Fish Arch: A Fish Arch is the apparent "arch" that appears on the display when any object
moves through the sonar cone. The arch results from a gradual decrease in distance to
an object as it moves into the sonar cone. The distance to an object changes due to the
conical shape of the sonar beam, which causes the distance to be greater at the edges
of the beam than at the center of the beam. When this distance change is graphed on
the display, an arch appears.
Fish ID+™: Fish ID+™ is a Humminbird® feature that uses advanced sonar processing
algorithms to determine if a detected object is likely to be a fish. When the sonar signal
from an object meets strict parameters, the unit draws a Fish Symbol (or icon) and the
digital depth of the target. On DualBeam and DualBeam PLUS™ units, fish detected in
the narrow center beam are shown as shaded symbols, and fish detected in the wider
beam are shown as hollow symbols.
Fish Symbol: A Fish Symbol is the graphic that is displayed on the screen when Fish ID+
determines that a sonar return is likely to be a fish. See Fish ID+.
Freeze Frame: Freeze Frame is a Humminbird® feature that pauses the sonar scrolling
so that the image on screen can be studied with greater detail. See Instant Image
Update.
Frequency: Frequency is a measure of the number of sound wave cycles per second of a
sound impulse transmitted underwater. A typical frequency for fishfinders is 200 kHz,
which offers a good balance of performance under many conditions. Lower frequencies,
such as 50 kHz, are capable of penetrating to greater depths, but with less resolution.
Higher frequencies, such as 455 kHz, offer greater resolution, but are limited in depth
performance. Humminbird® uses a variety of frequencies that are optimized for specific
applications.
Grayscale: Grayscale is the use of varying shades of gray to represent the strength of the
sonar signal on the display , and is a very intuitive method of presenting information.
Traditionally, the strongest sonar signals are represented in black, and progressively
weaker signals are represented in progressively lighter shades of gray.
Grayscale, Inverse: Inverse Grayscale is a Humminbird® feature that reverses the
correlation of sonar signal strength and the shade of gray typically used to represent it.
The strongest sonar signals are represented by "white", and progressively weaker
signals are represented in progressively darker shades of gray. While somewhat counter-
intuitive, this method makes the sonar images crisper, and has the benefit of enhancing
2:38 PM
Page 100
93
the apparent sensitivity because the weaker signals appear bolder. Inverse grayscale
works well in very clear water. Debris-laden water often appears as a lot of clutter on
the screen.
Instant Image Update: Instant Image Update is a Humminbird® feature that updates all
the sonar information on the display when Sensitivity and a variety of sonar settings
(Bottom View, Range, etc.) are modified. This differs from the traditional functionality
that only updates the new sonar information collected after the setting change. Instant
Image Update permits more accurate fine-tuning of the display because the user can see
the results on the complete sonar graph. When combined with the Freeze Frame
feature, the user can adjust and understand the effects of many different sonar settings
quickly and easily.
Maximum Depth Menu: The Maximum Depth Menu is a Humminbird® feature that
optimizes performance based on the maximum operational depth set by the user.
Many Humminbird® units can operate across a very broad depth range (up to 2500
feet) which causes the unit to "look" up to that full depth under some circumstances.
Due to the speed of sound in water, this can result in less responsiveness because
the unit has to wait for a longer period of time to receive the sonar signal. When the
Maximum Depth menu is set to a lower value, the unit only looks up to the setting,
which increases the responsiveness of the unit. This is an important feature for
anyone operating in shallower depths!
Noise: Noise is unintentional, external sound waves that interfere with the optimal
operation of sonar. Noise appears as random "dots" on the display, and is caused by a
variety of sources. Electrical noise (from trolling motors, bilge pumps, VHF radios)
typically manifests as a consistent dot pattern. Electrical noise can be isolated by
selectively turning on and off other electrical devices to determine the source. Often re-
routing the power cable, or connecting to an alternative power supply (second battery)
can help overcome electrical noise. Hydrodynamic noise (from propeller and/or hull
cavitation) has a more random appearance and is generally related to boat speed, so
that faster operation results in more noise. Hydrodynamic noise can be overcome by
proper transducer installation. Many Humminbird® products have a Noise Filter menu
setting that allows the user to clear the screen of noise that is difficult to eliminate.
Pixels: Pixels are the "picture elements", or small square blocks, that make up the image
on the LCD. Measured as a vertical by horizontal number (i.e. 640 V x 320 H), this key
specification typically indicates the quality of resolution. In fishfinders, the total
