  • Page 1 VENTS SLM R12+ R9010170 ’ WNER S MANUAL 09022004 R5976654/00...
  • Page 2 Barco nv Events Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.89.70 Fax: +32 56.36.88.24 E-mail: events@barco.com Visit us at the web: www.barco.com Printed in Belgium...
  • Page 3 Changes Barco provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied war- ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice.

  • Page 5: Table Of Contents

    Table of contents TABLE OF CONTENTS 1. Safety Instructions ....................5 1.1 Warnings .
  • Page 6 Table of contents 7.2.4 Load file......................... . 49 7.2.5 Edit File .
  • Page 7 Table of contents 9.7 Serial Communication ....................... . . 96 9.7.1 Start Up of the Serial Communication .
  • Page 8 Table of contents R5976654 SLM R12+ 09022004...

  • Page 9: Safety Instructions

    The customer should never attempt to disassemble the lamp casing or to dispose of the lamp casing other than by returning it to BARCO. To prevent injuries and physical damage, always read this manual and all labels on the system before connecting to the wall outlet, or adjusting the projector.
  • Page 10 1. Safety Instructions Extra Safety manual Read also safety instructions in separate manual (R5976125). R5976654 SLM R12+ 09022004...

  • Page 11: Packaging And Dimensions

    2. Packaging and Dimensions 2. PACKAGING AND DIMENSIONS Overview • Projector Packaging • Box Content • Lens Packaging • Projector Case 2.1 Projector Packaging Way of Packaging The projector is packed in a carton box. To provide protection during transportation, the projector is surrounded with foam. The package is secured with banding and fastening clips.

  • Page 12: Projector Case

    2. Packaging and Dimensions They are packed in a carton. 2.4 Projector Case Dimensions The dimensions are given in mm 25.4mm = 1 inch FRONT VIEW IR-receiver AIR OUT AIR IN 64,5 520,5 Image 2-2 Front view dimensions Image 2-3 Side view dimensions R5976654 SLM R12+ 09022004...

  • Page 13: Installation Guidelines

    3. Installation Guidelines 3. INSTALLATION GUIDELINES Never use the projector when turned with the inputs downwards. The engines are non sealed versions. 3.1 General Before installing the projector, read first the safety instructions. Ambient Temperature Conditions. Careful consideration of things such as image size, ambient light level, projector placement and type of screen to use are critical to the optimum use of the projection system.

  • Page 14: Configuration

    3. Installation Guidelines Special Care for Laser Beams Special care should be used when DLP projectors are used in the same room as performant laser equipment. Direct or indirect hitting of a laser beam on to the lens can severely damage the Digital MicroMirror Devices™ in which case there is a loss of warranty Which screen type ? There are two major categories of screens used for projection equipment.

  • Page 15: Positioning The Projector

    3. Installation Guidelines Positioning the projector Table mounted, front projection Table/Top side facing ceiling SIDE VIEW Projector Screen Optical axis projection lens Floor CD = SH/2 + B - A Screen TOP VIEW Floor BACK VIEW Image 3-1 Table mounted configuration R5976654 SLM R12+ 09022004...
  • Page 16 3. Installation Guidelines Table mounted, front projection, second way. Table/Top side facing floor Projector SIDE VIEW Screen Optical axis projection lens Floor CD = SH/2 + B + A - 554mm Screen TOP VIEW Floor BACK VIEW Image 3-2 Table mounted configuration up side down Ceiling mounted, front projection Ceiling/Top side facing floor Ceiling...

  • Page 17: Safety Area Around Projector

    3. Installation Guidelines Ceiling mounted, front projection, second way. Ceiling/Top side facing ceiling Ceiling Screen Optical axis projection lens Projector SIDE VIEW CD = SH/2 + B + A - 554mm Screen CEILING VIEW Ceiling BACK VIEW Image 3-4 Ceiling mounted projector 3.3 Safety Area around projector Safety area Make sure the projector is located so that the air inlets and outlets for the cooling system are not obstructed.

  • Page 18: Re-Adjusting The Lamp Position In The Lamp Casing

    3. Installation Guidelines Image 3-5 Safety area around the projector 3.4 Re-adjusting the lamp position in the lamp casing As the projector has to be opened, this procedure has to be performed by qualified service technician. With higher run times, the light output of the lamp will decrease, which results in a lower light output on the screen. This light output decrease can be compensated by readjusting the position of the lamp.

  • Page 19: Lenses

    3. Installation Guidelines Image 3-6 Lamp adjustment access Image 3-7 Never turn the other screws ! These are factory aligned. 3.5 Lenses Overview • Lenses • Lens selection • Lens formulas • Lens Installation • Cleaning the lens R5976654 SLM R12+ 09022004...

  • Page 20: Lenses

    3. Installation Guidelines 3.5.1 Lenses Available lenses TLD(1.6–2.0:1) R9840670 TLD(2.0–2.8:1) R9840680 TLD(2.8–5.0:1) R9840690 TLD(1.2:1) R9840770 TLD(0.8:1) R9840900 TLD(5.0–8.0:1) R9840910 R9842040 TLD HB(0.8:1) R9842060 TLD HB(1.6–2.0:1) TLD HB(2.0–2.8:1) R9842080 TLD HB(2.8–5.0:1) R9842100 TLD HB(5.0–8.0:1) R9842120 3.5.2 Lens selection How to select ? 1.

