- Page 1 All manuals and user guides at all-guides.com BARCO PROJECTION SYSTEMS SLM G5 Executive R9002780 OWNER'S MANUAL Date: 13.07.2001 Rev.: 00 Art. No.: R5976262...
- Page 2 Produced by BARCO NV, june 2001. All rights reserved. Trademarks are the rights of their respective owners. BARCO n.v./Projection Systems Noordlaan 5 B-8520 Kuurne Belgium Tel : +32/56/368211 Fax : +32/56/351651 E-mail : sales.bps@barco.com Visite Barco at the web : http://www.barco.com Printed in Belgium...
-
Page 3: Table Of Contents
All manuals and user guides at all-guides.com TABLE OF CONTENTS TABLE OF CONTENTS ......................I-1 SAFETY INSTRUCTION RELATED TO SLM PROJECTORS ......... 1-1 Warnings ..............................1-1 Federal Communication Commission ......................1-1 Note ................................1-2 PACKAGING AND DIMENSIONS ..................2-1 Projector Packaging ............................ 2-1 Lens Packaging ............................ - Page 4 All manuals and user guides at all-guides.com Input Source Connection ..........................4-3 Optional: Serial Digital Input (slot 3 & 4) ...................... 4-7 HD SDI Digital Input (slot 3 & 4) ........................4-8 Communication Connections ........................4-9 RS232 Connections ............................ 4-9 Communication port for communication with peripherals.
- Page 5 All manuals and user guides at all-guides.com RANDOM ACCESS ADJUSTMENT MODE ..............7-1 Random Access Mode ..........................7-1 Picture Service ............................7-2 Load File ..............................7-3 Edit File ..............................7-4 Rename a file .............................. 7-6 Copy a file ..............................7-7 Delete .................................
- Page 6 All manuals and user guides at all-guides.com Shift ................................7-14 Size ................................7-14 Blanking ..............................7-15 Aspect Ratio .............................. 7-16 INSTALLATION MODE ...................... 8-1 Installation Mode ............................8-1 Input Slots ..............................8-1 800 Peripheral ............................. 8-2 Convergence ............................... 8-3 Configuration ............................... 8-4 OSD color (On-Screen Display) ........................
- Page 7 All manuals and user guides at all-guides.com Change Language ............................9-5 Change Projector Address ........................... 9-5 Serial Communication ..........................9-5 Lamp ................................9-7 BARCO logo ............................... 9-7 Add-Ins ............................... 9-8 Preset Input Balance ........................... 9-9 Diagnosis..............................9-9 I2C Diagnosis ............................. 9-10 Formatter ..............................
- Page 8 All manuals and user guides at all-guides.com...
-
Page 9: Safety Instruction Related To Slm Projectors
To prevent personel injury The customer should never attempt to disassemble the lamp casing or to dispose of the lamp casing other than by returning it to BARCO. To prevent injuries and physical damage, always read this manual and all labels on the system before connecting to the wall outlet, or adjusting the projector. -
Page 10: Note
Extra safety manual Read also safety instructions in seperate manual (R5976125). R5976262 BARCO SLM G5 Executive 13072001... -
