SpeedDome
Day/Night Camera
Dome Configuration
Utility
Operator's Manual Supplement
Contents
About this Supplement .......................................... 1
DirectSet Menu...................................................... 2
Menu Programming Navigation............................. 3
Programming Motion Detection............................. 4
Programming Sequences...................................... 7
Controllers and Switchers .............................. 10
Specifications-Indoor Dome ................................ 12
Declarations ........................................................ 15
© 2004 Sensormatic Electronics Corp.
SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY
OPERATOR'S MANUAL SUPPLEMENT
Ultra VIIE
®

About this Supplement

This supplement provides detailed information
about SpeedDome Ultra VIIE camera dome
features that are not currently covered in your
operator's manual. This supplement supports
information found in the following manuals:
•
Day/Night Camera Dome Configuration Utility
Operator's Manual, 8200-0184-04
NOTE:
Keep this supplement with your operator's
manual for reference purposes.
If you need assistance...
Contact your Sales Representative.
New SpeedDome Ultra VIIE
Features
SpeedDome Ultra VIIE provides the following
features with firmware version 0710-0532-0100
and newer.
• DirectSet Menu for accessing commonly used
dome settings.
• AD Up-the-Coax protocol (UTC) for compatible
American Dynamics controllers.
• Motion Detection (available only on domes with
the following part numbers: 0101-0120-01, 0101-
0120-02, 0101-0120-03, 0101-0120-04, 0101-
0120-05, 0101-0120-06).
• 16 Sequences.
• Up to 16 Patterns.
• Ability to change camera functions for each
Preset.
Updated information is also provided for the
following:
• SensorNet, RS-422, Manchester, and UTC
matrix switchers and controllers.
1 of 15
8200-0184-12, REV. A
