- Page 1 INSTALLATION, OPERATION & MAINTENANCE MANUAL DVC/DVH 09/12/18/24 Inverter Single Zone Ductless Mini-Split Heat Controller • 1900 Wellworth Ave. • Jackson, MI 49203 • (517)787-2100 • www.heatcontroller.com...
-
Page 2: Table Of Contents
DVC/DVH Inverter Mini-Split Heat Controller TABLE OF CONTENTS Safety Precautions Warnings and Cautions ....................... 3 Installation Instructions Installation Location Selection ..................4-5 Accessories ......................... 6 Indoor unit installation ....................... 7-8 Outdoor unit installation ....................... 9 Refrigerant Pipe Connection Refrigerant line set installation ..................10 Leak test, evaluation and release of refrigerant .............. -
Page 3: Safety Precautions Warnings And Cautions
Heat Controller DVC/DVH Inverter Mini-Split • Read the follow SAFETY PRECAUTIONS carefully before installation. • Electrical work must be performed by a licensed electrician. Be sure to use the correct rating of the power cord and main circuit for the model to be installed. -
Page 4: Installation Instructions Installation Location Selection
DVC/DVH Inverter Mini-Split Heat Controller Selecting installation place Choose a location that places the outdoor unit as close to the indoor unit as possible. The maximum unit separation and vertical lift (compressor above the evaporator) must be taking into account. Do not exceed allowable refrigerant line lengths. -
Page 5: Rooftop Installation
Heat Controller DVC/DVH Inverter Mini-Split • Avoid areas where water, snow, or ice may fall from the roof onto the unit. • In climates where snow is a consideration, locate the unit away from areas prone to drifting. • Ensure the location of the unit will not be subject to snow drifts, heavy accumulation of snow or leaves or other seasonal debris. If unavailable, provide an awning for the unit. -
Page 6: Accessories
DVC/DVH Inverter Mini-Split Heat Controller Accessories Number Name of Accessories Qty/unit Wall Bracket Plastic Dry Wall Anchor 5-8 depending on model Self-tapping Screw A ST 3.9X25 5-8 depending on model Seal (heat pump models only) 1 (Part 202720090001) Drain Elbow (heat pump models only) -
Page 7: Indoor Unit Installation
Heat Controller DVC/DVH Inverter Mini-Split Wall Bracket should be Indoor unit installation flush with the interior wall 1. Wall Bracket Mounting A. There are two tabs on the back of the Fig. 9 indoor unit that hold the wall bracket onto the unit. - Page 8 DVC/DVH Inverter Mini-Split Heat Controller 4. Refrigerant Line Installation A. Remove the knockout from the desired side of the unit that the line set will be routed from. The lines from the unit can be routed either left or right, left back or right back (Fig. 14).
-
Page 9: Outdoor Unit Installation
