Page 1 2013 fordowner.com ford.ca DC3J 19A321 AA September 2012 First Printing Owner’s Manual Super Duty Litho in U.S.A.
Page 2: Table Of Contents
Table of Contents Introduction Child Safety Child seats ......... . .20 Child seat positioning .
Page 3 Table of Contents Locks Locking and unlocking ........70 SecuriCode™...
Page 4: Table Of Contents
Table of Contents Instrument Cluster Gauges ..........95 Warning lamps and indicators .
Page 5 Table of Contents Auxiliary Power Points Storage Compartments Overhead console ........181 Starting and Stopping the Engine Ignition switch .
Page 6: Table Of Contents
Table of Contents Cruise Control Driving Aids Load Carrying Vehicle loading ........237 Tailgate .
Page 7 Table of Contents Maintenance General information ........296 Opening and closing the hood .
Page 8: Table Of Contents
Accessories .........391 Ford Extended Service Plan Scheduled Maintenance Normal scheduled maintenance and log .
Page 9 Errors and omissions excepted. © Ford Motor Company 2012 2013 F-250/350/450/550 (f23) Owners Guide gf, 1st Printing...
Page 10: Introduction
Introduction ABOUT THIS MANUAL Thank you for choosing Ford. We recommend that you take some time to get to know your vehicle by reading this manual. The more that you know about it, the greater the safety and pleasure you will get from driving it.
Page 11 Introduction SYMBOL GLOSSARY WARNING: You risk death or serious injury to yourself and others if you do not follow the instruction highlighted by the warning symbol. These are some of the symbols you may see on your vehicle. Symbol Description Symbol Description Symbol Description Safety alert...
Page 12 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may...
Page 13 Introduction Ford Motor Company, Ford of Canada, and service and repair facilities may access or share among them data for vehicle improvement purposes. For U.S. only (if equipped), if you choose to use the SYNC® Vehicle Health Report, you consent that certain diagnostic information may also...
Page 14 Introduction that have such special equipment, can read the information if they have access to the vehicle or the EDR. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority.
Page 15 See www.dtsc.ca.gov/hazardouswaste/perchlorate for more information. FORD CREDIT (U.S. ONLY) Ford Credit offers a full range of financing and lease plans to help you acquire your vehicle. If you have financed or leased your vehicle through Ford Credit, thank you for your business.
Page 16 Genuine Ford and Motorcraft replacement parts are the only replacement parts that benefit from a Ford Warranty. Damage caused to your vehicle as a result of the failure of non-Ford parts may not be covered by the Ford Warranty. For additional information, see the terms and conditions of the Ford Warranty.
Page 17 Introduction Use of your Ford light truck as an ambulance, without the Ford Ambulance Preparation Package voids the Ford New Vehicle Limited Warranty and may void the Emissions Warranties. In addition, ambulance usage without the preparation package could cause high underbody temperatures, overpressurized fuel and a risk of spraying fuel which could lead to fires.
Page 18 Introduction EXPORT UNIQUE (NON–UNITED STATES/CANADA) VEHICLE SPECIFIC INFORMATION For your particular global region, your vehicle may be equipped with features and options that are different from the features and options that are described in this owner’s manual. A market unique supplement may be supplied that complements this book.
Page 19: Child Safety
NHTSA and other safety organizations, or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician and consulting your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in your vehicle.
Page 20 Child Safety Recommendations for Safety Restraints for Children Child size, height, weight, or Recommended restraint type Infants Children weighing 40 lb (18 kg) or Use a child safety seat less (generally age four or (sometimes called an toddlers younger). infant carrier, convertible seat, or toddler seat).
Page 21: Child Seats
Child Safety CHILD SEATS Use a child safety seat (sometimes called an infant carrier, convertible seat, or toddler seat) for infants, toddlers or children weighing 40 pounds (18 kilograms) or less (generally age four or younger). CHILD SEAT POSITIONING WARNING: Airbags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active airbag.
Page 22 Child Safety WARNING: Always restrain an unoccupied child seat or booster seat. These objects may become projectiles in a crash or sudden stop, which may increase the risk of serious injury. WARNING: Never place, or allow a child to place, the shoulder belt under a child’s arm or behind the back because it reduces the protection for the upper part of the body and may increase the risk of injury or death in a crash.
Page 23: Booster Seats
Child Safety BOOSTER SEATS WARNING: Never place, or allow a child to place, the shoulder belt under a child’s arm or behind the back because it reduces the protection for the upper part of the body and may increase the risk of injury or death in a crash.
Page 24 Child Safety Types of Booster Seats • Backless booster seats If your backless booster seat has a removable shield, remove the shield. If a vehicle seating position has a low seat back or no head restraint, a backless booster seat may place your child’s head (as measured at the tops of the ears) above the top of the seat.
Page 25 Child Safety Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 26: Installing Child Safety Seats
Child Safety INSTALLING CHILD SEATS Using Lap and Shoulder Belts WARNING: Airbags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
Page 27 Child Safety Perform the following steps when installing the child seat with combination lap and shoulder belts: Note: Although the child seat illustrated is a forward facing child seat, the steps are the same for installing a rear facing child seat. 1.
Page 28 Child Safety 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
Page 29 There should be no more than 1 inch (2.5 centimeters) of movement for proper installation. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician to make certain the child restraint is properly installed.
Page 30 Child Safety The belt webbing below the tongue is the lap portion of the combination lap and shoulder belt, and the belt webbing above the tongue is the shoulder belt portion of the combination lap and shoulder belt. 1. Position the child safety seat in the center front seat.
Page 31 Child Safety 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
Page 32 The shoulder belt must be snug to keep the lap belt tight during a collision. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician to make certain the child restraint is properly installed. In Canada, check with your local St. John Ambulance office for referral to a Child Passenger Safety Technician.
Page 33 Child Safety The tether strap anchors in your vehicle are in the following positions (shown from top view): • F-Series Regular Cab • F-Series SuperCab • F-Series Crew Cab Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor.
Page 34 Child Safety Tether Strap Attachment 1. Route the child safety seat tether strap over the back of the seat. For vehicles with adjustable head restraints, route the tether strap under the head restraint and between the head restraint posts, otherwise route the tether strap over the top of the seat back.
