Owner's Manual
Product May Vary Slightly From Pictured.
CAUTION:
Weight on this product should not exceed 250 lbs.
This Product is Distributed Exclusively by
2040 N. Alliance, Springfield, MO 65803
Customer Service
1 (800) 375-7520
www.staminaproducts.com
Magnetic Elliptical
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following number :
Model#: A550-090
STAMINA PRODUCTS
MADE IN CHINA
©
2012 Stamina Products, Inc.
2012, 08
Advertisement
Table of Contents
Related Manuals for Stamina AVARI Magnetic Elliptical
Summary of Contents for Stamina AVARI Magnetic Elliptical
- Page 1 CAUTION: Weight on this product should not exceed 250 lbs. This Product is Distributed Exclusively by STAMINA PRODUCTS MADE IN CHINA 2040 N. Alliance, Springfield, MO 65803 Customer Service © 2012 Stamina Products, Inc. 1 (800) 375-7520 2012, 08 www.staminaproducts.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Instructions ........2 Maintenance ..........15 Before You Begin ........4 Conditioning Guidelines ......16 Equipment Warning, Caution & Notice Labels ... 5 Warm-Up and Cool-Down ......17 Hardware Identification Chart ....6 Product Parts Drawing ......18 Assembly Instructions ........ -
Page 3: Customer Service
Monday - Thursday, 7:30 A.M. - 5:00 P.M., Central Time. Friday, 8:00 A.M. - 3:00 P.M., Central Time. ONLINE TELEPHONE MAIL CUSTOMER SERVICE CUSTOMER SERVICE CUSTOMER SERVICE STAMINA PRODUCTS, INC. customerservice@staminaproducts.com Tel: 1 (800) 375-7520 Fax: (417) 889-8064 ATTN: Customer Service www.staminaproducts.com P.O. Box 1071 Springfield, MO. 65801-1071... -
Page 4: Before You Begin
BEFORE YOU BEGIN Thank you for choosing the AVARI® Magnetic Although Stamina constructs its products with Elliptical. We take great pride in producing this the finest materials and uses the highest standards quality product and hope it will provide many hours... -
Page 5: Equipment Warning, Caution & Notice Labels
EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the AVARI® Magnetic Elliptical. Please take a moment to familiarize yourself with all of the warning, caution, and notice labels. Label is larger than actual size WARNING LABEL(78) -
Page 6: Hardware Identification Chart
HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws. -
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed. - Page 8 ASSEMBLY INSTRUCTIONS STEP 3 Refer to the inset drawing and the illustration below to connect the TENSION KNOB(8) to the TENSION CABLE(17) and assemble the UPRIGHT(2): 1. Set the TENSION KNOB(8) at position “8”, so the CABLE END extends out of the METAL FITTING as far as possible.
- Page 9 ASSEMBLY INSTRUCTIONS STEP 4 Place a SPACER(61) on each side of the SHAFT on the UPRIGHT(2). Slide the PIVOTING ARMS(71) onto the SHAFT on the UPRIGHT(2) on both sides and secure with SECURING CAPS(49), WASHERS (ø10xø19x2mm thick)(46), and NYLOCK NUTS(M10x1.5)(47). STEP 5 Slide the lower end of the PIVOTING ARM(71) into the bracket on the PEDAL ARM(9), and secure with the SHOULDER BOLT(ø15.9x77mm, M10x1.5 threaded)(13), WASHER(M10xø21x1.5mm thick)(60),...
- Page 10 ASSEMBLY INSTRUCTIONS STEP 6 There is a “L” decal on the LEFT HANDLEBAR(3), and a “R” decal on the RIGHT HANDLEBAR(5). Insert the LEFT HANDLEBAR(3) into the PIVOTING ARM(71) on the left side and secure with BUTTON HEAD BOLTS(M6x1x40mm)(62) and NYLOCK NUTS(M6x1)(33). Repeat on the right side. STEP 7 There is a “L”...
