ZTE USB Drivers for MF60 program group，which includes MF60 Web UI and Uninstall ZTE USB Drivers for MF60. There will be a shortcut icon on the desktop. -
Page 14: Mixed Mode
ZTE MF60 User Manual Mixed Mode Use the both connection methods to connect your PC or laptop. And the following picture is one application example: 14 Confidential and Proprietary Information of ZTE CORPORATION... -
Page 15: Operation And Function
Notes: You need to check your Wireless Network Connection. Set the client to obtain an IP address automatically in the Internet protocol (TCP/IP) properties, and the client will get an IP address like‖192.168.0.101‖. 3. Select the SSID of your device, and then click Connect. Confidential and Proprietary Information of ZTE CORPORATION 15... -
Page 16: Access The Internet
It is recommended that you use IE (6.0 or later), Firefox (1.0 or later), Opera (6.0 or later), Safari (3.0 or later), Chrome (6.0 or later) The login page appears as follows. 16 Confidential and Proprietary Information of ZTE CORPORATION... -
Page 17: Login
ZTE MF60 User Manual Login In the WebGUI Configuration page, select the desired language and input the password (the default Password is admin). Confidential and Proprietary Information of ZTE CORPORATION 17... - Page 18 If you check Save after type in password, the device will save it. Next time when you want to login the device with the same password, what you need to do is click Login. When you login, the following interface appears. 18 Confidential and Proprietary Information of ZTE CORPORATION...
-
Page 19: Quick Setup
: Wi-Fi status and number of the connected users. And the maximum number is 10. Quick Setup 1. In the main interface click Quick Setup. 2. Read the guide carefully, and then click Next. Confidential and Proprietary Information of ZTE CORPORATION 19... - Page 20 Service Set Identifier (SSID) is used to uniquely identify your WLAN. If you enable SSID Broadcast, the gateway will broadcast the SSID, and other devices can detect and connect to it. 5. Set Security Configuration in the following figure: 20 Confidential and Proprietary Information of ZTE CORPORATION...
-
Page 21: 3G Settings
Please disconnect the device from the network before change the settings. • 3G Settings Wireless Info Select Settings > 3G Settings > Wireless Info, the 3G wireless information is shown in the following figure: Confidential and Proprietary Information of ZTE CORPORATION 21... - Page 22 GSM Only: Device searches for GSM network only. • Click Apply to confirm your configuration. APN Setting Select Settings > 3G Settings > APN Setting, the APN parameters are shown in the following figure: 22 Confidential and Proprietary Information of ZTE CORPORATION...
- Page 23 Profile Name Type the APN string. Set DNS mode. Authentication Password Authentication Protocol (PAP) provides a simple method without encryption for the peer to establish its identity using a 2-way handshake. Challenge-Handshake Confidential and Proprietary Information of ZTE CORPORATION 23...
-
Page 24: Wi-Fi Settings
• Network Name(SSID): Service Set Identifier(SSID). Enter a string less than 32 characters as the name for your wireless local area network(WLAN). 24 Confidential and Proprietary Information of ZTE CORPORATION... - Page 25 The WLAN clients who have the same WEP key with wireless gateway can pass the authentication and access the wireless network. WPA-PSK WPA Pre-Shared Key, Enter the Pre-Shared key as a plain text (ASCII) Confidential and Proprietary Information of ZTE CORPORATION 25...
- Page 26 A WEP can be in HEX form either 10 or 26 hexadecimal digits (0~9,a~f and A~F) and in ASCII form either 5or 13 ASCII code. If the Authentication type is OPEN, the bottom part of the configuration page displays WPA parameters. 26 Confidential and Proprietary Information of ZTE CORPORATION...
-
Page 27: Firewall
You may setup firewall rules to protect your network from virus, worm and malicious activity on the Internet. Notes: You can set the maximum 10 filtering items for MAC/IP/Port Filtering and Port Forwarding. MAC/IP/Port Filtering Confidential and Proprietary Information of ZTE CORPORATION 27... - Page 28 Dest. Port Range: Set the destination port numbers that will be filtered • • Source Port Range: Set the source port numbers that will be filtered. Action: Set how to handle the packet if it matches with the rule. • 28 Confidential and Proprietary Information of ZTE CORPORATION...
- Page 29 You can setup virtual servers to provide services on the Internet. Select Settings > Firewall > Port Forwarding, the virtual server settings are shown in the following figure: If you select Enable, the Virtual Server Settings will appear: Confidential and Proprietary Information of ZTE CORPORATION 29...
-
Page 30: Advanced
Advanced Status Select Settings > Advanced > Status, the system information is shown in the following figure: Management Select Settings > Advanced > Management, the administrator settings information is shown in the 30 Confidential and Proprietary Information of ZTE CORPORATION... - Page 31 PIN code, and you do not need to input PIN code every time after power on. If you select Modify, the modification parameters are shown in the following figure: Confidential and Proprietary Information of ZTE CORPORATION 31...