Page 35 If the safety seat is not anchored properly, the risk of a child being injured in a collision greatly increases. If your child restraint system is equipped with a tether strap, and the child restraint manufacturer recommends its use, Ford also recommends its use. Tether Strap Attachment (Rear SuperCab Only) There are three loops of webbing just above the back of the rear seat (along the bottom edge of the rear window) in the SuperCab.
Page 36: Child Safety Locks
Child Safety 3. Install the child safety seat tightly using the vehicle belts. Follow the instructions in this chapter. 4. Tighten the tether strap according to the child seat manufacturer’s instructions. A single loop can be used to route and anchor more than one child seat. For example, the center loop can be used as a routing loop for a child safety seat in the center rear seat and as an anchoring loop for child seats installed in the outboard rear seats.
Page 37: Safety Belts
Safety Belts PRINCIPLES OF OPERATION WARNING: Always drive and ride with your seat back upright and the lap belt snug and low across the hips. WARNING: To reduce the risk of injury, make sure children sit where they can be properly restrained. WARNING: Never let a passenger hold a child on his or her lap while the vehicle is moving.
Page 38 Safety Belts WARNING: Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather; they could burn a small child. Check seat covers and buckles before you place a child anywhere near them. WARNING: Front and rear seat occupants, including pregnant women, should wear safety belts for optimum protection in an accident.
Page 39: Fastening The Safety Belts
Safety Belts FASTENING THE SAFETY BELTS The front outboard and rear safety restraints in your vehicle are combination lap and shoulder belts. 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch.
Page 40 Safety Belts 1. To lengthen the lap belt, pull some webbing out of the shoulder belt retractor. 2. While holding the webbing below the tongue, grasp the tip (metal portion) of the tongue so that it is parallel to the webbing and slide the tongue upward.
Page 41 Safety Belts Restraint of Pregnant Women WARNING: Always ride and drive with your seat back upright and the safety belt properly fastened. The lap portion of the safety belt should fit snug and be positioned low across the hips. The shoulder portion of the safety belt should be positioned across the chest.
Page 42 Safety Belts All safety restraints in the vehicle are combination lap and shoulder belts. The driver safety belt has the first type of locking mode, and the front outboard passenger and rear seat safety belts have both types of locking modes described as follows: Vehicle Sensitive Mode This is the normal retractor mode, which allows free shoulder belt length adjustment to your movements and locking in response to vehicle...
Page 43: Safety Belt Height Adjustment
Safety Belts Safety Belt Extension Assembly WARNING: Do not use extensions to change the fit of the shoulder belt across the torso. If the safety belt is too short when fully extended, you can obtain a safety belt extension assembly from an authorized dealer. Use only extensions manufactured by the same supplier as the safety belt.
Page 44: Safety Belt Warning Light And Indicator Chime
Safety Belts SAFETY BELT WARNING LIGHT AND INDICATOR CHIME This lamp illuminates and an audible warning will sound if the driver’s safety belt has not been fastened when the vehicle’s ignition is turned on. Conditions of Operation If... Then... The driver’s safety belt is not The safety belt warning light illuminates buckled before the ignition 1-2 minutes and the warning chime...
Page 45 Safety Belts If... Then... The driver’s safety belt becomes The Belt-Minder® feature is activated - unbuckled for approximately one the safety belt warning light illuminates minute while the vehicle is and the warning chime sounds for six traveling at least 6 mph seconds every 25 seconds, repeating for (9.7 km/h) and more than approximately five minutes or until the...
Page 46: Child Restraint And Safety Belt Maintenance
Read the child restraint manufacturer’s instructions for additional inspection and maintenance information specific to the child restraint. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a crash be replaced.
Page 47: Supplementary Restraints System
Supplementary Restraints System PRINCIPLES OF OPERATION WARNING: Airbags do not inflate slowly or gently, and the risk of injury from a deploying airbag is the greatest close to the trim covering the airbag module. WARNING: All occupants of your vehicle, including the driver, should always properly wear their safety belts, even when an airbag supplemental restraint system is provided.
Page 48 Supplementary Restraints System The airbags are a supplemental restraint system and are designed to work with the safety belts to help protect the driver and right front passenger from certain upper body injuries. Airbags do not inflate slowly; there is a risk of injury from a deploying airbag. Note: You will hear a loud bang and see a cloud of harmless powdery residue if an airbag deploys.
Page 49: Driver And Passenger Airbags
Supplementary Restraints System DRIVER AND PASSENGER AIRBAGS WARNING: Never place your arm or any objects over an airbag module. Placing your arm over a deploying airbag can result in serious arm fractures or other injuries. Objects placed on or over the airbag inflation area may cause those objects to be propelled by the airbag into your face and torso causing serious injury.
Page 50 Supplementary Restraints System • Recline the seat slightly (one or two degrees) from the upright position. After all occupants have adjusted their seats and put on safety belts, it is very important that they continue to sit properly. A properly seated occupant sits upright, leaning against the seat back, and centered on the seat cushion, with their feet comfortably extended on the floor.
Page 51 Supplementary Restraints System FRONT PASSENGER SENSING SYSTEM WARNING: Even with Advanced Restraints Systems, children 12 and under should be properly restrained in a rear seating position. WARNING: The front passenger airbag is not designed to offer protection to an occupant in the center seating position. High-series vehicles (if equipped) The front passenger sensing system uses a passenger airbag status...
Page 52 Supplementary Restraints System Passenger Airbag ON/OFF Switch (if equipped) WARNING: An airbag ON/OFF switch may be installed in this vehicle. Before driving, always look at the face of the switch to be sure the switch is in the proper position in accordance with these instructions and warnings.
Page 53 Supplementary Restraints System Turning the Passenger Airbag Back On WARNING: The safety belts for the driver and right front passenger seating positions have been specifically designed to function together with the airbags in certain types of crashes. When you turn OFF your airbag, you not only lose the protection of the airbag, you also may reduce the effectiveness of your safety belt system, which was designed to work with the airbag.
