FRONT AND REAR PANEL DESCRIPTIONS
10. RS-232 Output
The output of this jack must be connected to the PC Control input of the VX-3c
Projector. This communication will allow the controller and projector to be
turned on simultaneously by turning on just the VHD Controller.
11. Power Input
Plug in main power here.
12. 115 VAC Fuse
This is the main AC input fuse.
(Main Fuse: 5mm x 20 mm, 500mA, 250v, Slow Blow)
13. Main Power Switch
Disconnects or applies main power to the processor.
6-7
