Page 8
Example: The mic-off switch is set to 20s position...
Page 9
Example: The speaker restriction switch is set to the "2" position. The chairman unit can be used at any time regardless of the limitation of the number of usable delegate units.
Page 11
Note that the system does not operate if the cords are connected in reverse orientation. Space the conference units 1.5-2 m apart.
Page 13
Place the expansion amplifier's switch in the [1] position. the same position as the center amplifier. Place the expansion amplifier's chime volume control in the [0] position.
