#T20 Torx screw
Stepper
motor
#T20 Torx
screw
Belt to platen roller
Pulley
Ball bearing
Plastic bearing
Spacer
EasyCoder PX4i and PX6i Service Manual
EasyCoder PX6i
In the illustration below, the upper parts of the print unit and the label
stop sensor have been removed to improve visibility.
Platen roller
Plastic bearing
Belt to ribbon
rewind unit
Ball bearing
#T20 Torx screw
Chapter 8 — Print Unit
Bracket
Bracket
69