  • Page 21: Lens Installation

    3. Installation Guidelines Metric formulas (meter) Inch formulas (inch) TLD HB(2.8–5.0:1) =2.84xSW-0.16 =2.84xSW-6.30 =5.18xSW-0.38 =5.18xSW-14.96 TLD HB(5.0–8.0:1) =4.97xSW-0.01 =4.97xSW-0.39 =8.28xSW-0.29 =8.28xSW-11.42 3.5.4 Lens Installation How to install ? Follow the next procedure: 1. Remove the foam rubber in the opening of the lens holder. 2.

  • Page 22: Battery Installation In The Rcu

    3. Installation Guidelines Do not use fabric softener when washing the cleaning cloth or softener sheets when drying the cloth. Do not use liquid cleaners on the cloth as doing so will contaminate the cloth. Other lenses can also be cleaned safely with this Toraysee cloth.
  • Page 23 3. Installation Guidelines How to stack? Handle as follow: 1. Put the second projector on the first one so that base plate of the second projector matches with the rigging socket of the first projector. (image 3-12) 2. Turn the rigging sockets of the second projector counter clockwise until they are free to move up and down. (image 3-13) 3.
  • Page 24 3. Installation Guidelines Image 3-14 Image 3-15 Mounting the security chain Mounting the security hook Image 3-16 Mounting the security hook (detail) How to open a secured rigging point? 1. Push the ring (A) of the first projector downwards and hold it in that position. (image 3-17) 2.

  • Page 25: Rigging Points And Accessories

    3. Installation Guidelines Image 3-17 Opening the rigging sockets 3.8 Rigging points and Accessories Clamps Slots are made in the carry handle frame for easy inserting the overlockers and for easy adjusting the clamps position so that this position matches with the rigging points. Consult a professional structural engineer prior to suspending the ceiling mount from a structure not intended for that use.
  • Page 26 3. Installation Guidelines Image 3-20 Mounting the clamp — detail How to mount the Overlockers to the truss? To mount the overlocker to the truss, handle as follow : 1. Open the fixation handle. (image 3-21) 2. Hook the clamp around the tube. The trigger automatically shuts the clamp.

  • Page 27: Connections

    4. Connections 4. CONNECTIONS Overview • Power connection • Switching on • Switching to standby • Switching off • Input Source Connections • Communication Connections 4.1 Power connection AC Power cord connection Use the supplied power cord to connect your projector to the wall outlet. Plug the female power connector into the male connector at the left of the projector.
  • Page 28 The total lifetime of the lamp for a safe operation is 500 hours max. Do not use it longer. Always replace with a same type of lamp. Call a BARCO authorized service technician for lamp replacement. Using a lamp for more than 500 hours is dangerous as the lamp could explode.

  • Page 29: Switching To Standby

    4. Connections 4.3 Switching to standby How to switch to standby? 1. Press Standby to switch the projector to standby. 4.4 Switching off How to switch off the projector? 1. Press first Standby. 2. Let cool down the projector until the fans stop blowing, at least 15 min. 3.

  • Page 30: Input Module Insertion

    4. Connections slot 1 RGB/Component slot 2 Video slot 3 not used slot 4 not used When using a RCVDS05, it is recommended to use a 5-cable output module in the RCVDS. The outputs of this module has to be connected to slot 1 of the projector.

  • Page 31: Fixed Slot (Slot 1 & 2)

    4. Connections How to select the new installed module? The new installed module can be selected with the digit buttons on the RCU or the local keypad. 4.5.4 Fixed slot (slot 1 & 2) Where to find? Slot 1 & 2 has 5 BNC input terminals for 5 cable input and a DVI plug for DVI input. Slot 1 has also an DVI output for loop through to a second projector.

  • Page 32: Serial Digital Input (Slot 3 & 4)

    4. Connections 5. Press ENTER. The internal system will scan the inputs and displays the result in the Input Slots menu. 6. Push the cursor key ↑ or ↓ to select the first or second slot. (menu 4-6) ADJUSTMENT MODE INSTALLATION INPUT SLOTS Select a path from below :...

  • Page 33: Hd Sdi Digital Input (Slot 3 & 4)

    4. Connections Diagnostic Code IR-Receiver Green Operation Red Stand-by Two way Hardwired hardwired remote remote CTRL 2 CTRL 3 Sync OK Hardwired remote RS232/422 IN RS232/422 OUT COMM PORT TRIGGER OUT CTRL 1 SDI DIGITAL INPUT HD SDI DIGITAL MODULE High Bandwidth 5 CABLE INPUT DVI INPUT High Bandwidth 5 CABLE INPUT...

