Henny Penny OEA-342 Specification Sheet

PROJECT
Large capacity open fryers
With auto lift
Auto lift open fryer, model OEA-342.
Standard Features
• Stainless steel construction for
easy-cleaning and long life.
• Heavy-duty stainless steel
rectangular fry pots with 7-year
warranty.
• Two large fry wells offer greater
surface area and promotes more
even cooking.
• Specially designed "beach"
accommodates oil displacement
when lowering basket.
• Computron ®
8000 control with 10
programmable cook cycles, melt
mode, load compensation,
proportional control, idle mode,
optional filter prompt and
customizable filter tracking, clean-
out mode.
APPROVED APPROVED AS NOTED
AUTHORIZED SIGNATURE
© 2006 Henny Penny Corporation, Eaton, OH 45320 USA Revised 11/09/07
QUANTITY
General Information
The 340 series large capacity
open fryers from Henny Penny are
designed to offer maximum frying
surface area within a reasonable
footprint. These high volume open
fryers feature a larger, shallower fry
well that produces more consistent
frying results with items that float
when cooking.
The quiet, dependable auto lift
mechanism is designed into the
large-capacity 340 series open fryer
without adding one square inch to
the footprint. This feature promotes
perfect results without constant
monitoring and can significantly
increase productivity in lightly staffed
operations.
Henny Penny's unique high-
efficiency heat-exchange design
produces extremely fast temperature
recovery—typically in seconds—
• Fryer can be programmed to
operate half baskets independently
or together at the touch of a button.
• 16-character digital display with
multiple language settings.
• Fry pot protection system.
• Built-in filtration with over-the-top
return to wash away remnants.
• Rugged direct-drive lift mechanism
with quiet, low-voltage motor.
• Auto lift motor and drive built into
existing cabinet—footprint is NOT
increased.
• Easy basket set and release.
• Specially designed cold zone
prevents scorching.
• Four heavy-duty casters, two
locking.
RESUBMIT
DATE
ITEM NO
OEA-342
2-well electric
MODEL
OGA-342
2-well gas
without requiring excess oil to retain
heat. Fast recovery speeds up
production, saves energy, and
preserves frying oil quality by reducing
temperature fluctuations.
Built-in filtration system filters hot
frying oil in under 4 minutes, with no
separate pumps or pans required. Hot
filtered oil returns directly to each fry
well. Quick, easy and frequent filtering
extends shortening life and can result
in significant savings in time and
direct shortening costs.
The OEA/OGA-342 auto lift open
fryer features two fry wells with two
lifters each for half or full-basket
loads. Henny Penny's heavy-duty
stainless steel rectangular fry pot
promotes fast, even cooking and
comes with a 7-year warranty—the
best in the business.
Accessories shipped with unit
• Fry baskets—please select one
(2) full baskets
(1) full and (2) half baskets
(4) half baskets
• Basket support
• Lift tool for basket support
• Lift tool for electric elements
• Max shortening filtration system
and (2) PHT filter envelopes. (Units
available without filtration.)
Accessories and options available
separately
(3) Third-size fry baskets per well
Direct Connect shortening disposal
(filtration equipped units, only)
Shortening shuttle
Filter rinse hose
Henny Penny Corporation
PO Box 60 Eaton OH 45320 USA
+1 937 456.8400 800 417.8417
+1 937 456.8434 Fax 800 417.8434 Fax
www.hennypenny.com