Page 54 Supplementary Restraints System The vast majority of drivers and passengers are much safer with an airbag than without. To do their job and reduce the risk of life threatening injuries, airbags must open with great force, and this force can pose a potentially deadly risk in some situations, particularly when a front seat occupant is not properly buckled up.
Page 55 Supplementary Restraints System 2. Child age 1 to 12. A child age 1 to 12 must ride in the front seat because: • the vehicle has no rear seat; • although children ages 1 to 12 ride in the rear seat(s) whenever possible, children ages 1 to 12 sometimes must ride in the front because no space is available in the rear seat(s) of the vehicle;...
Page 56: Side Airbags
Supplementary Restraints System 2. Child age 12 or under: A child age 12 or under must ride in the front seat because: • my vehicle has no rear seat; • although children age 12 and under ride in the rear seat whenever possible, children age 12 and under have no option but to sometimes ride in the front seat because rear seat space is insufficient;...
Page 57: Safety Canopy Curtain Airbags
Supplementary Restraints System WARNING: If the side airbag has deployed, the airbag will not function again. The side airbag system (including the seat) must be inspected and serviced by an authorized dealer. If the airbag is not replaced, the unrepaired area will increase the risk of injury in a crash. The side airbags are located on the outboard side of the seat backs of the front seats.
Page 58 Supplementary Restraints System WARNING: Do not attempt to service, repair, or modify the curtain airbags, its fuses, the A, B, or C pillar trim, or the headliner on a vehicle containing curtain airbags. Contact your authorized dealer as soon as possible. WARNING: All occupants of your vehicle including the driver should always wear their safety belts even when an airbag SRS and curtain airbag is provided.
Page 59: Crash Sensors And Airbag Indicator
Supplementary Restraints System • A flexible headliner which opens above the side doors to allow air curtain deployment. • Crash sensors and monitoring system with readiness indicator. See Crash Sensors and Airbag Indicator in this chapter. Children 12 years old and under should always be properly restrained in the rear seats.
Page 60: Airbag Disposal
Supplementary Restraints System • The readiness light will either flash or stay lit. • The readiness light will not illuminate immediately after the ignition is turned on. • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem or light are repaired.
Page 61: Keys And Remote Control
Keys and Remote Control GENERAL INFORMATION ON RADIO FREQUENCIES This device complies with part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 62: Remote Control
Keys and Remote Control REMOTE CONTROL Integrated Keyhead Transmitters (IKTs) (If Equipped) Your vehicle may be equipped with two integrated keyhead transmitters. The key blade is used to start the vehicle and unlock or lock the driver’s door from outside the vehicle.
Page 63 Keys and Remote Control 4. Insert the new battery. Refer to the instructions inside the integrated keyhead transmitter for the correct orientation of the battery. Press the battery down to ensure that the battery is fully seated in the battery housing cavity.
Page 64 Keys and Remote Control Car Finder Press the button twice within three seconds. The horn will chirp and the turn signals will flash. It is recommended that this method be used to locate your vehicle, rather than using the panic alarm. Sounding a Panic Alarm Press the button to activate the alarm.
Page 65 Keys and Remote Control • you have already attempted two remote vehicle starts within the last hour • your vehicle is not in P • your vehicle battery voltage is too low • the service engine soon light is on. Remote Starting the Vehicle Note: You must press each button within three seconds of each other.
Page 66: Replacing A Lost Key Or Remote Control
Keys and Remote Control Extending the Vehicle Run Time Repeat Steps 1 and 2 with your vehicle still running to extend the run time for another remote start duration. If the duration is set to last 10 minutes, the duration will extend by another 10 minutes beginning after what is left of the first activation time.
Page 67: Mykey
MyKey PRINCIPLES OF OPERATION MyKey® allows you to program keys with restricted driving modes to promote good driving habits. All but one of the keys programmed to the vehicle can be activated with these restricted modes. Any keys that have not been programmed are referred to as an administrator key or admin key which can be used to: •...
Page 68: Creating
MyKey • Audio system maximum volume of 45%. A message in the audio system is displayed when attempting to exceed the limited volume. (Not available in vehicles equipped with AM/FM only audio systems.) • AdvanceTrac. The system cannot be turned off when Always-on has been set.
Page 69: Clearing
MyKey Programming/Changing Optional Settings Note: All programmed keys can be cleared within the same key cycle in which a key was programmed, otherwise an admin key is required to clear the keys. To clear all keys, see Clearing all MyKeys. You can access the optional settings through the information display control.
Page 70: Remote Start, Mykey
USING MYKEY WITH REMOTE START SYSTEMS MyKey is NOT compatible with non-Ford-approved aftermarket remote start systems. If you choose to install a remote start system please see your Ford authorized dealer for a Ford-approved remote start system. MYKEY TROUBLESHOOTING Condition Potential Causes •...
Page 71: Locks
Locks LOCKING AND UNLOCKING You can use the power door lock control or the remote control to lock and unlock the vehicle. Power Door Locks (If Equipped) The power door lock control is located on the driver and front passenger door panels.
Page 72 Locks Smart Unlocks (If Equipped) This feature helps to prevent you from locking yourself out of the vehicle if your key is still in the ignition. When you open the driver’s door and lock the vehicle with the power door lock control, all the doors will lock, then the driver’s door will unlock if your key is still in the ignition.
Page 73 Locks Autolock: Once in programming mode, press the power door unlock button then the lock button. The horn will chirp once if autolock was deactivated or twice (one short and one long chirp) if autolock was activated. Autounlock: Once in programming mode, press the power door lock button then the unlock button.
Page 74: Securicode™ Keyless Entry Keypad
Locks SECURICODE™ KEYLESS ENTRY KEYPAD (IF EQUIPPED) You can use the keyless entry keypad to lock or unlock the doors without using a key. The keypad can be operated with the factory set 5-digit entry code; this code is located on the owner’s wallet card in the glove box and is available from your authorized dealer.
Page 75 Locks All personal codes are now erased and only the factory set 5- digit code will work. Anti-Scan Feature The keypad will go into an anti-scan mode if the wrong code has been entered seven times (35 consecutive button presses). This mode disables the keypad for one minute and the keypad lamp will flash.