  • Page 34: Digital Video Decoder Input

    4. Connections Diagnostic Code IR-Receiver Green Operation Red Stand-by Two way hardwired Hardwired remote remote CTRL 2 CTRL 3 Sync OK Hardwired remote RS232/422 OUT COMM PORT TRIGGER OUT RS232/422 IN CTRL 1 SDI DIGITAL INPUT HD SDI DIGITAL MODULE High Bandwidth 5 CABLE INPUT DVI INPUT High Bandwidth 5 CABLE INPUT...
  • Page 35 4. Connections Diagnostic Code IR-Receiver Green Operation Red Stand-by Two way Hardwired hardwired remote remote CTRL 2 CTRL 3 Sync OK Hardwired remote RS232/422 IN RS232/422 OUT COMM PORT Ethernet CTRL 1 Y/Vid S-Video HD SDI DIGITAL MODULE DIGITAL VIDEO DECODER High Bandwidth 5 CABLE INPUT DVI INPUT High Bandwidth 5 CABLE INPUT...

  • Page 36: Communication Connections

    4. Connections 4.6 Communication Connections Overview • RS232 (RS422) Connection • Communication with peripherals • Network connection 4.6.1 RS232 (RS422) Connection Application Remote control : easy adjustment of projector via an IBM PC (or compatible) or MAC connection. allow storage of multiple projector configurations and set ups. wide range of control possibilities.

  • Page 37: What Can Be Done

    4. Connections What can be done? When the optional network connection is installed, the projector can be connected to a LAN (local area network) (Ethernet). Once installed and connected to the LAN, users are capable of accessing the projector from any location, inside or outside their company network from a standard web browser.
  • Page 38 4. Connections R5976654 SLM R12+ 09022004...

  • Page 39: Getting Started

    5. Getting Started 5. GETTING STARTED 5.1 RCU & Local keypad How controlling the projector ? The projector can be controlled by the local keypad or by the remote control unit. Location of the local keypad ? The local keypad is located on the input side of the projector. Remote control functions.

  • Page 40: Operating The Projector

    5. Getting Started Barco key selection key, to get direct access to the lens adjustment menus. ADJUST key, to enter or exit the adjustment mode. Address key (recessed key), to enter the address of the projector (between 0 and 9). Press the recessed address key with a pencil, followed by pressing one digit button between 0 and 9.

  • Page 41: Switching To Standby

    5. Getting Started EXIT ENTER STBY PAUSE TEXT FREEZ HELP PHASE SHARPNESS TINT COLOR STANDBY EXIT BRIGHTNESS ENTER CONTRAST TEXT PAUSE SHARPN TINT BRIGHTN PHASE COLOR CONTRAST Image 5-2 Lamp Run time indication see chapter "4. Connections", "Switching on", page 23 Lamp Light output indication see chapter "4.

  • Page 42: Quick Set Up Adjustments

    Quick Lens Adjustment Quick zoom/focus adjustment 1. Press the Selection key *, Barco key. The zoom/focus menu will be displayed. (image 5-3) 2. Push the cursor key ↑ or ↓ to zoom and ← or → to focus the image.

  • Page 43: Quick On Screen Color Change

    <ENTER> to shift <EXIT> to return Image 5-3 Quick shift adjustment 1. Press the Selection key *, Barco key. The zoom/focus menu will be displayed (image 5-3). 2. Press ENTER. The shift menu will be displayed. (image 5-4) 3. Push the cursor key ↑ or ↓ to shift the image up or down and ← or → to shift the image left or right.

  • Page 44: Using The Rcu

    5. Getting Started 5.5 Using the RCU Pointing to the reflective screen 1. Point the front of the RCU to the reflective screen surface. (image 5-5) Ceiling IR sensor Screen Image 5-5 Hardwired Remote Input 1. Plug one end of the remote cable in the connector on the bottom of the RCU. 2.
  • Page 45 5. Getting Started Hardwired to the XLR input 1. Plug one end of the remote cable in the connector on the bottom of the RCU 2. Plug the other end in the connector in the front panel of the projector labelled Hardwired CTRL2. (image 5-7) Diagnostic Code IR-Receiver Green Operation...

  • Page 46: Projector Address

    5. Getting Started IR sensor IR sensor Side of projector Table Rear of projector Front of projector 45ø 45ø 45ø 45ø 45ø 45ø EXIT ADDR ENTER STBY MUTE TEXT FREEZ EXIT ENTER ADDR SHARPNESS EXIT STBY MUTE TEXT FREEZ TINT ADDR ENTER COLOR...

  • Page 47: Displaying And Programming Addresses

    5. Getting Started 5.6.2 Displaying and Programming addresses Displaying the Projector Address on the Screen. 1. Press Address key (recessed key on the RCU) with a pencil. The projector’s address will be displayed in a ’Text box’ To continue using the RCU with that specific address, it is necessary to enter the same address with the digit buttons (address between 0 and 9) within 5 seconds after pushing the address key.
  • Page 48 5. Getting Started The Stand-by Key When the Stand-by key is pressed, the image projection is stopped and the projector goes to stand-by. This situation is used when a projection stop is planned for a longer period. R5976654 SLM R12+ 09022004...

  • Page 49: Start Up Of The Adjustment Mode

    6. Start up of the Adjustment mode 6. START UP OF THE ADJUSTMENT MODE 6.1 Start up Possible paths There are 3 possible paths to follow once in the Adjustment mode. They are : • Installation - Installation should be selected if a new input module is installed or a new source is connected to an existing input module.

  • Page 50: Menus On Local Lcd Display

    6. Start up of the Adjustment mode Entering your password 1. The first digit position is highlighted. Enter the first digit. (menu 6-2) The highlighted square jumps to the next position. 2. Continue with the other digits Example : 2 3 1 9 When your password is correct, you gain access to the selected item.

