HM-135
[MAIN UNIT]
REF ORDER
NO. NO.
R1 7010006890 RESISTOR
R2 7010006910 RESISTOR
R3 7010006880 RESISTOR
R4 7010006900 RESISTOR
C1 4010008030 CERAMIC
MC1 7700002120 MICROPHONE KUC2123-030245
S1 2260002340 SWITCH
S2 2260002340 SWITCH
S3 2260002340 SWITCH
W1 9018490010 WIRE
W2 9018490010 WIRE
EP1 0910051480 PCB
EP2 9018230010 TUBE

[SW BOARD]

REF ORDER
NO. NO.
S1 2260002330 SWITCH
EP1 0910051490 PCB
DESCRIPTION
R20J 12 kΩ
R20J 33 kΩ
R20J 6.8 kΩ
R20J 15 kΩ
DD104 B 471K 50V
SKHHAM024A
SKHHAM024A
SKHHAM024A
71/98/010/X98/X98 <KN>
71/98/010/X98/X98 <KN>
B 5324
IRRAX 0.7(d) L=5mm
DESCRIPTION
SKHHLP014A
B 5325
SP-24
[CHASSIS UNIT]
REF ORDER
NO. NO.
SP1 2510001170 SPEAKER
W1 8900011090 CABLE
EP1 8930006760 M.OTHER
5 - 20
DESCRIPTION
077P0401 <KS>
OPC-1104
SR-2P-4
S.=Surface mount