Page 11: Packaging And Dimensions
Contents of the complete unit (box) : - 1 BARCO SLM G5 (weight ± 56 kg, 123.5 lbs) - 1 remote control unit RCU + 1 battery - 1 power cable. -
Page 12: Lens Packaging
&($" DS…rprv‰r… DS…rprv‰r… 6qwˆ†‡hiy rÃsrr‡ 6qwˆ†‡hiy rÃsrr‡ 6D SÃD I 6D SÃD I $##$ $##$ '&$ '&$ 7PUU PHÃWD@X G‚phyÃxr’ ƒh q É Hhv†Ãƒ‚r…Ã É 9v†ƒyh’à Dƒˆ‡† Q‚r…ÃTv‡p uà "( Q‚v‡Ã‚sÃt…h‰v‡’ "$"# 6DSÃPVU $##$ R5976262 BARCO SLM G5 Executive 13072001... -
Page 13: Installation Guidelines
All manuals and user guides at all-guides.com Installation Guidelines INSTALLATION GUIDELINES Installation Guidelines Ambient Temperature Conditions Humidity Conditions Environment Environment condition check clean air well Special care for Laser beams Which screen type? -
Page 14: Projector Configurations
All manuals and user guides at all-guides.com Installation Guidelines For more information about screens, contact your local screen supplier. What image size? How big should the image be? Projector Configurations Which configuration can be used. )URQW&HLOLQJ 5HDU&HLOLQJ 5HDU7DEOH )URQW7DEOH Image 1 Positioning the Projector Definitions of the Abbreviation on drawings... - Page 15 All manuals and user guides at all-guides.com Installation Guidelines U hi yr Æ ‡h q vt T D9 @ÃWD@X T p …r r Q…‚ wrp‡‚… P ƒ ‡vphyÃh‘v†Ãƒ …‚wrp‡v‚ Ãyr† Ay‚‚… 89Ã2ÃTC!ÃÃ7ÃÃ6 " ( Q ‚ v ‡Ã‚ sÃt … h ‰ v‡ ’ "...
- Page 16 All manuals and user guides at all-guides.com Installation Guidelines Safety Area around the Projector à P ’ v ‡ ‰ … s à ‚ ‡ à v ‚ Safety area for blow out hot air Image 6 Re-adjusting the lamp position in the lamp casing Image 7...
-
Page 17: Lenses
All manuals and user guides at all-guides.com Installation Guidelines Lenses Which Lens has to be selected. Available lenses Lens formulas to calculate the projector distance... - Page 18 All manuals and user guides at all-guides.com Installation Guidelines Installing the Projection Lens Attention avoid sliding off from the table Image 8 Image 9 Image 10...
-
Page 19: Battery Installation In The Rcu
All manuals and user guides at all-guides.com Installation Guidelines Cleaning the lens Battery installation in the RCU. How is the battery delivered ? How to install ? D ' 5 : Image 15... -
Page 20: Connections
The projector mode indication lamp will be green. (;,7 ( 17(5 67%< 3$86( 7( ;7 )5((= +( /3 3+$6( " 6+$531 (66 7,17 &2/25 67$1'%< (;,7 %5,* +71(66 (17(5 &2175$67 7(;7 3$86( 6+$531 7,17 %5,*+71 3+$6( &2/25 &2175$67 D R5976262 BARCO SLM G5 Executive 13072001... - Page 21 When OK (ENTER) is pressed to go on, the warning will be repeated every 30 min. The total lifetime of the lamp for a safe operation is 1500 hours max. Do not use it longer. Always replace with a same type of lamp. Call a BARCO authorized service technician for lamp replacement. Lamp Runtime Warning Using a lamp for more than 1500 hours is dangerous as the lamp could explode.
-
Page 22: Input Source Connection
When using a RCVDS05, it is recommended to use a 5-cable output module in the RCVDS. The outputs of this module has to be connected to slot 1 of the projector. To switch the projector in the 5-cable mode see chapter 'Installation mode'. R5976262 BARCO SLM G5 Executive 13072001... - Page 23 …r€ ‚‡r ST!"!#!!ÃPVU 8PHHÃQPSU USDB B@SÃP VU S T!"! #!! ÃDI 8USGà P VU DI à DI à P V U P T9DÃ9DB DU6G ÃDIQ VU C9ÃT9DÃ9DBDU6 GÃHP9VG@ CvtuÃ7hq vq‡uÃÃ$Ã867G@ÃDIQVU 9WDÃDIQVU CvtuÃ7hqvq‡uÃÃ$Ã867G@ÃDIQVU 9WDÃDIQVU 9WDÃPVUQVU R5976262 BARCO SLM G5 Executive 13072001...
