Chapter 8 — Print Unit
Stepper motor
#T20 Torx
screw
Belt to platen roller
Ball bearing
68
EasyCoder PX4i
In the illustration below, the upper parts of the print unit and the label
stop sensor have been removed to improve visibility.
#T20 Torx screw
Pulley
Plastic bearing
Spacer
Platen roller
Belt to ribbon
rewind unit
Spacer
Plastic bearing
Ball bearing
Bracket
#T20 Torx screw
EasyCoder PX4i and PX6i Service Manual
