CONTROL COMMAND
• Command table (continued)
Command Sub command
1A 0577
06
07
08
1B 00
01
02
1C 00
01
D D To send/read memory contents
When sending or reading memory contents, additional code
as follows must be added to appoint the memory channel.
➥ Additional code: 0000–0102
D D Band stacking register
To send or read the desired band stacking register's con-
tents, combined code of the frequency band and register
codes as follows are used.
For example, when sending/reading the oldest contents in
the 21 MHz band, the code "0703" is used.
• Frequency band code
Code Frequency band Frequency range (unit: MHz)
01 1.8
02 3.5
03 7
04 10
05 14
06 18
07 21
08 24
09 28
10 50
11 144
12 GENE
• Register code
Code
01
02
03
97
Description
Send/read MONITOR level (0=0%
to 255=100%)
Send/read DATA mode (0=OFF,
1=ON)
Send/read SSB transmit band-
width (0=WIDE, 1=MID, 2=NAR)
Send/read DSP filter shape
(0= sharp, 1= soft)
Set/read repeater tone frequency
(see p. 98 for details)
Set/read TSQL tone frequency
(see p. 98 for details)
Set/read DTCS code and polarity
(see p. 98 for details)
Set/read the transceiver's condi-
tion (0=Rx; 1=Tx)
Set/read antenna tuner condition
(0=OFF, 1=ON, 2=Start tuning or
while tuning)
(0100=P1, 0101=P2, 0102=Call)
1.800000– 1.999999
3.400000– 4.099999
6.900000– 7.499999
9.900000–10.499999
13.900000–14.499999
17.900000–18.499999
20.900000–21.499999
24.400000–25.099999
28.000000–29.999999
50.000000–54.000000
144.000000–148.000000
Other than above
Registered number
1 (latest)
2
3 (oldest)
D D Codes for memory keyer contents
To send or read the desired memory keyer contents, the
channel and character codes as follows are used.
• Channel code
Code Channel number
01
02
03
04
• Character's code
Character ASCII code
0–9 30–39 Numerals
A–Z 41–5A Alphabetical characters
space 20 Word space
/ 2F Symbol
? 3F Symbol
, 2C Symbol
. 2E Symbol
^ 5E e.g., to send
✱
2A Inserts contact number (can be
used for 1 channel only)
D D Codes for memory name contents
To send or read the desired memory name settings, the char-
acter codes, instructed codes for memory keyer contents as
above, and follows are additionally used.
• Character's code— Alphabetical characters
Character ASCII code
a–z 61–7A
• Character's code— Symbols
Character ASCII code
! 21
$ 24
& 26
? 3F
' 27
+ 2B
: 3A
= 3D
> 3E
) 29
] 5D
} 7D
_ 5F
M1
M2
M3
M4
Description
, enter ^4254
BT
Character ASCII code
— —
Character ASCII code
# 23
% 25
¥ 5C
" 22
` 60
– 2D
; 3B
< 3C
( 28
[ 5B
{ 7B
| 7C
–
7E