  • Page 51: Random Access Adjustment Mode

    7. Random Access Adjustment Mode 7. RANDOM ACCESS ADJUSTMENT MODE Overview • Overview Flow • Picture Services • Picture Tuning • Geometry • ScenergiX • Picture in Picture (PiP) • Save Changes 7.1 Overview Flow Overview LOAD EDIT RENAME FILE SERVICE COPY DELETE OPTIONS...

  • Page 52: Picture Services

    7. Random Access Adjustment Mode Start up 1. Push the cursor key ↑ or ↓ to highlight Random Access. (menu 7-1) 2. Press ENTER. (menu 7-2) ADJUSTMENT MODE RANDOM ACCESS ADJUSTMENT MODE Select a path from below : FILE SERVICE RANDOM ACCESS PICTURE TUNING INSTALLATION...

  • Page 53: Start Up

    7. Random Access Adjustment Mode Possible file Manipulations The following file manipulations are possible : • Load : installation of a file for a new source. • Edit : editing a loaded file to the source specs. • Rename : renaming a file. •...

  • Page 54: Edit File

    7. Random Access Adjustment Mode How to load a file ? 1. Push the cursor key ↑ or ↓ to select the best fitting file. (menu 7-7) 2. Press ENTER to select. A confirm Load file menu will be displayed with the newly created file and the one on which the new file is based on. (menu 7-8) 3.

  • Page 55: Changing The Settings

    7. Random Access Adjustment Mode 7.2.5.2 Changing the settings Different methods The 3 different methods to change a setting will be describe hereafter. These methods are: • with the numeric keys on the remote control. • with the arrow keys selecting the changing digit. •...
  • Page 56 7. Random Access Adjustment Mode Vertical Start number of lines between the start of the input signal and start of the image on the screen. Interlaced [On] or [Off] this selection is automatically filled when active file has to be edited. If the image is wrong due to mismeasurement, use the ENTER key to toggle between [On] and [Off].
  • Page 57 7. Random Access Adjustment Mode Vertical refresh The way of updating the image information. Not available for PAL-NTSC-SECAM sources. This [sync/async] option will be displayed in gray. • For sources with a vertical frequency up to 60 Hz : the vertical refresh rate is the same as the vertical frequency of the incoming source.

  • Page 58: Rename

    7. Random Access Adjustment Mode 7.2.6 Rename Start Up To change the name of a selected file : 1. Push the cursor key ↑ or ↓ to highlight Rename. (menu 7-13) 2. Press ENTER. The Rename selection menu will be displayed. (menu 7-14) 3.

  • Page 59: Copy

    7. Random Access Adjustment Mode 7.2.7 Copy Start Up To copy the name of a selected file : 1. Push the cursor key ↑ or ↓ to highlight Copy. 2. Press ENTER. The Copy selection menu will be displayed. (menu 7-17) 3.

  • Page 60: File Options

    7. Random Access Adjustment Mode 4. Press ENTER to select. If [all] is selected, your password has to be entered before all files will be deleted. A confirmation menu "Delete file ’file name’?" is displayed. (menu 7-22) 5. Press ENTER to delete the file, press EXIT if you want to keep it. Note: The active file cannot be deleted.

  • Page 61: Picture Tuning

    7. Random Access Adjustment Mode 7.3 Picture Tuning 7.3.1 Start up Start up To improve the image quality, the items in the Picture Tuning menu can be toggled or adjusted. To start up the Picture Tuning : 1. Push the cursor key ↑ or ↓ to highlight Picture Tuning. (menu 7-25) 2.

  • Page 62: Gamma

    7. Random Access Adjustment Mode White X Image 7-3 7.3.3 Gamma What can be adjusted ? With the gamma correction adjustment, it is possible to accurately set the gamma of the projector image. Changing the gamma value 1. Push the cursor key ↑ or ↓ to highlight Gamma. (menu 7-29) 2.

  • Page 63: Noise Reduction

    7. Random Access Adjustment Mode How to select. 1. Push the cursor key ↑ or ↓ to highlight Color Space. (menu 7-30) The Color Space selection menu will be displayed. (menu 7-31) 2. Push the cursor key ↑ or ↓ to highlight the desired color space and press ENTER. Projector Maximum color space European Broadcasting Union.

  • Page 64: Input Balance

    7. Random Access Adjustment Mode 7.3.6 Input Balance Why adjusting the input balance? The input balance is normally correct adjusted in the factory. But due to signal distribution or signal transmission, a color imbalance can be the result. This imbalance can be adjusted source by source for color critical applications. These adjustments influence only the actual custom adjustment file.

  • Page 65: Input Balance For Yuv Signals

    7. Random Access Adjustment Mode 4. Adjust the contrast to a maximum value until the green noise becomes visible in the white areas and return one step. 5. Adjust with the cursor keys ↑ or ↓ or ← or → until the red respectively blue noise becomes visible in the white areas and return one step.

  • Page 66: Returning To The Factory Defaults

    7. Random Access Adjustment Mode 7.3.6.3 Returning to the factory defaults How to return to the factory defaults 1. Push the cursor key ↑ or ↓ to highlight Default. (menu 7-38) 2. Press ENTER to select. The default settings will be loaded. INPUT BALANCE BLACK BALANCE WHITE BALANCE...