Page 76: Security
Security SECURILOCK® PASSIVE ANTI-THEFT SYSTEM (IF EQUIPPED) Note: The system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Metallic objects, electronic devices or a second coded key on the same key chain may cause vehicle starting issues if they are too close to the key when starting the engine.
Page 77 Security Programming a Spare Key Note: A maximum of eight coded keys can be programmed to your vehicle. Only four of these eight can be integrated keyhead transmitters. You can program your own integrated keyhead transmitters or standard SecuriLock coded keys to your vehicle. This procedure will program both the engine immobilizer key code and the remote entry portion of the remote control to your vehicle.
Page 78: Anti-Theft Alarm
Security ANTI-THEFT ALARM (IF EQUIPPED) The system will warn you of unauthorized entry to your vehicle. The turn signal lamps will flash and the horn will sound when: • any door or the hood is opened without using the key or the remote control •...
Page 79: Steering Wheel
Steering Wheel ADJUSTING THE STEERING WHEEL WARNING: Do not adjust the steering wheel when your vehicle is moving. Note: Make sure that you are sitting in the correct position. See Sitting in the Correct Position in the Seats chapter. 1. Unlock the steering column. 2.
Page 80 Steering Wheel Media Press the media button repeatedly to scroll through available audio modes. Seek, Next or Previous Press the seek button to: • tune the radio to the next or previous stored preset • play the next or previous track. Press and hold the seek button to: •...
Page 81 Steering Wheel CRUISE CONTROL (IF EQUIPPED) See the Cruise Control chapter. INFORMATION DISPLAY CONTROL Type 1 SETUP INFO RESET Type 2 See the Information Displays chapter. HEATED STEERING WHEEL (IF EQUIPPED) See the MyFord Touch chapter. 2013 F-250/350/450/550 (f23) Owners Guide gf, 1st Printing USA (fus)
Page 82: Pedals
Pedals ADJUSTABLE PEDALS (IF EQUIPPED) WARNING: Never adjust the accelerator and brake pedal with feet on the pedals while the vehicle is moving. The control is located on the left side of the steering column. Press and hold the appropriate control to move the pedals. A.
Page 83: Wipers And Washers
Wipers and Washers WINDSHIELD WIPERS Note: Fully defrost the windshield in icy conditions before turning on the windshield wipers. Rotate the end of the control away from you to increase the speed of the wipers. Rotate toward you to decrease the speed of the wipers. Speed Dependent Wipers When your vehicle speed increases, the interval between wipes will decrease when intermittent wipe is selected.
Page 84: Lighting
Lighting LIGHTING CONTROL • Rotate the headlamp control clockwise to the first position to turn on the parking lamps. • Rotate clockwise to the second position to also turn on the headlamps. High Beams Pull the lever fully past the detent to switch the high beams on.
Page 85: Autolamps
Lighting AUTOLAMPS (IF EQUIPPED) The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control. • To turn autolamps on, rotate the control to the fourth position. • To turn autolamps off, rotate the control to the first, second, or third position.
Page 86: Instrument Lighting Dimmer
Lighting INSTRUMENT LIGHTING DIMMER Use to adjust the brightness of the instrument panel and all applicable lit components in the vehicle during headlamp and parking lamp operation. • Tap the top or bottom of the control to brighten/dim all interior lit components incrementally, or •...
Page 87: Front Fog Lamps
Lighting FRONT FOG LAMPS (IF EQUIPPED) The headlamp control also operates the fog lamps. The fog lamps can be turned on only when the headlamp control is in the parking lamp (second) position, headlamps on (third) position, or autolamp (fourth) position, and the high beams are not turned on.
Page 88: Interior Lamps
Lighting INTERIOR LAMPS Front Map Lamps (If Equipped) The map lamps are located on the overhead console. Press the controls on either side of each map lamp to turn on the lamps. The map lamps also light when: • any door is opened, •...
Page 89: Windows And Mirrors
Windows and Mirrors POWER WINDOWS (IF EQUIPPED) WARNING: Do not leave children unattended in the vehicle and do not let them play with the power windows. They may seriously injure themselves. WARNING: When closing the power windows, you should verify they are free of obstructions and make sure that children and pets are not in the proximity of the window openings.
Page 90 Windows and Mirrors Bounce-Back (One-Touch Up or Down Windows Only) The window will stop automatically while closing and reverse some distance if there is an obstacle in the way. Overriding the Bounce-Back Feature Pull up the window switch and hold within two seconds of the window reaching the bounce-back position.
Page 91: Exterior Mirrors
Windows and Mirrors Power Sliding Back Window (If Equipped) WARNING: When operating the power sliding back window you must ensure all rear seat occupants and/or cargo are not in the proximity of the back window. WARNING: Do not leave children unattended in the vehicle and do not let children play with the power sliding back window.
Page 92 Windows and Mirrors Fold-Away Exterior Mirrors Push the mirror toward the door window glass. Make sure that you fully engage the mirror in its support when returning it to its original position. Power-Folding Mirrors (If Equipped) Note: Activating the mirrors 10 or more times within one minute, or repeated folding and unfolding of the mirrors while holding the control down during full travel, may disable the system to protect motors from overheating.
Page 93: Interior Mirrors
Windows and Mirrors Clearance Lamps (If Equipped) The lower, outer portion of the mirror housings illuminates when the headlamps or parking lamps are switched on. Telescoping Mirrors (If Equipped) This feature allows the mirror to extend approximately 3 inches (75 millimeters).
Page 94: Sun Visors
Windows and Mirrors Auto-Dimming Mirror (If Equipped) Note: Do not block the sensors on the front and back of the mirror. Mirror performance may be affected. A rear center passenger or raised rear center head restraint may also block light from reaching the sensor. The mirror will dim automatically to reduce glare when bright lights are detected from behind your vehicle.
Page 95: Moonroof
Windows and Mirrors MOONROOF (IF EQUIPPED) WARNING: Do not let children play with the moonroof or leave children unattended in the vehicle. They may seriously hurt themselves. WARNING: When closing the moonroof, you should verify that it is free of obstructions and ensure that children and/or pets are not in the proximity of the moonroof opening.
