[PA UNIT]
REF ORDER
NO. NO.
C6708 4030006880 S.CERAMIC
C6801 4030011600 S.CERAMIC
RL6701 6330001470 RELAY
J6301 6510021530 CONNECTOR
J6302 6510021530 CONNECTOR
J6401 6510007020 CONNECTOR
J6411 6510021390 CONNECTOR
J6412 6510021390 CONNECTOR
J6501 6510003390 CONNECTOR
J6701 6510022540 S.CONNECTOR 20FMN-BMTTR-A-TBT
J6702 6510007020 CONNECTOR
J6703 6510003400 CONNECTOR
F6701 5210000060 FUSE
F6702 5220000230 HOLDER
F6703 5220000230 HOLDER
W6401 9054500690 WIRE
W6402 9054500690 WIRE
W6601 9045201001 WIRE
W6701 7030008240 S.JUMPER
EP6001 0910054694 PCB
EP6601 6910000630 BEAD
EP6602 6510018330 TERMINAL
EP6603 6510018330 TERMINAL

[FILTER UNIT]

REF ORDER
NO. NO.
Q7301 1590000680 S.TRANSISTOR DTC114EUA T106
D7271 1750000190 S.DIODE
D7272 1750000190 S.DIODE
D7301 1750000550 S.DIODE
L7031 6200002040 S.COIL
L7035 6200002040 S.COIL
L7036 6140002240 COIL
L7037 6140001990 COIL
L7038 6140002000 COIL
L7061 6200002040 S.COIL
L7065 6200002040 S.COIL
L7066 6140002340 COIL
L7067 6140002230 COIL
L7068 6140002240 COIL
L7091 6200002040 S.COIL
L7095 6200002040 S.COIL
L7096 6140002260 COIL
L7097 6140002230 COIL
L7098 6140002230 COIL
L7121 6200002040 S.COIL
L7125 6200002040 S.COIL
L7126 6140002250 COIL
L7127 6140002340 COIL
L7128 6140002340 COIL
L7151 6200005050 S.COIL
L7155 6200005050 S.COIL
L7156 6140002280 COIL
L7157 6140002250 COIL
L7158 6140002250 COIL
L7181 6200005050 S.COIL
L7182 6140002300 COIL
L7183 6140002290 COIL
L7184 6140002290 COIL
L7185 6200005050 S.COIL
L7211 6200005010 S.COIL
DESCRIPTION
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
AJS1311
IMSA-9230B-1-04Z024-T
IMSA-9230B-1-04Z024-T
TMP-J01X-V6
IMSA-9230B-1-03Z024-T
IMSA-9230B-1-03Z024-T
B03B-EH-S
TMP-J01X-V6
B04B-EH-S
FGB 5A
S-N5054
S-N5054
76/98/020/X98/X98
76/98/020/X98/X98
74/98/040/X98/X98
ERJ12YJ0R00U
B 5724D
FSRH070140RN000B (FSOH070RN)
F4053A
F4053A
DESCRIPTION
1SS322 (TE85R)
1SS322 (TE85R)
1SS355 TE-17
NL 252018T-101J
NL 252018T-101J
LR-236 (T68-2)
LR-226 (T68-2)
LR-227 (T68-2)
NL 252018T-101J
NL 252018T-101J
LR-263 (T68-2)
LR-235 (T68-2)
LR-236 (T68-2)
NL 252018T-101J
NL 252018T-101J
LR-238 (T68-2)
LR-235 (T68-2)
LR-235 (T68-2)
NL 252018T-101J
NL 252018T-101J
LR-237 (T68-2)
LR-263 (T68-2)
LR-263 (T68-2)
NL 252018T-330J
NL 252018T-330J
LR-241 (T68-6)
LR-237 (T68-2)
LR-237 (T68-2)
NL 252018T-330J
LR-243 (T68-10)
LR-242 (T68-10)
LR-242 (T68-10)
NL 252018T-330J
NL 252018T-100J
[FILTER UNIT]
REF ORDER
NO. NO.
