Chapter 1 — Models and Options
1.3 EasyCoder PX6i Specifications
Printing
Print Technique
Printhead Resolution
Print Speed (variable)
Print Width (max)
Print Length (max)
Media Width (min/max)
Media Roll Diameter (max)
Media Roll Core Diameter
Ribbon Width (min/max)
Ribbon Roll Diameter (outer), max.
Ribbon Roll Core Diameter (inner)
Print Directions
Modes of Operation
Tear-Off (Straight-through)
Cut-Off
Peel-Off (Self-strip)
Fingerprint Firmware
Operating System
Smooth Fonts
Resident Scaleable Fonts
Resident Bar Codes
Startup Program (std)
IPL Firmware
Operating System
Smooth Fonts
Resident Bar Codes
Physical Measures
Dimensions (W × L × H)
Weight (excluding media)
Ambient Operating Temperature
Storage Temperature
Humidity
Electronics
Microprocessor
On-board Flash SIMMs
On-board SDRAM SIMM
10
Direct Thermal and Thermal Transfer
8 dots/mm (203.2 dpi) or
11.81 dots/mm (300 dpi)
100 to 225 mm/sec. (≈ 4 to 8.85 in./sec.)
167.4 mm (6.59 in.)
32767 dots
= 409.5 cm (161.25 in.) at 203.2 dpi
= 277.5 cm (109.23 in.) at 300 dpi
76 to 170 mm (3 to 6.69 in.)
213 mm (8.38 in.)
205 mm (8.07 in.)
38 to 40 mm (1.5 in.) or
76 mm (3 in.) with adapter fi tted
76.2 to 170 mm (3 to 6.69 in.)
80 mm (3.15 in.)
25 mm (1.00 in.)
4
Yes
Option
Option
Intermec Fingerprint v8.30
TrueDoc and TrueType fonts
15
59
Intermec Shell v8.2
IPL v2.30
13 scaleable + 21 simulated bitmap
44
335 × 482 × 238 mm
(13.2 × 19.0 × 9.4 in)
14.8 kg (32.6 pounds)
+5°C to +40°C (+41°F to +104°F)
-20°C to +70°C (-4°F to +152°F)
10 to 90% non-condensing
32 bit RISC
2 sockets for 4MB or 8MB each
1 socket for 16MB
Not supported by IPL
1
1
Tear-off & Cut-off
Peel-off & batch takeup
≈ 450 m (1476 ft) length
With cutter
With rewinder
Incl. Direct Protocol
Unicode fonts
Std. 1 x 4MB
(Std. 16MB)
EasyCoder PX4i and PX6i Service Manual