Page 96: Instrument Cluster
Instrument Cluster GAUGES Cluster shown in standard measure. Metric similar. A. Engine oil pressure gauge B. Engine coolant temperature gauge C. Transmission fluid temperature gauge D. Fuel gauge E. Speedometer F. Information display. See Information displays for more information. G. Tachometer Engine Oil Pressure Gauge Indicates engine oil pressure.
Page 97 Instrument Cluster Engine Coolant Temperature Gauge Indicates engine coolant temperature. At normal operating temperature, the level indicator will be in the normal range. If the engine coolant temperature exceeds the normal range, stop the vehicle as soon as safely possible, switch off the engine and let the engine cool. WARNING: Never remove the coolant reservoir cap while the engine is running or hot.
Page 98: Warning Lamps And Indicators
Instrument Cluster WARNING LAMPS AND INDICATORS The following warning lamps and indicators will alert you to a vehicle condition that may become serious. Some lamps will illuminate when you start your vehicle to make sure they work. If any lamps remain on after starting your vehicle, refer to the respective system warning lamp for further information.
Page 99 Instrument Cluster Charging System It will illuminate when the 12–volt battery is not charging properly. Contact your authorized dealer as soon as possible. This indicates a problem with the electrical system or a related component. Check Fuel Cap It will illuminate when the fuel cap may not be properly installed.
Page 100 Instrument Cluster Fasten Safety belt It will illuminate and a chime will sound to remind you to fasten your safety belt. High Beam It will illuminate when the headlamp high beam is switched on. It will flash when you use the headlamp flasher. Hill Descent (if equipped) Illuminates when hill descent is turned on.
Page 101 Instrument Cluster Solid illumination after the engine is started indicates the on-board diagnostics system (OBD-II) has detected a malfunction. Refer to On-board diagnostics (OBD-II) in the Fuel and Refueling chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter.
Page 102: Audible Warnings And Indicators
Instrument Cluster 4X4 HIGH Illuminates when four-wheel drive high is engaged. If the light fails to display when the ignition is turned on, or remains on, have the system serviced immediately by your authorized dealer. Diesel Warning Lights: If your vehicle is equipped with a diesel engine, it has some unique warning lights;...
Page 103: Information Displays
GENERAL INFORMATION WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device or feature that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
Page 104 Information Displays Info Press the INFO button repeatedly to cycle through the following features: Note: Some options may appear slightly different or not at all if the items are optional. INFO TRIP A/B XXX° (if equipped) MYKEY MILES (km) (if programmed) XXX MILES (km) TO E XX.X AVG MPG (L/100km) MPG (L/km)
Page 105 Information Displays • MPG (L/km): This displays instantaneous fuel economy as a bar graph. Your vehicle must be moving to calculate instantaneous fuel economy. Instantaneous fuel economy cannot be reset. • TIMER: Displays the trip elapsed drive time. Press and release RESET to pause the timer.
Page 106 Information Displays SETUP UNITS press the Distance English RESET button Metric Temperature Fahrenheit Celsius AUTOLAMP 0 to 180 seconds (SEC) AUTOLOCK On or Off AUTOUNLOCK On or Off COURTESY On or Off WIPE CREATE MYKEY / MYKEY SETUP / CLEAR MYKEY RESET FOR ZONE SETTING (if equipped) ZONE XX RESET = CHANGE (if equipped) RESET FOR CALIBRATION (if equipped)
Page 107 Information Displays To reset the oil monitoring system to 100% after each oil change, perform the following: 1. Press and release the SETUP button to display OIL LIFE XXX% HOLD RESET = NEW. 2. Press and hold the RESET button for two seconds and release to reset the oil life to 100%.
Page 108 Information Displays • RESET FOR CALIBRATION (if equipped): This feature calibrates the compass. The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antenna. Magnetic or metallic objects placed in, on or near the vehicle may also affect compass accuracy.
Page 109 Information Displays • RESET FOR REMOTE START (if equipped) • REAR PARK AID (if equipped): This feature sounds a warning tone to warn the driver of obstacles near the rear bumper, and functions only when R (Reverse) gear is selected. •...
Page 110 Information Displays • Truck Apps (If Equipped) • Settings • Information Gauge Mode Use the arrow buttons to choose between the following gauge options. Gauge Mode Gauges Detail Engine Oil Temperature (Diesel only) Transmission Temperature Compass The compass orientation can be changed between fixed north or rotating north.
Page 111 Information Displays Trip A/ B Use the arrow buttons to choose between the following trip options. Trip A/ B Trip time Trip distance Fuel used Avg MPG (L/100km) Odometer Press OK to pause the Trip A or B screen/press again to un-pause. Press and hold OK to reset the currently displayed trip information.
Page 112 Information Displays • Average MPG: shows the average fuel usage based on time. See Fuel Hist. to change the time interval. Press and hold OK to reset this value. Truck Apps In this mode, off-road information depicted with graphics and trailer towing application options are available.
Page 113 Information Displays Truck Apps (cont’d) Trailer Active trailer name or default trailer (cont’d) Accumulated trailer distance Trailer gain and output Trailer disconnected. Disregard this status if your vehicle is not equipped with a factory installed trailer brake controller. This message may appear when an aftermarket TBC is used even when the trailer is connected.
Page 114 Information Displays Truck Apps (cont’d) Trailer Press OK for Connection Conventional, Fifth Wheel (cont’d) options Checklist (if and Gooseneck. Use the equipped) up/down arrows to highlight one of these choices and press OK to display the connection checklist. Follow the on-screen instructions to go through the connections list.
Page 115 Information Displays Settings In this mode, you can configure different driver setting choices. Note: Some items are optional and may not appear. Settings Driver Assist Rear Park Aid On/Off Rear Video Camera Delay On/Off Camera Trailer Brake Electric or Elect. Over Hydraulic Mode Trailer Sway On/Off...
Page 116 Information Displays Settings (cont’d) Vehicle Autolamp Off or XXX seconds Delay Compass Zone Setting (1–15) See the diagram below to determine your magnetic zone. Calibration (When choosing Calibration, follow the on-screen directions to calibrate the compass) Easy On/Off Entry/Exit Normal History Used Calculation Towing History Used (distance to...