L7215 6200005010 S.COIL
L7216 6140002290 COIL
L7217 6140002290 COIL
L7218 6140002290 COIL
L7241 6200005010 S.COIL
L7244 6200005010 S.COIL
L7245 6140002330 COIL
L7246 6140002330 COIL
L7248 6140002330 COIL
L7271 6200002040 S.COIL
L7272 6140003490 COIL
L7273 6200002040 S.COIL
L7321 6140001460 COIL
L7331 6200002040 S.COIL
L7332 6200002040 S.COIL
R7271 7030003560 S.RESISTOR
R7272 7030003490 S.RESISTOR
R7273 7030003520 S.RESISTOR
R7274 7030008190 S.RESISTOR
R7275 7030003560 S.RESISTOR
R7276 7030003490 S.RESISTOR
R7277 7030003520 S.RESISTOR
R7301 7030003200 S.RESISTOR
R7314 7540000230 ABSORBER
R7315 7030010650 S.RESISTOR
C7031 4510005480 ELECTROLYTIC 50 MV 1 HC
C7032 4030011600 S.CERAMIC
C7033 4320000651 DIP MICA
C7034 4010006410 CERAMIC
C7035 4010006410 CERAMIC
C7036 4320000981 DIP MICA
C7037 4010005360 CERAMIC
C7038 4010005880 CERAMIC
C7039 4320000951 DIP MICA
C7041 4030011120 S.CERAMIC
C7042 4010005930 CERAMIC
C7043 4010005930 CERAMIC
C7044 4010005930 CERAMIC
C7045 4010005370 CERAMIC
C7046 4030011600 S.CERAMIC
C7049 4010005850 CERAMIC
C7061 4510005480 ELECTROLYTIC 50 MV 1 HC
C7062 4030011600 S.CERAMIC
C7063 4030011730 S.CERAMIC
C7064 4010006410 CERAMIC
C7065 4010006410 CERAMIC
C7066 4010005370 CERAMIC
C7067 4010005880 CERAMIC
C7068 4010005880 CERAMIC
C7069 4010005880 CERAMIC
C7070 4030011730 S.CERAMIC
C7071 4010006410 CERAMIC
C7072 4010006410 CERAMIC
C7073 4010006410 CERAMIC
C7074 4010005880 CERAMIC
C7075 4010005370 CERAMIC
C7076 4010005370 CERAMIC
C7077 4010005370 CERAMIC
C7078 4010005930 CERAMIC
C7079 4010006410 CERAMIC
C7080 4030012480 S.CERAMIC
C7081 4030012480 S.CERAMIC
C7082 4010005930 CERAMIC
C7083 4010005930 CERAMIC
C7084 4030011550 S.CERAMIC
C7085 4030011600 S.CERAMIC
C7086 4030011120 S.CERAMIC
C7087 4030012480 S.CERAMIC
C7091 4510005480 ELECTROLYTIC 50 MV 1 HC
C7092 4030006880 S.CERAMIC
C7094 4010005370 CERAMIC
C7095 4010005930 CERAMIC
C7096 4010005930 CERAMIC
C7098 4010005370 CERAMIC
C7099 4010006410 CERAMIC
C7100 4030011730 S.CERAMIC
C7101 4010005360 CERAMIC
C7102 4030006880 S.CERAMIC
5 - 13
DESCRIPTION
NL 252018T-100J
LR-242 (T68-10)
LR-242 (T68-10)
LR-242 (T68-10)
NL 252018T-100J
NL 252018T-100J
LR-262 (T68-6)
LR-262 (T68-6)
LR-262 (T68-6)
NL 252018T-101J
LR-391
NL 252018T-101J
LR-170
NL 252018T-101J
NL 252018T-101J
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ12YJ330U (33 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 100 V (10 Ω)
SA05 401N
ERJ12YJ823U (82 kΩ)
C1608 JB 1E 104K-T
KD20C 102J5A
HM13SJ SL 471J 500V
HM13SJ SL 471J 500V
KD20C 222J5A
HM11SJ SL 301J 500V
HM95SJ SL 271J 500V
KD20C 272J5A
GRM31M2C2H100JV01L (GRM42-6 CH)
HM11SJ SL 391J 500V
HM11SJ SL 391J 500V
HM11SJ SL 391J 500V
HM11SJ SL 331J 500V
C1608 JB 1E 104K-T
HM95SJ SL 181J 500V
C1608 JB 1E 104K-T
GRM31M2C2H101JV01L (GRM42-6 CH)
HM13SJ SL 471J 500V
HM13SJ SL 471J 500V
HM11SJ SL 331J 500V
HM95SJ SL 271J 500V
HM95SJ SL 271J 500V
HM95SJ SL 271J 500V
GRM31M2C2H101JV01L (GRM42-6 CH)
HM13SJ SL 471J 500V
HM13SJ SL 471J 500V
HM13SJ SL 471J 500V
HM95SJ SL 271J 500V
HM11SJ SL 331J 500V
HM11SJ SL 331J 500V
HM11SJ SL 331J 500V
HM11SJ SL 391J 500V
HM13SJ SL 471J 500V
GRM31M2C2H121JV01L (GRM42-6 CH)
GRM31M2C2H121JV01L (GRM42-6 CH)
HM11SJ SL 391J 500V
HM11SJ SL 391J 500V
GRM31M2C2H680JV01L (GRM42-6 CH)
C1608 JB 1E 104K-T
GRM31M2C2H100JV01L (GRM42-6 CH)
GRM31M2C2H121JV01L (GRM42-6 CH)
C1608 JB 1H 472K-T
HM11SJ SL 331J 500V
HM11SJ SL 391J 500V
HM11SJ SL 391J 500V
HM11SJ SL 331J 500V
HM13SJ SL 471J 500V
GRM31M2C2H101JV01L (GRM42-6 CH)
HM11SJ SL 301J 500V
C1608 JB 1H 472K-T
S.=Surface mount