  • Page 67: Geometry Start Up

    7. Random Access Adjustment Mode 7.4.2 Geometry start up Start up 1. Push the cursor key ↑ or ↓ to highlight Geometry. (menu 7-39) 2. Press ENTER to select. The geometry menu will be displayed. (menu 7-40) ADJUSTMENT MODE GEOMETRY Select a path from below : SHIFT SIZE...

  • Page 68: Size

    7. Random Access Adjustment Mode How to shift the image ? 1. Push the cursor key ↑ or ↓ to highlight Shift. (menu 7-41) 2. Press ENTER to select. 3. Push the cursor key ↑ or ↓ to shift the image in a vertical direction. Push the cursor key ←...

  • Page 69: Side Keystone

    7. Random Access Adjustment Mode Image 7-5 Size adjustment Horizontal size adjustment Vertical size adjustment Size adjustment 1. Push the cursor key ↑ or ↓ to highlight Size. (menu 7-42) 2. Press ENTER to select. 3. Push the cursor key ↑ or ↓ to size the image in a vertical direction. Push the cursor key ←...

  • Page 70: Blanking

    7. Random Access Adjustment Mode Image 7-6 Side Keystone Side keystone adjustment 1. Push the cursor key ↑ or ↓ to highlight Side Keystone. (menu 7-43) 2. Press ENTER to select. 3. Push the cursor key ← or → to adjust the keystone of the image. When the upper part of the image is wider than the lower part of the image, push the cursor key ←.

  • Page 71: Aspect Ratio

    7. Random Access Adjustment Mode Image 7-7 Blanking Top blanking Bottom blanking Left blanking Right blanking Adjusting the blanking. 1. Push the cursor key ↑ or ↓ to highlight Blanking. (menu 7-44) 2. Press ENTER to display the blanking menu. (menu 7-45) 3.

  • Page 72: Geometry Options

    7. Random Access Adjustment Mode How to set up the desired aspect ratio ? 1. Push the cursor key ↑ or ↓ to highlight Aspect Ratio. (menu 7-46) 2. Press ENTER to scroll between [5:4], [4:3], [16:9], [2.35], [1.88] or [1.78]. GEOMETRY SHIFT SIZE...

  • Page 73: Order Information

    7. Random Access Adjustment Mode 7.5.1 Order information Order numbers SLM G5 R9840880 SLM R6 R9840890 SLM G8/G10 R9841500 SLM R8/R10/R12+ R9841510 7.5.2 Introduction When available ? ScenergiX is only available as an option, some menu items will be grayed out when this option is not installed. Why ScenergiX ? When working in a multichannel setup the SLM R12+ and its Soft Edge possibilities enable an image blending that gives the ap- pearance of a single view, thus achieving realistic immersion for the majority of wide screen applications.

  • Page 74: Preparations

    7. Random Access Adjustment Mode 7.5.3 Preparations ScenergiX Preparations To ensure proper ScenergiX adjustment, be sure that the following adjustments are done perfectly on all projectors: • Convergence (Electronic Convergence). • Geometry • Color Matching (Color Temperature, Input Balance, Gamma) 7.5.4 Scenergix How to activate Scenergix?

  • Page 75: Scenergix Overlap Zone (Vertical Scenergix)

    7. Random Access Adjustment Mode Horizontal Resolution source : number of active pixels of the source. Adjustment of Active pixels (Pact) of the first projector 1. Go to File –> Edit menu of first projector. 2. Enter value for horizontal active (= Pact) as follows : Pact = [(Horz.

  • Page 76: Scenergix Size Adjustment

    7. Random Access Adjustment Mode Adjustment of Active lines (Lact) of second projector 1. Go to File –> Edit menu of second projector. 2. Enter value for vertical act (= Lact) as follows : Lact = [(Vert.. resolution of 1 projector)/(Total vert. screen resolution)] x (vert. resolution source) 3.
  • Page 77 7. Random Access Adjustment Mode Image 7-12 Width selections Image 7-13 Width set up for projector 1 R5976654 SLM R12+ 09022004...

  • Page 78: Adjusting The Black Level Of The Images

    7. Random Access Adjustment Mode Image 7-14 Width set up for projector 2 7.5.8 Adjusting the black level of the images For dark images, the overlap zone will be brighter then the rest of the images. Therefore we can rise the black level of the remaining image (excluding the overlap zone).

  • Page 79: Picture In Picture (Pip)

    7. Random Access Adjustment Mode 7.6 Picture in Picture (PiP) Overview • Introduction to PiP • Picture in Picture activation • Picture in Picture source • Position of Picture in Picture window • Set up of the Quick Selection 7.6.1 Introduction to PiP PiP stands for "Picture in Picture"...

  • Page 80: Picture In Picture Activation

    7. Random Access Adjustment Mode 7.6.2 Picture in Picture activation How to activate PIP? 1. Push the cursor key ↑ or ↓ to highlight PIP. (menu 7-53) 2. Press ENTER to select. The PIP menu will be displayed. (menu 7-54) 3.

