Henny Penny OEA-323 Specification Sheet

PROJECT
Auto lift open fryers
Three-well auto lift open fryer,
model OEA-323
Standard Features
• Stainless steel construction for
easy-cleaning and long life.
• 3 heavy-duty stainless steel
rectangular fry pots with 7 year
warranty.
• Computron
®
8000 control with 10
programmable cook cycles for
each well, melt mode, load
compensation, proportional control,
idle mode, optional filter prompt
and customizable filter tracking,
clean-out mode.
• Each well can be programmed to
operate half baskets independently
or together at the touch of a button.
• 16-character digital display with
multiple language settings.
APPROVED APPROVED AS NOTED
AUTHORIZED SIGNATURE
© 2006 Henny Penny Corporation, Eaton, OH 45320 USA Revised 11/01/07
QUANTITY
General Information
Henny Penny auto lift open fryers
offer high-volume, integral multi-well
frying with auto lift capabilities. Auto
lift open fryers automatically raise
loads out of the fry pot when cooking
program is complete. This feature
promotes perfect results without
constant monitoring and can
significantly increase productivity in
lightly staffed operations.
The quiet, dependable auto lift
mechanism is designed into the high-
quality, high-efficiency Henny Penny
320 Series open fryer without adding
one square inch to the footprint.
Henny Penny's unique high-
efficiency heat-exchange design
produces extremely fast temperature
recovery—typically in seconds—while
requiring less than 2kW per gallon of
shortening. Fast recovery speeds up
production, saves energy, and
preserves frying oil quality by
• Fry pot protection system.
• Built-in filtration with stainless steel
Max filtering screen and filter
envelope.
• Rugged direct-drive lift mechanism
powered by quiet, low-voltage
motor.
• Motor and drive built into existing
cabinet—footprint is NOT
increased.
• Easy basket set and release.
• Specially designed cold zone
prevents scorching.
• Four heavy-duty casters, two
locking.
RESUBMIT
DATE
ITEM NO
OEA-323
3-well electric
MODEL
OGA-323
3-well gas
reducing temperature fluctuations.
Built-in filtration system filters hot
frying oil in under 4 minutes, with no
separate pumps or pans required. Hot
filtered oil returns directly to each well.
Quick, easy and frequent filtering
extends shortening life and can result
in significant savings in time and
direct shortening costs.
The OEA/OGA-323 auto lift open
fryer features three integral fry wells
with two lifters at each well for full or
half-basket loads. Henny Penny's
heavy-duty stainless steel rectangular
fry pots promote fast even cooking
and come with a 7-year warranty—the
best in the business.
The standard Computron
controller provides fully automatic,
programmable operation, as well as
energy-saving, filtration and load
management features.
Accessories shipped with unit
• Fry baskets—please select one
(3) full baskets
(2) full and (2) half baskets
(1) full and (4) half baskets
(6) half baskets
• (3) basket supports
• Max shortening filtration system
and (2) PHT filter envelopes.
Accessories and options available
separately
Shortening shuttle
Filter rinse hose
Fry well covers
Henny Penny Corporation
PO Box 60 Eaton OH 45320 USA
+1 937 456.8400 800 417.8417
+1 937 456.8434 Fax 800 417.8434 Fax
www.hennypenny.com
®
8000