- Page 11 ASSEMBLY INSTRUCTIONS STEP 8 To assemble the STATIONARY HANDLEBAR(10), run the PULSE SENSOR WIRES(64) through the hole on the UPRIGHT(2) and through the opening on the top. Attach the STATIONARY HANDLEBAR(10) to the UPRIGHT(2) with BUTTON HEAD BOLTS(M8x1.25x15mm)(67) and WASHERS(M8)(68). STEP 9 Install two AA batteries into the METER(15), the batteries are not included.
-
Page 12: Set Up Instructions
SET UP INSTRUCTIONS Place the AVARI® Magnetic Elliptical in the area where it will be used. It is recommended that the AVARI® Magnetic Elliptical be placed on an equipment mat. The maximum operation dimensions of the AVARI® Magnetic Elliptical are approximately 46.9 inches long x 22 inches wide x 59.1 inches tall. (These dimensions may vary up to one inch.) Make sure that adequate space is available for access to move around and emergency dismount from the AVARI®... -
Page 13: Operational Instructions
OPERATIONAL INSTRUCTIONS LOAD ADJUSTMENT To increase the load, turn the TENSION KNOB(8) clockwise. To decrease the load, turn the TENSION KNOB(8) counterclockwise. There are eight levels for the load adjustment. NOTE: The load will increase as you pedal faster. EXERCISE WORKOUT To start using the AVARI®... - Page 14 OPERATIONAL INSTRUCTIONS USING THE FITNESS METER POWER ON : Pedal movement or push the MODE button. POWER OFF : Automatic shut off after four minutes of inactivity. MODE BUTTON: Press to select display functions, include SCAN, TIME, SPEED, DISTANCE, CALORIES, ODOMETER, RPM, and PULSE. Press and hold for three seconds to reset all functions to zero, QUICK START...
-
Page 15: Storage
2. Verify that all nuts and bolts are present and properly tightened. Replace missing nuts and bolts. Tighten loose nuts and bolts. 3. Verify that the WARNING LABEL(78) is in place and easy to read. Call Stamina Products immediately at 1-800-375-7520 for a replacement WARNING LABEL(78) if it is missing or damaged. -
Page 16: Conditioning Guidelines
CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs. -
Page 17: Warm-Up And Cool-Down
WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place. -
Page 19: Parts List
PARTS LIST PART# PART NAME Main Frame Upright Left Handlebar Front Stabilizer Right Handlebar Pulley Magnetic Unit Tension Knob Pedal Arm Stationary Handlebar Left Cover Right Cover Shoulder Bolt (ø15.9 x 77mm, M10 x 1.5 threaded) Screw, Round Head (M5 x 0.8 x 50mm) Meter Handlebar Foam Tube Tension Cable... - Page 20 PARTS LIST PART# PART NAME Securing Cap Nylock Nut (M8 x 1.25) Tension Spring Endcap (ø50mm) Screw, Round Head (M4 x 30mm) Bolt, Button Head (M8 x 1.25 x 20mm) Bolt, Button Head (M8 x 1.25 x 25mm) Washer (ø16 x ø21.8 x 1mm) Acorn Nut (M8 x 1.25) Extension Wire Bearing (6202z)
-
Page 21: Warranty
To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. P.O. Box 1071, Springfield Missouri, USA, 65801-1071, or email us at customerservice@staminaproducts.com, or call us at 1-800-375-7520. -
Page 22: Notes
NOTES... -
Page 23: Fax/Mail Ordering Form
ATTN: Customer Service www.staminaproducts.com P.O. Box 1071 Springfield, MO. 65801-1071 Would you like to recieve email information or special offers from Stamina Products? Register at contact.staminaproducts.com TO REGISTER YOUR PRODUCT TO REGISTER YOUR PRODUCT To enact your warranty, please register your product by going to register.staminaproducts.com. Please have your product model number (printed on the cover of this owner’s manual) and the serial number (printed on the black and white sticker on your...