Page 117 Information Displays Compass (if equipped): Determine which magnetic zone you are in for your geographic location by referring to the zone map. 7 8 9 1011 Settings (cont’d) MyKey Create MyKey Hold OK to create MyKey AdvanceTrac Always On / Selectable MAX Speed 80 MPH (130 km/h) or Off Speed Warning...
Page 118: Information Messages
Information Displays Information System Check Some items will only display during a system check if a problem has been detected. If an issue exists on one of the monitored systems, the number of warnings that need immediate attention will display in red and the number of informational warnings will display in amber.
Page 119 Information Displays AdvanceTrac® / Action / Description Traction Control Messages Displayed when the traction control has been TRACTION disabled by the driver. Refer to the Traction CONTROL OFF Control chapter for more information. Alarm/Security Action / Description Messages Displayed when the perimeter alarm system is TO STOP ALARM START VEHICLE armed and the vehicle is entered using the key...
Page 120 Information Displays Diesel Messages Action / Description CHECK COOLANT Displayed when the coolant additive needs to be checked. Refer to your diesel supplement ADDITIVE for more information. CLEANING Displayed when the vehicle has entered the cleaning mode. Various engine actions will EXHAUST FILTER raise the exhaust temperature in the Diesel Particulate Filter (DPF) system to burn off the...
Page 121 Information Displays Diesel Messages Action / Description STOP SAFELY NOW Displayed and a chime sounds when the vehicle exhaust system temperature exceeds intended operating range. If this warning occurs, engine power is reduced and the engine will shut down when the vehicle speed is below 3 mph (5 km/h).
Page 122 Information Displays Diesel Messages Action / Description ENGINE TURNS Displayed when the vehicle is in the final OFF IN XX 30 seconds of a countdown to where the engine will intentionally be turned off by the SECONDS PCM. The diesel engine shutdown for extended idling is an optional feature.
Page 123 Information Displays Diesel Messages Action / Description EXHAUST CLEAN Displayed when the Diesel Particulate Filter (DPF) manual regeneration process (OCR) has STOPPED been stopped. Refer to your diesel supplement for more information. Displays the distance you can travel before EXHAUST FLUID depleting the remaining diesel exhaust fluid.
Page 124 Information Displays Diesel Messages Action / Description ENGINE IDLED - Displayed when a problem exists with the SCR SEE OWNER’S system. The vehicle will enter into an idle-only MANUAL EXHAUST mode. If the exhaust fluid is empty, it must be replenished to resume normal operation of the FLUID EMPTY vehicle.
Page 125 Information Displays Diesel Messages Action / Description ENGINE IDLED - Displayed when the SCR system detects a SEE OWNER’S fault. The engine will eventually enter into an idle-only mode. Press OK to override the idle MANUAL EXHAUST FLUID SYSTEM mode. Refer to your diesel supplement for more information.
Page 126 The customer warranty may be void from using additives that do not meet or exceed Ford specifications. If the low fuel pressure message persistently appears after re-fueling during the cold start and cold operation...
Page 127 Information Displays Door Messages Action / Description Displayed when the corresponding door is not X DOOR AJAR completely closed. Drivetrain Messages Action / Description LOCKING Displayed when the electronic locking DIFFERENTIAL differential is engaged. ENGAGED/ DISENGAGED LOCKING Displayed when the electronic locking DIFFERENTIAL differential is disengaged.
Page 128 Information Displays Engine Messages Action / Description TRANSPORT MODE Displayed when the vehicle is set to transport mode. The transport mode is used to disable CONTACT DEALER certain vehicle functions to prevent battery discharge when the vehicle is in the transport/inventory phase and is not driven long enough to maintain the battery’s charge.
Page 129 Information Displays Maintenance Action / Description Messages SERVICE POWER The power steering system has detected a condition that requires service. See your STEERING authorized dealer. The power steering system has detected a SERVICE POWER condition within the power steering system STEERING NOW that requires service immediately.
Page 130 Information Displays MyKey® Messages Action / Description BUCKLE UP TO Displayed when a MyKey® is in use and Belt-Minder® is activated. UNMUTE AUDIO MYKEY COULD NOT Displayed when an attempt is made to program a spare key using two existing PROGRAM MyKeys.
Page 131 Information Displays Tire Messages Action / Description LOW TIRE Displays when one or more tires on your vehicle have low tire pressure. PRESSURE TIRE PRESSURE Displays when the tire pressure monitoring system is malfunctioning. If the warning stays MONITOR FAULT on or continues to come on, contact your authorized dealer.
Page 132 Information Displays Trailer Messages Action / Description TRAILER BRAKE Displayed and accompanied by a single chime, in response to faults sensed by the TBC. Refer MODULE FAULT to the Towing chapter for more information. TRAILER Displayed when a correct trailer connection (a trailer with electric trailer brakes) is sensed CONNECTED during a given ignition cycle.
Page 133 Information Displays 4WD Messages Action / Description TO EXIT 4X4 LOW Displayed when 2WD is selected from 4X4 LOW mode. APPLY BRAKE TO EXIT 4X4 LOW Displayed when 2WD is selected while the vehicle has been stopped in 4X4 LOW. SHIFT TO N TO EXIT 4X4 LOW Displayed when 2WD is selected while the...
Page 134 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Note: Do not insert CDs with homemade paper (adhesive) labels into the CD player as the label may peel and cause the CD to become jammed.
Page 135 Audio System MP3 Track and Folder Structure Audio systems capable of recognizing and playing MP3 individual tracks and folder structures work as follows: • There are two different modes for MP3 disc playback: MP3 track mode (system default) and MP3 folder mode. •...
Page 136: Audio System Am/Fm Stereo
AUDIO WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that you use extreme caution when using any device or feature that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 137: Am/Fm/Cd With Sync
AM/FM/CD WITH SYNC® WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that you use extreme caution when using any device or feature that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 138 Audio System C. Tune: Press this button to manually search through the radio frequency band. Press and hold for a fast search. D. Phone: Press this button to access the phone features of the SYNC® system. See the SYNC® chapter for more information. E.
Page 139 Audio System H. Play, Pause and OK: • Play and Pause allow you to play or pause a track when listening to a • OK allows you to confirm commands with phone and media features of the SYNC system. See the SYNC® chapter for more information. I.