- Page 32 IP Address: IP address for LAN interface. • • Subnet Mask: Subnet mask for the IP address. MAC Address: MAC address for the LAN interface. • • DHCP Server: Enable or disable DHCP Server function. 32 Confidential and Proprietary Information of ZTE CORPORATION...
-
Page 33: Phonebook
Enter the contact’s phone number Mobile number 3. Click Save to confirm your configuration. Operation in native Select Phonebook > Native to access the following figure: All contacts stored in your device will be displayed here. Confidential and Proprietary Information of ZTE CORPORATION 33... -
Page 34: Operation In Sim Card
Configure the validity period of outgoing messages Center Number Enter the short message center number, detailed please consult your service provider Save New Select the device or SIM card to save your messages Message 34 Confidential and Proprietary Information of ZTE CORPORATION... -
Page 35: Sending New Sms
All the received messages saved in your device will be displayed here. • Click View to view the selected message. Click Reply to reply to the selected message sender. • • Click Delete to delete the selected message. Confidential and Proprietary Information of ZTE CORPORATION 35... -
Page 36: Operation In Sim Card
Select SMS > SIM Card > Inbox/Outbox/Drafts to access the corresponding figure, detailed operation please refer to the chapter Operation in native. WAN Connection Click WAN Connection, you can configure how to connect to the Internet in the following figure: There are two connection modes: 36 Confidential and Proprietary Information of ZTE CORPORATION... -
Page 37: Usage Of Wps
10 minutes or you press the WPS button, the device will enter the sleep mode， and the LED screen will be turned off. In the sleep mode, the Wi-Fi function will Confidential and Proprietary Information of ZTE CORPORATION 37... - Page 38 Press Power or WPS button to wake up the device, and all LEDs will be turned Notes: With USB connection if no Wi-Fi user connects to the device within 10 minutes, only the Wi-Fi function will be disabled. Press WPS button to enable this function. 38 Confidential and Proprietary Information of ZTE CORPORATION...
-
Page 39: Warning And Notice
Handle the device carefully. Do not drop, bend or strike it. Otherwise the device will be damaged. • • No dismantling by non-professionals and only qualified technicians can undertake repair work. Confidential and Proprietary Information of ZTE CORPORATION 39... -
Page 40: Using Battery
Product. iv. Modifications or repairs not made by ZTE or a ZTE-certified individual. v. Power failures, surges, fire, flood, accidents, actions of third parties or other events outside ZTE’s reasonable control. vi. Usage of third-party products, or usage in conjunction with third-party products provided that such defects are due to the combined usage. -
Page 41: Limitation Of Liability
ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential damages resulting from or arising out of or in connection with using of this product, whether or not ZTE had been advised, knew or should have known of the possibility of such damages, including, but not limited to lost profits, interruption of business, cost of capital, cost of substitute facilities or product, or any downtime cost. - Page 42 FCC RF exposure guidelines. SAR information on this model device is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID: Q78-ZTEMF60. 42 Confidential and Proprietary Information of ZTE CORPORATION...
-
Page 43: Troubleshooting
2. For the webGUI configuration page password, the default password is Admin. 3. If you changed the password, and forgot the new password. You need to restore the device to the factory default settings. For more assistance, please: Confidential and Proprietary Information of ZTE CORPORATION 43... - Page 44 ZTE MF60 User Manual Sending E-mail to mobile@zte.com.cn • Visiting http://www.zte.com.cn • Calling Service Hotline: +86–755–26779999 • 44 Confidential and Proprietary Information of ZTE CORPORATION...
-
Page 45: Technical Parameters
Web Browser IE (6.0 or later), Firefox (1.0 or later), Opera (6.0 or later), Safari (3.0 or later), Chrome (6.0 or later) Working temperature 0℃ ~ +35℃ Storage temperature -20℃ ~ +50℃ Confidential and Proprietary Information of ZTE CORPORATION 45... - Page 46 ZTE MF60 User Manual Charging temperature 0℃ ~ +40℃ Humidity 5%~ 95% Notes: The device’s standby and working time are based on ideal working environment. 46 Confidential and Proprietary Information of ZTE CORPORATION...
-
Page 47: Glossary
PUK: PIN Unlocking Key • • UPNP: Universal Plug and Play SIM: (UMTS) Subscriber Identification Module • • WCDMA: Wideband CDMA (Code-Division Multiple Access) WEP: Wired Equivalent Privacy • Wi-Fi：Wireless Fidelity • Confidential and Proprietary Information of ZTE CORPORATION 47... - Page 48 ZTE MF60 User Manual WLAN: Wireless LAN • WPA-PSK: Wi-Fi Protected Access–PreShared Key • 48 Confidential and Proprietary Information of ZTE CORPORATION...
