Chapter 10 — Label Taken Sensor

10.3 Activating the LTS

10.4 Adjustment

116
In Fingerprint, the label taken sensor is enabled using the instruction
LTS& ON.
In IPL, the self-strip mode must be enabled. This can also be done by
executing the following commands:
<STX>R<ETX>
<STX><SI>t1<ETX>
The sensitivity of the Label Taken Sensor (LTS) may need to be adjusted
according to the ambient light conditions and the refl ective characteristics
of the back side of the media.
Fingerprint
The sensitivity can be adjusted in the Setup Mode (see Appendix A), or by
using setup fi les or setup strings (see Intermec Fingerprint v8.xx, Program-
mer's Reference Manual). In the Setup Mode, the LTS setup options are
only displayed if an optional label taken sensor is installed in the printer.
• LTS Adjust:
Press <Enter>. A label is fed out. Remove the label and press <Enter>
again. A menu shows the sensitivity automatically selected by the fi rm-
ware and the range in which the LTS will work. Press <Enter> again and
you will proceed to the LTS Test menu.
• LTS Test:
Press <Enter>. A label is fed out. Remove the label and a new label
should be fed out automatically. Repeat until you are sure the LTS
works properly. Then press <Enter> to stop and exit.
• LTS Value:
Press <Enter>. You can enter a new value in the range indicated in the
LTS Adjust menu (see above). Min/max values are in the range 0-10.
IPL
The sensitivity can be adjusted in the Setup Mode (see Appendix A).
• In the Setup Mode, select the Confi guration option.
• Select LTS Calibration and press the
• Press <Enter>
• A number of labels are fed out. Remove the labels and press <Enter>.
• The sensor has now been automatically adjusted and the resulting
sensitivity is displayed as a numeric value in the range of 8 to 14.
(Enter print/confi guration mode)
(Enable self-strip)
key.