- Page 24 Pin 24 TMDS Clock- How to select input Slot 1 or 2 : Key in 1 or 2 on the RCU or the local keypad. Selection of the signal format on the 'Input slot' menu. R5976262 BARCO SLM G5 Executive 13072001...
- Page 25 When using an RCVDS 05 with a 5 cable output module, connect these 5 cables to this fixed 5-input slot (slot1) of the projector. All sources of the RCVDS can now be accepted by the projector. R5976262 BARCO SLM G5 Executive 13072001...
-
Page 26: Optional: Serial Digital Input (Slot 3 & 4)
Key in the corresponding slot number on the RCU or the local keypad. Note : When a RCVDS05 is connected to the projector, the SDI input is available by keying in 83 or 84 on the RCU. R5976262 BARCO SLM G5 Executive 13072001... -
Page 27: Hd Sdi Digital Input (Slot 3 & 4)
Key in the corresponding slot number on the RCU or the local keypad. Note : When a RCVDS05 is connected to the projector, the HD-SDI input is available by keying in 83 or 84 on the RCU. R5976262 BARCO SLM G5 Executive 13072001... -
Page 28: Communication Connections
Connections Communication Connections Available communication connections : RS232/422 connection between projector and computer. Communication port for communication with BARCO peripherals. Trigger output RS232 Connections RS 232/422 input and RS232/422 output of the projector. The projector has a RS232/422 input port that allows it to communicate with a computer. - Page 29 All manuals and user guides at all-guides.com Connections 4-10 R5976262 BARCO SLM G5 Executive 13072001...
-
Page 30: Getting Started
All manuals and user guides at all-guides.com Getting Started GETTING STARTED Remote Control & Local Keypad Functionality (;,7 (17(5 67%< 3$86( 7(;7 )5((= +(/3 3+$6( " 6+$531(66 7,17 (;,7 67$1'%< &2/25 (17(5 %5,*+71(66 7(;7 3$86( &2175$67 7,17 6+$531 %5,*+71 3+$6( &2/25 &2175$67... - Page 31 All manuals and user guides at all-guides.com Getting Started Terminology Barco key : ADJ. STBY PAUSE Help : Digit buttons Picture controls PHASE 10 TEXT 11 FREEZ 12 ENTER 13 EXIT 14 Cursor Keys '+' and '-' keys '+' and '-' keys...
-
Page 32: Operating The Projector
All manuals and user guides at all-guides.com Getting Started Operating the Projector Switching on (;,7 ( 17(5 67%< 3$86( 7( ;7 )5((= +( /3 3+$6( " 6+$531 (66 7,17 &2/25 67$1'%< (;,7 %5,* +71(66 (17(5 &2175$67 7(;7 3$86( 6+$531 7,17 %5,*+71 3+$6( &2/25... -
Page 33: Quick Set Up Adjustments
All manuals and user guides at all-guides.com Getting Started Lamp Light Output Indication ENTER WARNING Lamp run time is 1400 hours. The light output of the lamp is less than 50% of its initial value. It is advisable to replace the lamp before damage occurs. - Page 34 All manuals and user guides at all-guides.com Getting Started Quick Lens Adjustment é ê ç è EXIT ENTER LENS ADJUSTMENT ZOOM/FOCUS ZOOM with éor ê FOCUS with çor è <ENTER> to Shift <EXIT> to return ENTER é ê ç è EXIT ENTER LENS ADJUSTMENT SHIFT...
-
Page 35: Using The Rcu
All manuals and user guides at all-guides.com Getting Started Quick On Screen Color change ENTER é ê ENTER é ê ENTER é ê ENTER ADJUSTMENT MODE INSTALLATION OSD COLOR HIGHLIGHTED ITEM Select a path from below : INPUT SLOTS 800 PERIPHERALS CONFIGURATION GREEN RANDOM ACCESS... - Page 36 All manuals and user guides at all-guides.com Getting Started Hardwired Remote Input 9vh t ‚†‡vp Ã8 ‚ qr D SSr p r v‰r… B… rr ÃPƒr …h‡ v ‚ Sr qà T‡h qi ’ U‚à h’ Ch …qv…r q u h…...
