- Page 1 STAINLESS STEEL GAS GRILL MODEL NO.: 720-0063-LP Jenn-Air is a Trademark of the Maytag Corporation and is used under license to Lowe’s Companies, Incorporated. FOR OUTDOOR USE ONLY PLEASE CONTACT 1-800-554-5799 FOR ASSISTANCE DO NOT RETURN TO PLACE OF PURCHASE...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION ONE SECTION FIVE Safety Instructions…………………………. Exploded View……………………….….. Placement of the grill……………………….. Parts List ………………………………… SECTION TWO SECTION SIX Side Shelf Assembly……………………….. Grilling Hints …………………………….. Side Shelf Handle & Grease Tray Handle Grill Cooking Chart ……………………… 21-23 Assembly……………………………………. - Page 3 PRECAUTIONS SAFETY INSTRUCTIONS RECOGNIZED SAFETY SYMBOLS, WORDS AND LABELS WARNING WARNING Do not try lighting this appliance without first reading the “LIGHTING INSTRUCTIONS” section of this manual. WARNING – Hazards or unsafe practices which COULD result in severe personal injuray or death. DO NOT USE ALUMINUM FOIL TO LINE THE GRILL RACKS OR GRILL BOTTOM.
- Page 4 PRECAUTIONS SAFETY INSTRUCTIONS WARNING: IMPORTANT! USING THE SIDE BURNER: Inspect the gas supply hose prior to turning the gas “ON”. If there is evidence of cuts, wear or abrasion, it must be replaced prior to use. Do not use the side burner if the odor of gas is present.
-
Page 5: Safety Instructions
SAFETY INSTRUCTIONS WARNING *** FOR YOUR SAFTY If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Open lid 4. If odor continues, immediately call your gas supplier or your fire department. FOR YOUR SAFETY 1. - Page 6 SIDE SHELF ASSEMBLY INSTALLATION OF SIDE SHELF • The screws used to attach the side shelf are already screwed into the right side panel (see the figure below). Remove the screws from the right side panel, align with the holes in the side shelf, and then re-screw into the holes on the right side panel of the grill.
-
Page 7: Placement Of The Grill
THE GRILL. them periodically for optimum performance. The burners will only operate in one position and must The 720-0063-LP Grill is designed for optimum be mounted correctly for safe operation. performance without the use of briquettes. Do not place briquettes on the radiant as this will block off Clean the grill with caution. -
Page 8: Side Shelf Assembly
SIDE SHELF ASSEMBLY INSTALLATION OF SIDE SHELF • The screws used to attach the side shelf are already screwed into the two-side panel (see the figure below). Remove the screws from the two-side panel, align with the holes in the side shelf, and then re-screw into the holes on the side panels of the grill. -
Page 9: Side Shelf Handle & Grease Tray Handle Assembly
SIDE SHELF HANDLE & GREASE TRAY HANDLE ASSEMBLY • The two screws used to attach the grease tray handle are already attached to the grease tray handle, remove the two screws from grease tray handle, align with the holes in grease tray, and then re-screw into the holes on the grease tray handle. (see the figure below) •... -
Page 10: Battery & Spice Tray, Individual Shelf Assembly
BATTERY & SPICE TRAY, INDIVIDUAL SHELF ASSEMBLY • In order to install the battery, remove the ignition button housing. Please keep the positive pole of the battery facing toward you. Insert the battery into the housing. Replace the ignition button housing after battery is installed. •... -
Page 11: Propane Tank Assembly
PROPANE TANK ASSEMBLY ● Attach propane gas tank to regulator inlet fitting by turning the regulator clockwise as shown in figure below. -
Page 12: Gas Hook Up
CONNECTION: Total gas consumption (per hour) of 720-0063-LP Your grill is equipped with gas supply orifices for grill with all burners on “HI”: use only with liquid propane gas. It is also equipped... -
Page 13: Leak Testing
LEAK TESTING GENERAL the burners. The flames of the burners should be Although all gas connections on the grill are leak visually checked. tested at the factory prior to shipment, a complete gas tightness check must be performed at the installation site due to possible mishandling in shipment, or excessive pressure unknowingly being applied to the unit. -
Page 14: Installer Final Check
