- Page 1 OWNER’S MANUAL Room Air Heat Pump with R-410A: RAH-123G Heat Controller, Inc. • 1900 Wellworth Ave. • Jackson, MI 49203 • (517)787-2100 • www.heatcontroller.com...
-
Page 2: Table Of Contents
Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc. Room Air Conditioner & Heat Pump Use and Care Manual Contents Introduction ..............1 Introduction ............. 1 Safety Information ............1 Safety Information ..........1 Normal Care & Maintenance ........3 Normal Care &... - Page 3 Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual OWNER'S PRODUCT IDENTIFICATION WARNING To prevent heat related illness or death, do MOdEL NUMBER To prevent heat related illness or death, not use this device for unattended cooling do not use this device unattended.
-
Page 4: Normal Care And Maintenance
Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc. page included with this manual or in the mounting kit Unit Plug Receptacle Circuit Rating, Voltage assembly. Follow these instructions carefully. Keep these Type Required Breaker, Time Rating On instructions with this manual for future reference. - Page 5 Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual Note: The life of your unit may be greatly reduced if you live Air Filter Cleaning Note: The life of your unit may be greatly reduced if you live in a salt air or other corrosive type environment.
-
Page 6: Installation Requirements
Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc. IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, electrical shock or injury when using your air conditioner, follow these basic precautions: Plug into a grounded 3 prong outlet. -
Page 7: Electrical Requirements
Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual Electrical Requirements Window installation Window opening measurements: WARNING 27" min. to 39" max. opening width. 16¹⁄₄" min. opening height. Electrical Shock Hazard Plug into a grounded 3 prong outlet. - Page 8 Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc. WARNING Recommended grounding method This air conditioner must be grounded. This air conditioner is equipped with a power supply cord having a grounded 3 prong plug. To minimize possible shock hazard, the cord must be plugged into a mating, grounded 3 prong outlet, grounded in accordance with all local codes and ordinances.
-
Page 9: Installation Instructions
Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual INSTALLATION INSTRUCTIONS Unpacking 3. Remove front panel by removed 2 phillips screws on both WARNING bottom left right sides of front. 3A: Remove both knobs from control panel. Excessive Weight Hazard Excessive Weight Hazard 4. - Page 10 Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc. Attach Side Curtains Attach foam adhesive seal 1. Locate provided bag of screws. Attach foam adhesive seal along the bottom of the curtain bottom channel. 2. Insert top and then bottom of right-hand curtain housing in top and bottom curtain guides on air conditioner cabinet.
-
Page 11: Through-The -Wall Cabinet Instructions
Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual 4. Use a ³⁄₁₆" drill bit to drill 3 starter holes 1/2" deep through the 2. Insert one of the #10 x ³⁄₄" round-head screws through 3 holes in the cabinet and into the windowsill. -