-
Page 37: Projector Address
All manuals and user guides at all-guides.com Getting Started Directly to the IR Sensors DSÆr†‚… DS Ær†‚… 7DEOH Tvq rÂsÃ…‚wrp‡‚ … S rh… sÃ…‚wrp‡‚… A …‚ ‡Ã‚ sÃ…‚ wrp ‡‚ … ƒ ƒ ƒ ƒ ƒ ƒ 6 9E @ Y D U ( 17 (5 6 99 S ) 5( (=... -
Page 38: Controling The Projector
All manuals and user guides at all-guides.com Getting Started Display the Projector Address on the Screen ADDRESS PROJECTOR ADDRESS How to Program an Address into the RCU ? ADDRESS Controling the Projector Input Selection Picture Contols Brightness Control 'brightness' Contrast Control Color Saturation Tint Control Sharpness Control. - Page 39 All manuals and user guides at all-guides.com Getting Started Phase Control The Pause key. The Stand-by key.
-
Page 40: Start Up Of The Adjustment Mode
Enter the digits with the numeric keys. Example : 2 3 1 9 The first digit position is highlighted. Enter with the numeric keys. The highlighted square jumps to the next position. Continue until all 4 digits are filled in. R5976262 BARCO SLM G5 Executive 13072001... - Page 41 The menus will be displayed line by line in the same order as they were displayed on the projection screen. Adjustments can be done while the projector is running without projecting the disturbing menus on the screen. Use the cursor keys to scroll through the menus and press ENTER to activate the displayed menu. R5976262 BARCO SLM G5 Executive 13072001...
-
Page 42: Random Access Adjustment Mode
All manuals and user guides at all-guides.com Random Access Adjustment Mode RANDOM ACCESS ADJUSTMENT MODE Random Access Mode Starting up ENTER ADJUSTMENT MODE Select a path from below : RANDOM ACCESS INSTALLATION SERVICE Source 01 Select with é or ê then <ENTER>... -
Page 43: Picture Service
All manuals and user guides at all-guides.com Random Access Adjustment Mode Picture Service Connecting a new Source. Start up the File Service. é ê ENTER EXIT ADJUST RANDOM ACCESS FILE SERVICE ADJUSTMENT MODE LOAD FILE SERVICE EDIT PICTURE TUNING RENAME GEOMETRY COPY DELETE... -
Page 44: Load File
All manuals and user guides at all-guides.com Random Access Adjustment Mode Load File Start up the Load File. é ê ENTER è ç ENTER FILE SERVICE LOAD FILE FILTER LIST [All] LOAD Filename Resolution EDIT ----------------------------------------------------- RENAME Video525.s01 1 675x240i COPY Video525.c01 1 675x240i... -
Page 45: Edit File
All manuals and user guides at all-guides.com Random Access Adjustment Mode Edit File What can be done with the Edit File menu ? How to start up the EDIT menu ? é ê ENTER ENTER FILE SERVICE EDIT FILE LOAD Filename Resolution EDIT... - Page 46 All manuals and user guides at all-guides.com Random Access Adjustment Mode How to find the correct values for the displayed item? Caution : Do not adjust these settings on an active file, they are used to identify the input source file. "Horizontal Total Pixels"...