Page 140 MEDIA WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that you use extreme caution when using any device or feature that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 141: Auxiliary Input Jack
AUXILIARY INPUT JACK WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that you use extreme caution when using any device or feature that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 142: Usb Port
USB PORT (IF EQUIPPED) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that you use extreme caution when using any device or feature that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
Page 143: Satellite Radio Information
Audio System MEDIA HUB (IF EQUIPPED) The media hub is located in the center console and has the following features: A. A/V inputs B. SD card slot C. USB ports For more information, see the MyFord Touch chapter. SATELLITE RADIO INFORMATION (IF EQUIPPED) Satellite Radio Channels SIRIUS®...
Page 144 Note: SIRIUS® reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
Page 145 Audio System SIRIUS® Troubleshooting Tips Radio Display Condition Possible Action Invalid Channel The channel is no Tune to another longer available. channel or choose another preset. Unsubscribed Channel Your subscription does Contact SIRIUS® at not include this 1–888–539–7474 to channel. subscribe to the channel, or tune to another channel.
Page 146: Climate Control
Climate Control MANUAL CLIMATE SYSTEM MAX A/C A. Defrost: Distributes air through the windshield defroster vents and demister vents. This setting can also be used to defog and clear the windshield of a thin covering of ice. B. Rear defrost and heated mirrors: Turns the heated rear window and heated mirrors on and off.
Page 147 Climate Control Distributes air through the floor vents. E. A/C: Press to turn air conditioning on or off. Air conditioning cools the vehicle using outside air. To improve air conditioning when starting your vehicle, drive with the windows slightly open for two to three minutes.
Page 148: Dual Automatic Temperature Control
Climate Control DUAL AUTOMATIC TEMPERATURE CONTROL SYSTEM PASS TEMP AUTO Note: You can switch temperature units between Fahrenheit and Celsius. See Menu features in the MyFord Touch or MyLincoln Touch chapter. A. Power/Driver temperature control: Press to turn the climate control system on and off.
Page 149 Climate Control Distributes air through the instrument panel vents and floor vents. Distributes air through the floor vents. E. A/C: Press to turn air conditioning on or off. Air conditioning cools the vehicle using outside air. To improve air conditioning when starting your vehicle, drive with the windows slightly open for two to three minutes.
Page 150 Climate Control GENERAL OPERATING TIPS Manual Heating and Air Conditioning System • To reduce fog build-up on the windshield during humid weather, select Defrost. Temperature and fan speed can also be increased to improve clearing. • To reduce humidity build-up inside the vehicle, do not drive with the system off or with recirculated air engaged.
Page 151 Climate Control Dual Zone Automatic Temperature Control • To reduce fog build-up on the windshield during humid weather, select Defrost. Temperature and fan speed can also be increased to improve clearing. • To reduce humidity build-up inside the vehicle, do not drive with the system off or with recirculated air engaged.
Page 152: Rear Window Defroster
Climate Control HEATED WINDOWS AND MIRRORS (IF EQUIPPED) Heated Rear Window Note: The engine must be running to use this feature. Note: If your vehicle is equipped with a sliding rear window, the feature still operates when the window is opened. Press the button to clear the rear window of thin ice and fog.
Page 153 Climate Control Manual Climate Systems In hot weather, the climate control system is set to MAX A/C. In moderate weather, the system either heats or cools (based on previous settings). The rear defroster and heated mirrors are not automatically turned on. In cold weather, maximum heat is provided in floor/defrost mode.
Page 154: Seats
Seats SITTING IN THE CORRECT POSITION WARNING: Sitting improperly out of position or with the seat back reclined too far can take off weight from the seat cushion and affect the passenger sensing system, resulting in serious injury or death in a crash. Always sit upright against your seat back, with your feet on the floor.
Page 155: Head Restraints
Seats HEAD RESTRAINTS WARNING: To minimize the risk of neck injury in the event of a crash, you and the passenger occupants should not sit in or operate the vehicle, until the head restraint is placed in its proper position. Never adjust the head restraint while the vehicle is in motion. WARNING: The adjustable head restraint is a safety device.
Page 156 Seats Adjusting the Head Restraint Raise: Pull up the head restraint. Lower: 1. Press and hold button C. 2. Push down on the head restraint. Remove: 1. Pull up the head restraint until it reaches the highest adjustment position. 2. Press and hold buttons C and D. 3.
Page 157: Manual Seats
Seats Tilting Head Restraints (If Equipped) The front head restraints may have a tilting feature for extra comfort. To tilt the head restraint, do the following: 1. Adjust the seat back to an upright driving or riding position. 2. Tilt the head restraint forward by gently pulling the top of the head restraint.
Page 158 Seats Recline Adjustment Manual Lumbar (If Equipped) The lumbar support control is located on the outboard side of the seat. Turn the control to adjust your support. 2013 F-250/350/450/550 (f23) Owners Guide gf, 1st Printing USA (fus)
Page 159: Power Seats
Seats POWER SEATS (IF EQUIPPED) WARNING: Before returning the seat back to its original position, make sure that cargo or any objects are not trapped behind the seat back. WARNING: Never adjust the driver’s seat or seat back when the vehicle is moving.
Page 160: Memory Function
Seats MEMORY FUNCTION (IF EQUIPPED) This system allows automatic positioning of the driver seat, power mirrors, and adjustable pedals to two programmable positions. The memory control is located on the driver’s door. • To program position 1, move the memory features to the desired positions using the associated controls.
Page 161: Rear Seats
Seats REAR SEATS Folding Up the Rear Seats (SuperCab) 1. Pull the control to release the seat cushion. 2. Rotate the seat cushion up until it locks into the vertical storage position. Returning the Seat to the Seating Position WARNING: Make sure that cargo or any objects are not trapped underneath the seat cushion before returning the seat cushion to its original position, and that the seat cushion locks into place.
Page 162 Seats Folding up the Rear Seat Cushion 1. Pull the control to release the seat cushion. 2. Rotate the seat cushion up until it locks into the vertical storage position. Returning the Seat to the Seating Position WARNING: Make sure that cargo or any objects are not trapped underneath the seat cushion before returning the seat cushion to its original position, and that the seat cushion locks into place.