INSTALLER FINAL CHECK Specified clearance maintained 24” from Unit tested and free of leaks. combustibles. User informed of gas supply shut off valve All internal packaging removed. location. Knobs turn freely. Burners are tight and sitting properly on orifices. PLEASE RETAIN THESE INSTRUCTIONS FOR Pressure regulator connected and set for 11.2”... -
Page 15: Operating Instruction
OPERATING INSTRUCTION General use of the grill and rotisserie Each main burner is rated at 12,000 BTU/hr. The the stainless steel motor mount. The rotisserie main grill burners encompass the entire cooking motor must be electrically grounded in accordance area and are side ported to minimize blockage from with local codes or, in the absence of local codes, falling grease and debris. -
Page 16: Lighting Instructions
LIGHTING INSTRUCTIONS Burner flames should be blue and stable with no WARNING: IMPORTANT! yellow tips, excessive noise, or lifting. If any of these conditions exist call our customer service line. BEFORE LIGHTING… If the flame is yellow, it indicates insufficient air. If Inspect the gas supply hose prior to turning the gas the flame is noisy and tends to lift away from the “ON”. -
Page 17: To Match Light The Grill
TO MATCH LIGHT THE GRILL TO MATCH LIGHT THE GRILL: If the burner will not light after several attempts then the burner can be match lit. If you have already attempted to light the burner with the igniter, allow 5 minutes for any accumulated gas to dissipate. -
Page 18: Lighting Illustration
LIGHTING ILLUSTRATION Main & Side Burner Lighting Illustration Rotisserie Burner Lighting Illustration 1. Make sure the lid is in open position. 1. Push and turn the rotisserie knob to HI. 2. Push and turn one of main or side burner knob 2. -
Page 19: Using The Side Burner
USING THE SIDE BURNER control knob counterclockwise to the “HI” position. If the burner does not light, turn the control knob to WARNING: IMPORTANT! “OFF”. If the smell of gas is detected and the igniter USING THE SIDE BURNER: is not functioning, immediately turn the control knob Inspect the gas supply hose prior to turning the gas “OFF”. -
Page 20: Care And Maintenance Of Side Burner
CARE & MAINTENANCE OF SIDE BURNER SIDE BURNER CLEANING: Clean the exterior of the burner with a wire brush. Clear any clogged burner ports with a straightened paper clip. Never enlarge the burner ports. Never use a wooden toothpick as it may break off and clog the port. STAINLESS STEEL: There are many different stainless steel cleaners available. -
Page 23: Grilling Hints
GRILLING HINTS The doneness of meat, whether rare, medium, or Use a spatula instead of tongs or a fork to turn the well done, is affected to a large degree by the meat, as a spatula will not puncture the meat and thickness of the cut. - Page 24 FOOD WEIGHT FLAME APPROXIMATE SPECIAL OR THICKNESS SIZE TIME INSTRUCTIONS AND TIPS MEATS BEEF Hamburgers 1/2 to 3/4 inch Medium 10 to 18 minutes Grill, turning once when juices rise to the surface. Do not leave hamburgers unattended since a flare-up could occur quickly.
- Page 25 FOOD WEIGHT FLAME APPROXIMATE SPECIAL OR THICKNESS SIZE TIME INSTRUCTIONS AND TIPS Breasts Medium 30 to 45 minutes Marinate with Italian dressing well-done FISH AND Grill, turning once. Brush with SEAFOOD melted butter, margarine or oil to keep moist. Steaks Halibut 3/4 to 1 inch Medium to...
-
Page 26: Grill Recipe Suggestions
GRILL RECIPE SUGGESTIONS In medium bowl, combine shrimp and aluminum foil. Bake covered 25 SALMON scallops. In small bowl combine chili minutes on medium with the lid of sauce and next six ingredients. Pour your BBQ grill closed. Remove foil 2 large salmon steaks over seafood. - Page 27 ½ tsp. pepper Heat through. If sauce gets too thick, Marinade ribs for 3 hours. Use ¼ tsp. oregano add 1 tbs. water. Serve sauce with marinade for basting by adding beer ¼ tsp. cumin kabobs. to it. Place pan under the ribs and Flour tortillas baste frequently.
-
Page 28: Limited Warranty
LIMITED WARRANTY MODEL 720-0063-LP STAINLESS STEEL OUTDOOR GAS GRILL Nexgrill Industries, Inc. warrants to the original consumer purchaser of each Jenn-Air Outdoor Gas Grill that when subject to normal residential use, it is free from defects in workmanship and materials for the periods specified below.