-
Page 47: Rename A File
All manuals and user guides at all-guides.com Random Access Adjustment Mode Field Polarity ENTER Field Select ENTER Vertical Refresh [sync/async] EXIT CONFIRM EDIT FILE Save changes to file xga.c30? <ENTER> to confirm <EXIT> to return ENTER EXIT Rename a file Start Up. -
Page 48: Copy A File
All manuals and user guides at all-guides.com Random Access Adjustment Mode How to change the characters ? ç è é ê ENTER EXIT RENAME FILE Frome file name : Video525.s01 To file name : demo.c10 Select with ç or è Reprogram with é... -
Page 49: Delete
All manuals and user guides at all-guides.com Random Access Adjustment Mode Delete Start Up é ê ENTER é ê ENTER ENTER EXIT FILE SERVICE DELETE FILE CONFIRM DELETE FILE LOAD Filename Resolution EDIT ----------------------------------------------------- Delete file: RENAME Video525.s01 1 675x240i Video525.c01? COPY Video525.c01 1... -
Page 50: Picture Tuning
All manuals and user guides at all-guides.com Random Access Adjustment Mode Picture Tuning Start Up é ê ENTER PICTURE TUNING RANDOM ACCESS ADJUSTMENT MODE CTI [ON] COLOR TEMPERATURE FILE SERVICE GAMMA PICTURE TUNING DECODING [EBU] GEOMETRY DYNAMIC COLOR DEPTH NOISE REDUCTION INPUT BALANCE Select with é... -
Page 51: Color Temperature
All manuals and user guides at all-guides.com Random Access Adjustment Mode Color Temperature Start Up é ê ENTER PICTURE TUNING COLOR TEMPERATURE CTI [ON] PROJECTOR WHITE COLOR TEMPARATURE COMPUTER 9300K GAMMA VIDEO 6500K DECODING [EBU] FILM 5400K DYNAMIC COLOR DEPTH BROADCAST 3200K NOISE REDUCTION... -
Page 52: Decoding Ebu/Ire
All manuals and user guides at all-guides.com Random Access Adjustment Mode How to change the Gamma Value ? é ê ENTER ç è EXIT PICTURE TUNING GAMMA = 2.2 CTI [ON] COLOR TEMPERATURE GAMMA menu 3 DECODING [EBU] DYNAMIC COLOR DEPTH NOISE REDUCTION INPUT BALANCE Select with é... -
Page 53: Noise Reduction
All manuals and user guides at all-guides.com Random Access Adjustment Mode Noise Reduction Purpose : To change the noise reduction value : é ê ENTER ç è EXIT PICTURE TUNING NOISE REDUCTION CTI [ON] COLOR TEMPERATURE GAMMA menu 2 DECODING [EBU] DYNAMIC COLOR DEPTH NOISE REDUCTION INPUT BALANCE... -
Page 54: Geometry
All manuals and user guides at all-guides.com Random Access Adjustment Mode How to adjust the input balance for YUV input signals? Important é ê é ê ENTER é ê ç è PICTURE TUNING INPUT BALANCE INPUT BALANCE CTI [ON] WHITE BALANCE WHITE BALANCE COLOR TEMPERATURE BLACK BALANCE... -
Page 55: Shift
All manuals and user guides at all-guides.com Random Access Adjustment Mode Shift What can be done ? To start up the shift action : é ê ENTER é ê ç è GEOMETRY SHIFT SIZE BLANKING ASPECT RATIO [4:3] Select with é or ê then <ENTER>... -
Page 56: Blanking
All manuals and user guides at all-guides.com Random Access Adjustment Mode Blanking What can be done ? Available Blanking Adjustment. U‚ƒÃiyhxvt Svtu‡Ãiyhxvt Grs‡Ãiyhxvt 7‚‡‡‚€Ãiyhxvt Adjusting the blanking. é ê ENTER é ê ENTER BLANKING GEOMETRY SHIFT BOTTOM SIZE LEFT BLANKING RIGHT ASPEC RATIO [4:3] Select with é... -
Page 57: Aspect Ratio
All manuals and user guides at all-guides.com Random Access Adjustment Mode Aspect Ratio What can be done? Setting Up the Aspect Ratio. é ê ENTER GEOMETRY SHIFT SIZE BLANKING ASPEC RATIO [4:3] Select with é or ê then <ENTER> <EXIT> to return. menu 1... -
Page 58: Installation Mode
