Fish Arch: A Fish Arch is the apparent "arch" that appears on the display when any
object moves through the sonar cone. The arch results from a gradual decrease in
distance to an object as it moves into the sonar cone. The distance to an object
changes due to the conical shape of the sonar beam, which causes the distance to
be greater at the edges of the beam than at the center of the beam. When this
distance change is graphed on the display, an arch appears.
Fish ID+ TM : Fish ID+ TM is a Humminbird® feature that uses advanced sonar processing
algorithms to determine if a detected object is likely to be a fish. When the sonar
signal from an object meets strict parameters, the unit draws a Fish Symbol (or icon)
and the digital depth of the target. On DualBeam and DualBeam PLUS
detected in the narrow center beam are shown as shaded symbols, and fish
detected in the wider beam are shown as hollow symbols.
Fish Symbol: A Fish Symbol is the graphic that is displayed on the screen when Fish
ID+ determines that a sonar return is likely to be a fish. See Fish ID+
Freeze Frame: Freeze Frame is a Humminbird® feature that pauses the sonar
scrolling so that the image on screen can be studied with greater detail. See Instant
Image Update.
Frequency: Frequency is a measure of the number of sound wave cycles per second
of a sound impulse transmitted underwater. A typical frequency for fishfinders is
200 kHz, which offers a good balance of performance under many conditions.
Lower frequencies, such as 50 kHz, are capable of penetrating to greater depths, but
with less resolution. Higher frequencies, such as 455 kHz, offer greater resolution,
but are limited in depth performance. Humminbird® uses a variety of frequencies
that are optimized for specific applications.
Grayscale: Grayscale is the use of varying shades of gray to represent the strength
of the sonar signal on the display , and is a very intuitive method of presenting
information. Traditionally, the strongest sonar signals are represented in black, and
progressively weaker signals are represented in progressively lighter shades of gray.
Grayscale, Inverse: Inverse Grayscale is a Humminbird® feature that reverses the
correlation of sonar signal strength and the shade of gray typically used to
represent it. The strongest sonar signals are represented by "white", and
progressively weaker signals are represented in progressively darker shades of gray.
While somewhat counter-intuitive, this method makes the sonar images crisper,
6:07 PM Page 100
TM units, fish
TM .
93
and has the benefit of enhancing the apparent sensitivity because the weaker
signals appear bolder. Inverse grayscale works well in very clear water. Debris-laden
water often appears as a lot of clutter on the screen.
Instant Image Update: Instant Image Update is a Humminbird® feature that
updates all the sonar information on the display when Sensitivity and a variety of
sonar settings (Bottom View, Range, etc.) are modified. This differs from the
traditional functionality that only updates the new sonar information collected
after the setting change. Instant Image Update permits more accurate fine-tuning
of the display because the user can see the results on the complete sonar graph.
When combined with the Freeze Frame feature, the user can adjust and understand
the effects of many different sonar settings quickly and easily.
Maximum Depth Menu: The Maximum Depth Menu is a Humminbird® feature that
optimizes performance based on the maximum operational depth set by the user. Many
Humminbird® units can operate across a very broad depth range (up to 2500 feet) which
causes the unit to "look" up to that full depth under some circumstances. Due to the speed
of sound in water, this can result in less responsiveness because the unit has to wait for a
longer period of time to receive the sonar signal. When the Maximum Depth menu is set
to a lower value, the unit only looks up to the setting, which increases the responsiveness
of the unit. This is an important feature for anyone operating in shallower depths!
Noise: Noise is unintentional, external sound waves that interfere with the optimal
operation of sonar. Noise appears as random "dots" on the display, and is caused by a
variety of sources. Electrical noise (from trolling motors, bilge pumps, VHF radios)
typically manifests as a consistent dot pattern. Electrical noise can be isolated by
selectively turning on and off other electrical devices to determine the source. Often re-
routing the power cable, or connecting to an alternative power supply (second battery)
can help overcome electrical noise. Hydrodynamic noise (from propeller and/or hull
cavitation) has a more random appearance and is generally related to boat speed, so
that faster operation results in more noise. Hydrodynamic noise can be overcome by
proper transducer installation. Many Humminbird® products have a Noise Filter menu
setting that allows the user to clear the screen of noise that is difficult to eliminate.
Pixels: Pixels are the "picture elements", or small square blocks, that make up the
image on the LCD. Measured as a vertical by horizontal number (i.e. 640 V x 320 H),
this key specification typically indicates the quality of resolution. In fishfinders, the
total resolution (vertical multiplied by horizontal) is often less important than the
"Vertical Pixel" resolution. See Pixels, Vertical.