  • Page 81: Set Up Of The Quick Selection

    7. Random Access Adjustment Mode How to position? 1. Push the cursor key ↑ or ↓ to highlight Position. (menu 7-56) 2. Press ENTER to toggle between Top-Left, Top-Right, Bottom-Left or Bottom-Right. STATUS [ON] SOURCE 01 POSITION [Top-Left] QUICK SELECT [OFF] Select with ↑...
  • Page 82 7. Random Access Adjustment Mode R5976654 SLM R12+ 09022004...

  • Page 83: Installation Mode

    8. Installation Mode 8. INSTALLATION MODE Overview • Start up of the Installation mode • Input Slots • 800 peripheral • Source Switching • No Signal • Contrast Enhancement • Convergence • Configuration • Lens Adjustment • Quick Access Keys •...

  • Page 84: What If A Switcher Is Connected To The Projector

    8. Installation Mode To view or the change the input configuration. 1. Push the cursor key ↑ or ↓ to highlight Input Slots. (menu 8-3) 2. Press ENTER to select. The input slots menu will be displayed. (menu 8-4) INSTALLATION INPUT SLOTS INPUT SLOTS 800 PERIPHERAL...

  • Page 85: Peripheral

    8. Installation Mode 8.3 800 peripheral Overview • Defining the output module of the RCVDS05. • Defining the Infrared Communication protocol 8.3.1 Defining the output module of the RCVDS05. Which module are available? When a RCVDS05 is connected to the projector, the type of output module of this RCVDS05 has to be defined in the 800 peripheral menu.

  • Page 86: Source Switching

    8. Installation Mode 8.4 Source Switching Switching from one source to another. To minimize undesired effects when switching from one source to another one can use the Seamless switching mode, beside Seam- less switching there is a choice between several effects which render the transitions more enjoyable. How to select a switching mode 1.

  • Page 87: Changing The Background Color

    8. Installation Mode 8.5.1 Changing the Background Color How to change ? 1. Push the cursor key ↑ or ↓ to highlight No signal. (menu 8-11) 2. Press ENTER to select. The no signal menu will be displayed. (menu 8-12) 3.

  • Page 88: Contrast Enhancement

    8. Installation Mode How to change ? To set up the shutdown time, handle as follow: 1. Push the cursor key ↑ or ↓ to highlight No Signal. (menu 8-15) 2. Press ENTER to select. The no signal menu will be displayed. (menu 8-16) 3.

  • Page 89: Convergence

    8. Installation Mode 8.7 Convergence What can be done? The convergence of the displayed image can be adjusted only by a qualified service technician. How to start up? 1. Push the cursor key ↑ or ↓ to highlight Convergence. (menu 8-20) 2.

  • Page 90: Lens Adjustment

    8. Installation Mode 8.9 Lens Adjustment What can be done ? All lens adjustments are motorized and can be adjusted with the RCU. The following items can be adjusted: • zoom/focus • shift • Options : same zoom/focus for all files, yes or no. How to start up.

  • Page 91: Quick Access Keys

    8. Installation Mode Options The zoom/focus and shift can be set the same for all files. 1. Push the cursor key ↑ or ↓ to highlight Options. (menu 8-27) 2. Press ENTER to select. The Lens Options menu will be displayed. (menu 8-28) 3.

  • Page 92: Osd

    8. Installation Mode 8.11 OSD Overview • Color Settings • Menu Position 8.11.1 Color Settings How to change 1. Push the cursor key ↑ or ↓ to highlight OSD. (menu 8-31) 2. Press ENTER to select. 3. Push the cursor key ↑ or ↓ to highlight Highlighted item color. (menu 8-32) 4.

  • Page 93: Available Patterns

    8. Installation Mode Available patterns Outline Hatch Color bars Multiburst Checker board Page Char Alpha numeric char How to select an internal patterns? 1. Push the cursor key ↑ or ↓ to highlight Internal Patterns. (menu 8-35) 2. Press ENTER to select. The internal patterns menu will be displayed.
  • Page 94 8. Installation Mode R5976654 SLM R12+ 09022004...

  • Page 95: Service Mode

    1. Push the cursor key ↑ or ↓ to highlight Service. (menu 9-1) 2. Press ENTER to display the service mode menu. (menu 9-2) ADJUSTMENT MODE SERVICE SERVICE Select a path from below : IDENTIFICATION BARCO LOGO CHANGE PASSWORD ADD INS RANDOM ACCESS CHANGE LANGUAGE PRESET INPUT BALANCE INSTALLATION CHANGE PROJ.

  • Page 96: Password

    This item is password protected when the password strap is installed. The password function is enabled when the password strap, second switch of S2 on the controller module is installed. Consult an authorized Barco service technician to change the strap position. About password types.

  • Page 97: Access Control List

    9. Service Mode Image 9-1 Image 9-2 Access password switch Image 9-4 Image 9-3 Metal top cover How to change the password ? 1. Push the cursor key ↑ or ↓ to highlight Change Password. (menu 9-6) 2. Press ENTER to display the Change Password menu. (menu 9-7) Note: Only possible when Owner.

  • Page 98: Access Levels

    CHANGE PASSWORD ACCESS CONTROL LIST IDENTIFICATION Enter new password Menu CHANGE PASSWORD OWNER 0000 Adj mode CHANGE LANGUAGE USER 0000 BARCO LOGO CHANGE PROJ. ADDRESS GUEST 0000 Change add SERIAL COMMUNICATION NETWORK ACCESS CONTROL LIST O=owner, U=user, G=Guest LAMP E=everybody DIMMING Select with ↑...