Video S-Video RGB analog RGB-SS[CV] : separate sync is composite video signal on H/C input RGB-SS[CS or HS&VS] : separate sync is composite sync or horizontal and vertical sync RGB-SOG : sync on green R5976262 BARCO SLM G5 Executive 13072001... -
Page 59: 800 Peripheral
NO SIGNAL LENS Select with é or ê QUICK ACCESS KEYS <ENTER> to toggle MENU POSITION [DEFAULT] <EXIT> to return. Select with é or ê then <ENTER> menu 2 <EXIT> to return. menu 1 R5976262 BARCO SLM G5 Executive 13072001... -
Page 60: Convergence
NO SIGNAL qualified LENS service personnel QUICK ACCESS KEYS <ENTER> to accept MENU POSITION [DEFAULT] <EXIT> to return. Select with é or ê then <ENTER> menu 2 <EXIT> to return. menu 1 R5976262 BARCO SLM G5 Executive 13072001... -
Page 61: Configuration
INTERNAL PATTERNS NO SIGNAL LENS Select with é or ê QUICK ACCESS KEYS then <ENTER> MENU POSITION [DEFAULT] <EXIT> to return. Select with é or ê then <ENTER> menu 2 <EXIT> to return. menu 1 R5976262 BARCO SLM G5 Executive 13072001... -
Page 62: No Signal
SHUTDOWN [Off] CONVERGENCE Shutdown time : CONFIGURATION OSD COLOR INTERNAL PATTERNS NO SIGNAL LENS QUICK ACCESS KEYS MENU POSITION [DEFAULT] Select with é or ê then <ENTER> menu 2 <EXIT> to return. menu 1 R5976262 BARCO SLM G5 Executive 13072001... -
Page 63: Internal Patterns
INTERNAL PATTERNS NO SIGNAL LENS Select with é or ê QUICK ACCESS KEYS then <ENTER> MENU POSITION [DEFAULT] <EXIT> to return. Select with é or ê then <ENTER> menu 2 <EXIT> to return. menu 1 R5976262 BARCO SLM G5 Executive 13072001... - Page 64 ZOOM with éor ê SHIFT with éor ê, çor è <EXIT> to return. FOCUS with çor è <ENTER> to Zoom/Focus <ENTER> to Shift <EXIT> to return <EXIT> to return menu 2 menu 1 menu 3 R5976262 BARCO SLM G5 Executive 13072001...
-
Page 65: Quick Access Keys
NO SIGNAL LENS CLEAR ALL QUICK ACCESS KEYS MENU POSITION [DEFAULT] Select with é or ê Select with é or ê then <ENTER> then <ENTER> <EXIT> to return. <EXIT> to return. menu 2 menu 1 R5976262 BARCO SLM G5 Executive 13072001... -
Page 66: Menu Position
[CENTER] : menus and adjustment boxes displayed in the center of the image. INSTALLATION INPUT SLOTS 800 PERIPHERAL CONVERGENCE CONFIGURATION OSD COLOR INTERNAL PATTERNS NO SIGNAL LENS QUICK ACCESS KEYS MENU POSITION [DEFAULT] Select with é or ê then <ENTER> <EXIT> to return. menu 1 R5976262 BARCO SLM G5 Executive 13072001... - Page 67 All manuals and user guides at all-guides.com Installation Mode 8-10 R5976262 BARCO SLM G5 Executive 13072001...
-
Page 68: Service Mode
Select with é or ê <ENTER> to confirm then <ENTER> Select with é or ê <EXIT> to return <EXIT> to return. Select with é or ê then <ENTER> <ENTER> to toggle <EXIT> to return. <EXIT> to return. R5976262 BARCO SLM G5 Executive 13072001... -
Page 69: Identification
- projector serial number - projector run time Detailed description - type of projector : BARCO SLM R6 - software version - Proj. Address : to change the address of the projector, see Change Projector Address in this chapter. - Installation : possible installations :... -
Page 70: Change Password
Depending on your password level some password protected items are accessible and others not. The owner (which has the highest level) can set up via the 'Access control list' the accessibility of the different items. See 'Access Control List'. R5976262 BARCO SLM G5 Executive 13072001... - Page 71 1 menu 3 An access level can be added to the following items : Adjustment mode Barco logo Change projector address File delete File delete all Input balance Installation Random access Serial communication Service R5976262 BARCO SLM G5 Executive 13072001...
