Chauvet Legend 300E Spot Quick Reference Manual
Hide thumbs
Also See for Legend 300E Spot:
- Specifications (1 page) ,
- User manual (34 pages) ,
- User manual (32 pages)
Advertisement
Quick Links
Download this manual
See also:
User Manual
Legend 300E Spot QRG
Contact Us
World Headquarters
General Information
Technical Support
World Wide Web
Legend 300E Spot QRG – Rev. 01q
© Copyright 2010 CHAUVET®
All rights reserved
Printed in the P. R. C.
CHAUVET®
th
5200 NW 108
Avenue
Sunrise, FL 33351
Voice: (954) 929-1115
Fax: (954) 929-5560
Toll free: (800) 762-1084
Voice: (954) 929-1115 (Press 4)
Fax: (954) 756-8015
www.chauvetlighting.com
Page 16
Quick Reference Guide
Advertisement
Related Manuals for Chauvet Legend 300E Spot
Summary of Contents for Chauvet Legend 300E Spot
- Page 1 Toll free: (800) 762-1084 Voice: (954) 929-1115 (Press 4) Technical Support Fax: (954) 756-8015 World Wide Web www.chauvetlighting.com Legend 300E Spot QRG – Rev. 01q © Copyright 2010 CHAUVET® All rights reserved Printed in the P. R. C. Page 16...
-
Page 2: About This
Legend 300E Spot QRG Legend 300E Spot QRG Continued from previous page About this The Legend 300E Spot Quick Reference Guide only contains the fixture’s connection and mounting information as well as the menu options and the Guide MODE 2... - Page 3 Legend 300E Spot QRG Legend 300E Spot QRG Continued from previous page Features 21 or 29-channel DMX control, compact, fully electronic, 300-watt moving yoke spot MODE 2 Channel Function Value Percent/Setting Pan: 540⁰ (Cont.) 000 007 ...
- Page 4 Legend 300E Spot QRG Legend 300E Spot QRG Continued from previous page AC Power This product has an auto-ranging power supply that can work with an input voltage range of 100~240 VAC, 50/60 Hz. MODE 2 Channel Function Value Percent/Setting (Cont.)
- Page 5 Channel Function Value Percent/Setting Gobo The Legend 300E Spot comes with two gobo wheels. Gobo wheel #1 has 000 255 0~540º seven rotating gobos, while gobo wheel #2 has eight fixed gobos, as Wheels indicated below. The diagram shows the first and last gobo on each wheel, 000 ...
- Page 6 Legend 300E Spot QRG Legend 300E Spot QRG Continued from previous page Replacing a 1) Turn the fixture off and disconnect it from the power outlet. Gobo 2) Open the head cover by loosening the four fastening screws at the sides...
-
Page 7: Increasing The Lamp's Life
Legend 300E Spot QRG Legend 300E Spot QRG Continued from previous page Replacing 1) Turn the fixture off and disconnect it from the power outlet. the Lamp 2) Wait at least 15 minutes for the lamp to cool down. MODE 1... -
Page 8: Menu Options
Legend 300E Spot QRG Legend 300E Spot QRG Menu Options -128~127 R-Gobo 2 -128~127 Offset Tilt -128~127 Gobo 2 -128~127 Menu Main Level Level Level Level Shutter 0~255 Prism 0~255 DMX Address 001~512 Dimmer 0~255 R-Prism -128~127 Mode 1 (21-channel)
