A-2
Installing HDD:
with the drive to the HDD connector, and the other end to IDE1 pin connector
on the mainboard.
Note: Be sure that the red line on the cable connects to the first pin of the
connectors.
Installing CD-ROM Drive:
cable that comes with the drive to the CD-ROM connector, and the other end to
the IDE2 pin connector on the mainboard.
Note: Be sure that the red line on the cable connects to the first pin of the
connectors.
Installing parallel port:
with the hardware to the LPT connector on the mainboard.
Installing serial port:
with the hardware to connector COM1 on the mainboard.
COM2- Connect the other 10-pin cable to connector COM2 on the mainboard.
Attach the bracket of Parallel Port, Serial Port and PS2 Mouse on the
computer case.
Installing Keylock connector:
PN1 - There is a specific orientation for pin 1 to pin 5. Insert the five-threads
keylock cable into correct pins of connector on the mainboard.
Pin number
1
2
3
4
5
IDE1- Connect one end of the 40-pin cable that comes
IDE2- Connect one end of the 40-pin
LPT- Connect the 26-pin cable that comes
COM1- Connect the 10-pin cable that comes
Name of the signal or signification
+5VDC
No connection
Ground
Keyboard inhibit Signal
Ground
Watch the pin position and the
orientation
Appendix A
