DIGITAL MULTIFUNCTIONAL SYSTEM
START GUIDE
Keep this manual close at hand for reference whenever needed.
MODEL: AR-5516S
AR-5520S
AR-5516
AR-5520
AR-5516D
AR-5520D
AR-5516N
AR-5520N
BEFORE USING
This section provides the
safety information to use
the machine and explains
how to use this manual.
SETUP
This section explains
software installation and
connection to a computer.
APPENDIX
This section includes the
troubleshooting and
specifications.
Advertisement
Table of Contents
Related Manuals for Sharp AR-5516S
Summary of Contents for Sharp AR-5516S
- Page 1 MODEL: AR-5516S AR-5520S AR-5516 AR-5520 AR-5516D AR-5520D DIGITAL MULTIFUNCTIONAL SYSTEM AR-5516N AR-5520N START GUIDE BEFORE USING This section provides the safety information to use the machine and explains how to use this manual. SETUP This section explains software installation and connection to a computer.
-
Page 3: Table Of Contents
HOW TO USE THE OPERATION GUIDE ..5 ● THE MEANING OF "R" IN ORIGINAL AND PAPER SIZE INDICATIONS......5 ● CONVENTIONS USED IN THIS MANUAL..6 ● SPF (AR-5516S/AR-5520S, AR-5516/AR-5520) ..6 ● RSPF (AR-5516D/AR-5520D/AR-5516N/AR-5520N) ..6 ● DIFFERENCES BETWEEN MODELS....6 SETUP BEFORE SOFTWARE SETUP ...... -
Page 4: Before Using
BEFORE USING CAUTIONS Follow the cautions below when using this machine. CAUTIONS ON USING Warning: • The fusing area is hot. Exercise care in this area when removing misfed paper. • Do not look directly at the light source. Doing so may damage your eyes. Caution: •... -
Page 5: Cautions On Handling
BEFORE USING The machine should be installed near an accessible power outlet for easy connection and disconnection. Be sure to connect the power cord only to a power outlet that meets the specified voltage and current requirements. Also make certain the outlet is properly grounded. Connect the machine to a power outlet which is not used for other electric appliances. -
Page 6: Environmental Information
BEFORE USING ENVIRONMENTAL INFORMATION Products that have earned the ENERGY STAR are designed to protect the environment ® through superior energy efficiency. ® The products that meet the ENERGY STAR guidelines carry the logo shown above. ® The products without the logo may not meet the ENERGY STAR guidelines. -
Page 7: How To Use The Operation Guide
Note file to your computer. • The Operation Guide can be printed out using Acrobat Reader. SHARP recommends printing out the sections which you refer to regularly. • Refer to "Help" of Acrobat Reader for more details on how to use Acrobat Reader. -
Page 8: Conventions Used In This Manual
Notes provide information relevant to the machine regarding specifications, functions, Note performance, operation and such, that may be useful to the user. SPF (AR-5516S/AR-5520S, AR-5516/AR-5520) This manual refers to the Single Pass Feeder as the "SPF". RSPF (AR-5516D/AR-5520D/AR-5516N/AR-5520N) This manual refers to the Reversing Single Pass Feeder as the "RSPF". -
Page 9: Setup
BEFORE SOFTWARE SETUP This chapter explains how to install and configure the software that is required for the printer and scanner functions of the machine. • The scanner function is not available on the AR-5516S/AR-5520S. Note • This manual refers to the CD-ROM that accompanied the machine simply as "CD-ROM". -
Page 10: Installing The Software (Ar-5516S/Ar-5520S/Ar-5516/Ar-5520/Ar-5516D/ Ar-5520D)
If the cable is connected, a Plug and Play window next step. will appear. If this happens, click the "Cancel" button to close the window and disconnect the cable. For AR-5516S/AR-5520S To connect the machine and a computer directly The cable will be connected in step 12. Note via a USB cable, normally click the "Standard"... - Page 11 A message will appear instructing you to connect the machine to your computer. Click the "OK" Follow the on-screen instructions. button. When "The installation of the SHARP software is After the installation, a message prompting complete." appears, click the "OK" button. Note you to restart your computer may appear.
-
Page 12: Connecting To A Computer (Ar-5516S/Ar-5520S/Ar-5516/Ar-5520/Ar-5516D/ Ar-5520D)
SETUP CONNECTING TO A COMPUTER (AR-5516S/AR-5520S/AR-5516/AR-5520/AR-5516D/AR-5520D) Follow the procedure below to connect the machine to your computer. A USB cable for connecting the machine to your computer is not included with the machine. Please purchase the appropriate cable for your computer. -
Page 13: Using The Machine As A Shared Printer
Click the "Display Readme" button to show sure to click "Continue Anyway" or "Yes". information on packages that are selected. For AR-5516S/AR-5520S You will return to the window of step 3. Click the "Printer Driver" button. Click the "Close" button. -
Page 14: Installing The Software (Ar-5516N/Ar-5520N)
SETUP INSTALLING THE SOFTWARE (AR-5516N/AR-5520N) • The screen images in this manual are mainly for Windows Vista. With other versions of Windows, some screen Note images may be different from those in this manual. • If an error message appears, follow the instructions on the screen to solve the problem. After the problem is solved, the installation procedure will continue. - Page 15 SETUP The printer or printers connected to Enter the IP address, subnet mask, the network will be detected. Click the and default gateway. The settings in the window below are examples. printer to be configured (the machine) Be sure to ask your network administrator for the and click the "Next"...