  • Page 99: Changing Language

    9. Service Mode 9.5 Changing Language Start up 1. Push the cursor key ↑ or ↓ to highlight Change Language. (menu 9-11) 2. Press ENTER to display the Change Language menu. (menu 9-12) 3. Push the cursor key ↑ or ↓ to highlight the desired language. 4.

  • Page 100: Serial Communication

    9. Service Mode 4. Press ENTER to activate. The address digit will be highlighted. 5. Select 0 or 1 with the ↑ or ↓ keys enter the new value with the numeric keys. SERVICE CHANGE PROJ. ADDRESS IDENTIFICATION PROJECTOR ADDRESS CHANGE PASSWORD CHANGE LANGUAGE COMMON ADDRESS (RC5) 0...

  • Page 101: Baud Rate Setting

    9. Service Mode 9.7.2 Baud rate Setting Set up To change the baud rate, handle as follow: 1. Push the cursor key ↑ or ↓ to highlight Baudrate. (menu 9-19) The actual baud rate will be displayed. 2. Press ENTER to toggle between the available baudrates. Default : 9600 SERIAL COMMUNICATION PROJECTOR ADDRESS 001...

  • Page 102: Rs422 Termination

    9. Service Mode 9.7.4 RS422 Termination Set up The last projector in a line should be RS422 terminated (ON position). All others in the line should be in the OFF position. To change the termination position : 1. Push the cursor key ↑ or ↓ to highlight RS422 Termination. (menu 9-21) The actual setting will be displayed.

  • Page 103: Lamp

    9. Service Mode Entering the necessary addresses. 1. Select the IP address with the cursor keys. (menu 9-24) 2. Press ENTER to edit. 3. Enter or reprogram the address with the numeric keys (contact your network responsible for the correct address). An address contains 4 octets with a maximum value of 255, separated by a bullet.
  • Page 104 9. Service Mode Clo value Time [h] Image 9-5 CLO function of one projector Linked CLO, used by multiple projectors If the linked CLO function is in the OFF position, the lamp of each projector will follow its own life cycle curve (dotted lines). When in the ON position and linked as described below, all projectors will use the preprogrammed CLO value as long as no projector in the chain is using its maximum lamp power already.
  • Page 105 9. Service Mode Proj 2 Proj 3 Proj 4 Proj 1 Terminator Image 9-7 Which information is available serial number unique serial number of the lamp type lamp type run time total time the lamp is used in this or other projectors. remaining run time time left before the lamp must be replaced Using the lamp longer than the maximum run time may damage the projector.

  • Page 106: Dimming

    OFF: no key on the RCU is used to display the BARCO logo. TEXT: the TEXT key on the RCU is used to display or to remove the BARCO logo with one single push on this key (only in operational mode).

  • Page 107: Add-Ins

    5. To reprogram the key, use the cursor key ↑ , ↓,← or → or the numeric keys for the digits. When the entered key is correct, the indication ’Software : not activated’ will change in ’activated’. 6. Press ENTER to confirm. SERVICE ADD-INS INSTALL ADD-INS BARCO LOGO CLO [INACTIVE] ADD INS SCENERGIX [INACTIVE] KEY :xxxxxxxxxxxxxx PRESET INPUT BALANCE...

  • Page 108: Advanced Processing

    The following warning will be displayed : (menu 9-35) Preset input balance is reserved to qualified service personnel. If you are not qualified, press EXIT to cancel the panel adjust- ments. SERVICE WARNING BARCO LOGO ADD INS PRESET INPUT BALANCE PRESET INPUT BALANCE ADVANCED PROCESSING...

  • Page 109: Diagnosis

    Start up 1. Push the cursor key ↑ or ↓ to highlight Diagnosis. (menu 9-38) 2. Press ENTER to select. The diagnosis menu will be displayed. (menu 9-39) SERVICE DIAGNOSIS BARCO LOGO ADD INS PRESET INPUT BALANCE SMPS ADVANCED PROCESSING LPS1...

  • Page 110: 3Dmd

    9. Service Mode 9.15.3 DMD How to select the overview? 1. Push the cursor key ↑ or ↓ to highlight DMD. (menu 9-42) 2. Press ENTER to select. An overview of the working of the DMD’s will be displayed. (menu 9-43) DIAGNOSIS STATUS RED STATUS GREEN...

  • Page 111: 6Voltages

    9. Service Mode 9.15.6 Voltages How to select the overview? 1. Push the cursor key ↑ or ↓ to highlight Voltages. (menu 9-48) 2. Press ENTER to select. The voltage overview window will be displayed. (menu 9-49) DIAGNOSIS VOLTAGES FAN1 VOLTAGE FAN2 VOLTAGE SMPS FAN3 VOLTAGE...
  • Page 112 9. Service Mode R5976654 SLM R12+ 09022004...

  • Page 113: Programmable Function Keys

    10. Programmable Function Keys 10. PROGRAMMABLE FUNCTION KEYS 10.1 Function Keys What can be done with these keys? The five function keys on top of an adapted remote control can be programmed as short cut keys (quick access) to almost any adjustment menu.
  • Page 114 10. Programmable Function Keys R5976654 SLM R12+ 09022004...