-
Page 72: Change Language
CHANGE PROJ. ADDRESS RS422 TERMINATION [ON] SERIAL COMMUNICATION LAMP MORE... Select with é or ê Select with é or ê then <ENTER> then <ENTER> <EXIT> to return. <EXIT> to return. menu 2 menu 1 R5976262 BARCO SLM G5 Executive 13072001... - Page 73 Press ENTER to toggle between ON and OFF. Default setting : ON SERIAL COMMUNICATION PROJECTOR ADDRESS 001 BAUDRATE [115200] INTERFACE STANDARD [RS232] RS422 TERMINATION [ON] Select with é or ê then <ENTER> <EXIT> to return. menu 1 R5976262 BARCO SLM G5 Executive 13072001...
-
Page 74: Lamp
Push the cursor key é or ê to highlight 'BARCO logo' (menu 1). Press ENTER to select. The BARCO logo menu will be displayed on the screen (menu 2. Within this menu, three toggle settings and a shift control are available. -
Page 75: Add-Ins
OFF : no key on the RCU is used to display the BARCO logo. TEXT : the TEXT key on the RCU is used to display or to remove the BARCO logo with one single push on this key (only in operational : mode). -
Page 76: Preset Input Balance
DIAGNOSIS BARCO LOGO ADD-INS FORMATTER PRESET INPUT BALANCE DIAGNOSIS MORE... Select with é or ê Select with é or ê then <ENTER> then <ENTER> <EXIT> to return. <EXIT> to return. menu 1 menu 2 R5976262 BARCO SLM G5 Executive 13072001... -
Page 77: I2C Diagnosis
An overview of the working of the formatter will be displayed (menu 2). DIAGNOSIS FORMATTER I2C (34H) CONFIGURATION FORMATTER INITIALISATION SELF TEST RED DISPLAY GREEN DISPLAY BLUE DISPLAY Select with é or ê <EXIT> to return. then <ENTER> <EXIT> to return. menu 2 menu 1 9-10 R5976262 BARCO SLM G5 Executive 13072001... -
Page 78: Programmable Function Keys
3. Press ENTER to confirm. 4. The function key is available in the operational mode. CONFIRM QUICK ACCESS <F1> will be used to quickly access this menu. <ENTER> to confirm <EXIT> to cancel. menu 1 10-1 R5976262 BARCO SLM G5 Executive 13072001... - Page 79 All manuals and user guides at all-guides.com Programmable Function Keys 10-2 R5976262 BARCO SLM G5 Executive 13072001...
- Page 80 MAC_5 512 X 342 60,158 22,259 15,670 704 MAC_6 832 X 624 74,546 49,722 57,280 1152 832 MAC_7 1024 X 768 74,907 60,150 80,000 1330 1024 MAC_LC 640 X 480 66,619 34,975 31,338 896 R5976262 BARCO SLM G5 Executive 13072001...
-
Page 81: Standard Source Set Up Files
1024 X 768 71,955 58,140 80,000 1376 1024 S1600_67 1600 X 1280 66,931 89,286 200,000 2240 1600 1334 1200 SDI_625 675 X 2781 25,000 15,625 13,500 864 SDI_525 675 X 2401 29,970 15,734 13,500 858 R5976262 BARCO SLM G5 Executive 13072001... -
Page 82: Index
All manuals and user guides at all-guides.com Index INDEX Symbols 5976229 BARCOSLM G5 14032001... - Page 83 All manuals and user guides at all-guides.com Index See also 5976229 BARCOSLM G5 14032001...