- Page 16 SETUP Install all of the software In the window for setting the If you have not set the IP Address yet, go to "Set the IP destination print port name, make Address" (p.12). sure that ":lp" appears at the end of the IP address and click the "Next"...
- Page 17 SETUP Choose the option you want to Select the model that you will be install using, and click the "Next" button. If you have not set the IP Address yet, go to "Set the IP Address" (p.12). • If you are using Windows Vista and a security warning window appears, be sure Caution Perform step 4 through 7 in "Set the IP...
- Page 18 SETUP If the machine will be used as a shared printer In the window for setting the on a network, select "Shared Printer" and destination print port name, make click the "Next" button. • For the port to be used, select the printer name set as sure that ":lp"...
- Page 19 SETUP Select the model that you will be When "The installation of the SHARP using, and click the "Next" button. software is complete." appears, click the "OK" button. Select whether or not you wish the printer to be your default printer and You will return to the window of step 3 click the "Next"...
-
Page 20: Configuring The Printer Driver
"start" menu, select "Control Panel", select "Printers and Other Hardware", and then select "Printers and Faxes". Click the "SHARP AR-XXXX" printer driver icon and select "Properties" from the "Organize" menu. In Windows XP/2000, select "Properties" from the "File"... -
Page 21: Setting Up Button Manager
"Select an event" pull-down menu. Select "ScanMenu SC2" from the "Select an event" pull-down menu. Select "Start this program", select "Sharp Button Manager U" from the pull-down menu. Do the same for each ScanMenu through "ScanMenu SC6". Click the "OK" button. -
Page 22: Windows 2000
SETUP Windows 2000 Click the "Start" button, select Select "Sharp Button Manager U" in "Settings", and then click "Control "Send to this application". Panel". Double-click the "Scanners and Cameras" icon. ScanMenu SC1 Select "SHARP AR-XXXX" and click the "Properties" button. -
Page 23: Appendix
If the software is not installed correctly, check the following items on your computer. The driver cannot be installed Plug and Play window does not appear (Windows 2000/XP) (AR-5516S/AR-5520S/AR-5516/AR-5520/ AR-5516D/AR-5520D) If the driver cannot be installed in Windows 2000/XP, follow these steps to check your computer's settings. -
Page 24: Removing The Software
"Hardware" tab, and click the "Device Manager" button. Click the icon beside "Other devices". If "SHARP AR-XXXX" appears, select and delete the item. If "Other devices" does not appear, close the Note "Device Manager" window. Install the software as explained in "INSTALLING THE SOFTWARE... -
Page 25: Specifications
APPENDIX SPECIFICATIONS AR-5516S/AR-5516/AR-5516D/AR-5516N AR-5520S/AR-5520/AR-5520D/AR-5520N Model Digital Multifunctional System, Desktop Type OPC drum Photoconductive type Fixed Document glass type Dry, electrostatic transfer Copy system Sheets, bound documents Originals Max. A3 Original sizes Max. A3 Min. A6 (A6 must be fed from the bypass tray) Copy size Image loss: Max. -
Page 26: Ambient Environment
APPENDIX Approx. 28.2 kg Approx. 33.1kg Weight Approx. 28.4 kg (AR-5516N) Approx. 33.3 kg (AR-5520N) 590 mm (W) x 550 mm (D) x 470 mm (H) 590 mm (W) x 550 mm (D) x 555 mm (H) Dimensions * First-copy time is measured with original on the document glass with the following settings made, in fully ready condition with fuser at operating temperature and mirror motor at operating speed, actual time may vary based on environment conditions. -
Page 27: Peripheral Devices
Please purchase a commercially available shielded cable. Button Manager Scanner utilities As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes Note for product improvement without prior notice. The performance specification figures indicated are nominal values of... -
Page 28: Information On Disposal
If the product is used for business purposes and you want to discard it: Please contact your SHARP dealer who will inform you about the take-back of the product. You might be charged for the costs arising from take-back and recycling. Small products (and small amounts) might be taken back by your local collection facilities. - Page 31 LUOKAN 1 LASERLAITE KLASS 1 LASERAPPARAT The above label is affixed to the laser unit inside the machine. SHARP ELECTRONICS (Europe) GmbH Sonninstraße 3, D-20097 Hamburg...
- Page 32 PRINTED IN FRANCE TINSE1936TSZ1...