  • Page 115: Standard Source Set Up Files

    A. Standard Source set up Files A. STANDARD SOURCE SET UP FILES A.1 Table overview Table overview The following standard source files are pre-programmed in the projector. Name Resolu- Fvert FHor Fpix Ptot Pact Ltot Lact tion 1600_48V 1600x600i 48,040 62,500 135,000 2160...
  • Page 116 A. Standard Source set up Files Name Resolu- Fvert FHor Fpix Ptot Pact Ltot Lact tion INTER_GR 1184x886 67,170 61,796 92,941 1504 1184 MAC_2 640x480 66,667 35,000 30,240 MAC_3 512x384 60,147 24,480 15,667 MAC_4 560_384 60,147 24,480 17,234 512x342 60,158 22,259 16,670 MAC_5...
  • Page 117 A. Standard Source set up Files Name Resolu- Fvert FHor Fpix Ptot Pact Ltot Lact tion SUNXGA77 1024x768 77,069 62,040 84,375 1360 1024 SUP_MAC 1024x768 60,000 48,780 63,999 1312 1024 SVGA_56V 800x600 56,250 35,156 36,000 1024 SVGA_60V 800x600 60,317 37,879 40,000 1056 SVGA_72V...
  • Page 118 A. Standard Source set up Files R5976654 SLM R12+ 09022004...

  • Page 119: Cleaning The Dust Filters

    B. Cleaning the dust filters B. CLEANING THE DUST FILTERS As the projector has to be opened, this procedure has to be performed by qualified service technician. When should it be done? Depending on the environment, the dust filters should be cleaned at least when replacing the lamp. When the projector operates in dusty environment, clean the dust filters earlier than when replacing the lamp.
  • Page 120 B. Cleaning the dust filters Image B-1 Removing stacking sockets Image B-2 Input box slide out R5976654 SLM R12+ 09022004...
  • Page 121 B. Cleaning the dust filters Image B-3 Front screw top cover removal Image B-4 Dust filter removal How to clean 1. Clean the dust filter with a dry cloth or blow out with compressed air. Reinsert the dust filters and put the cover back on its place by following the opposite procedure. Take care to click the lens light cover into its position.

  • Page 122: Dust Filter On The Back Side

    B. Cleaning the dust filters B.2 Dust filter on the back side Necessary tools • Flat screwdriver • Philips screwdriver What should be done To get access to the dust filters, the back cover must be removed. How to remove 1.

  • Page 123: Dust Filter On The Bottom Side

    B. Cleaning the dust filters Image B-7 Dust filter removal Image B-8 Dust filter removal How to clean 1. Clean the dust filter with a dry cloth or blow out with compressed air. Reinsert the dust filters and put the cover back on its place by following the opposite procedure. B.3 Dust filter on the bottom side Necessary tools No tools.
  • Page 124 B. Cleaning the dust filters Image B-9 Dust filter bottom side How to clean 1. Clean the dust filter with a dry cloth or blow out with compressed air. 2. Reinsert the dust filter. R5976654 SLM R12+ 09022004...

  • Page 125: Troubleshooting

    C. Troubleshooting C. TROUBLESHOOTING C.1 Error codes Overview The following table gives an overview of some important error codes displayed on the LED display of the projector. Error code Description Caused by Action 2002 lamp start failed • hot restrike •...
  • Page 126 C. Troubleshooting Error code Description Caused by Action 4111 30V too low Call a qualified service engineer 4112 15V too low Call a qualified service engineer 4113 12V too low Call a qualified service engineer 4114 5V too low Call a qualified service engineer 4115 3V3 too low Call a qualified service engineer...

  • Page 127: Glossary

    Glossary GLOSSARY 2:2 pull-down The process of transferring 24-frames/sec film format into video by repeating each frame (used for PAL DVD’s) as two video fields. ( AD ) 3:2 pull-down Method used to map the 24 fps of film onto the 30 fps (60 fields) or 25 fps (50 fields), so that one film frame occupies three video fields, the next two, etc.
  • Page 128 Glossary R5976654 SLM R12+ 09022004...

  • Page 129: Index

    Index INDEX Function Keys programming Address Fuses Program Adjustment 38–39, 46 Local LCD Display Quick set up 38–39 geometry Lens introduction On screen color Geometry 62–68 Adjustment mode 45, 47–48 Aspect ratio Random Access 47–48 Blanking Picture Services Options Start up Shift start up Side Keystone...
  • Page 130 57–61 built-up Color space Service Mode 91–93, 95–99, 102–106 Color Temperature Add-Ins Available Temperatures Advanced Processing Gamma Minimum Delay Input balance BARCO Logo Input Balance 60–61 Change Password Black Balance Common address 60–61 Change Noise Reduction Diagnosis 105–106 Start up 76–77...
  • Page 131 Revision Sheet Barco nv Events/Documentation Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.89.70, Fax: +32 56.36.88.24 E-mail: antoon.dejaegher@barco.com, Web: www.barco.com From: Date: Please correct the following points in this documentation (R5976654/00): page wrong correct R5976654 SLM R12+ 09022004...

Table of Contents