Page 163 Seats Use your vehicle key to lock the storage space. Rear Heated Seats (if equipped) WARNING: Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions, must exercise care when using the seat heater.
Page 164 Seats To operate the heated seats: • Push the indicated side of the control for maximum heat. • Push again to deactivate. • Push the indicated side of the control for minimum heat. • Push again to deactivate. The heated seat module resets at every ignition run cycle. While the ignition is in the on position, activate the high or low heated seat switch to enable heating mode.
Page 165: Heated And Cooled Seats
Seats HEATED AND COOLED SEATS (IF EQUIPPED) Heated Seats WARNING: Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions, must exercise care when using the seat heater. The seat heater may cause burns even at low temperatures, especially if used for long periods of time.
Page 166 Seats Heated and Cooled Seats Air Filter Replacement (if equipped) The heated and cooled seat system includes air filters that must be replaced periodically. See scheduled maintenance information. The filter is located under each front seat. Access the filter from the 2nd row foot-well area.
Page 167 Seats Pull up on the tab to open the storage bin. Lift up on the seat back to return it to the upright position. To gain access to the under-seat storage compartment (if equipped) in your seat cushion, lift the latch to open the lid.
Page 168: Universal Garage Door Opener (If Equipped) 167
Universal Garage Door Opener (If Equipped) 167 UNIVERSAL GARAGE DOOR OPENER The appearance of your vehicle’s universal garage door opener will vary according to your option package. Before programing, make sure you identify which transmitter you have by comparing it to the graphics below. HomeLink®...
Page 169 168 Universal Garage Door Opener (If Equipped) Note: We recommend that upon the sale or lease termination of your vehicle, you erase the programmed function buttons for security reasons. See Erasing the Function Button Codes later in this section. Note: You can program a maximum of three devices. To change or replace any of the three devices after it has been initially programmed, you must first erase the current settings.
Page 170 Universal Garage Door Opener (If Equipped) 169 Rolling Code Programming Note: If you do not follow the time-sensitive instructions, the device will time out and you will have to repeat the complete procedure. Note: It may be helpful to have another person assist you in programming the transmitter.
Page 171 170 Universal Garage Door Opener (If Equipped) Fixed Code Programming Note: It may be helpful to have another person assist you in programming the transmitter. To program units with fixed code DIP switches, you will need the garage door hand-held transmitter, paper and a pen or pencil.
Page 172 Universal Garage Door Opener (If Equipped) 171 8. The LED lamp will begin to flash rapidly until programming is complete. If your garage door does not operate, repeat the previous steps. Otherwise, call the toll-free help line at 1-866-572-2728. The LED lamp above the selected button will illuminate to confirm that the system is responding to the button command.
Page 173: Homelink® Wireless Control System
172 Universal Garage Door Opener (If Equipped) Note: We recommend that upon the sale or lease termination of your vehicle, you erase the programmed function buttons for security reasons. See Erasing the function button codes later in this section. Note: You can program a maximum of three devices. To change or replace any of the three devices after it has been initially programmed, you must first erase the current settings.
Page 174 Universal Garage Door Opener (If Equipped) 173 If the indicator light stays on, the programming is complete. Press and release the programmed HomeLink button, and then begin programming your garage door opener. See below for Steps 5 – 7. If the indicator light flashes rapidly for two seconds and then turns to a constant light, the HomeLink button is not programmed yet.
Page 175 174 Universal Garage Door Opener (If Equipped) Erasing the Function Button Codes Note: You cannot erase individual buttons. 1. Press and hold the outer two function buttons simultaneously for approximately 20 seconds until the indicator lights above the buttons flash rapidly. 2.
Page 176 Universal Garage Door Opener (If Equipped) 175 2. Press the same button twice to confirm the change to Programming mode. If done properly the LED light will appear red. 3. Hold the transmitter within 1–3 inches (2–8 centimeters) of the button on the sun visor you want to program.
Page 177 176 Universal Garage Door Opener (If Equipped) 4. Press and release the Genie Intellicode 2 hand-held transmitter’s previously programmed button. Both indicator lights on the garage door opener motor unit should now flash purple. 5. Press and hold the previously programmed button on the sun visor for 2 seconds.
Page 178: Auxiliary Power Points
Auxiliary Power Points AUXILIARY POWER POINTS WARNING: Do not plug optional electrical accessories into the cigarette lighter socket (if equipped). Improper use of the lighter can cause damage not covered by your warranty, and can result in fire or serious injury. Note: If used when the engine is not running, the battery will discharge.
Page 179 Auxiliary Power Points 110 Volt AC Power Point (If Equipped) WARNING: Do not keep electrical devices plugged in the powerpoint whenever the device is not in use. Do not use any extension cord with the 110 volt AC power point, since it will defeat the safety protection design.
Page 180 Auxiliary Power Points The power point can switch to a fault mode when it is overloaded, overheated, or shorted. Unplug your device and turn the ignition off then on for overloading and shorting conditions. Let the system cool off, then turn the ignition off then on for an overheating condition.
Page 181: Storage Compartments
Storage Compartments CENTER CONSOLE (IF EQUIPPED) WARNING: Use only soft cups in the cupholder. Hard objects can injure you in a collision. Your vehicle may be equipped with a variety of console features. These include: • Locking storage compartment with hanging file folder supports •...
Page 182: Overhead Console
Storage Compartments OVERHEAD CONSOLE (IF EQUIPPED) The appearance of the overhead console will vary according to your option package. Press near the rear edge of the door to open it. 2013 F-250/350/450/550 (f23) Owners Guide gf, 1st Printing USA (fus)
Page 183: Starting And Stopping The Engine
Starting and Stopping the Engine GENERAL INFORMATION WARNING: Extended idling at high engine speeds can produce very high temperatures in the engine and exhaust system, creating the risk of fire or other damage. WARNING: Do not park, idle, or drive your vehicle on dry grass or other dry ground cover.
Page 184: Ignition Switch
Starting and Stopping the Engine IGNITION SWITCH Note: To switch the engine off when your vehicle is moving, move the transmission selector lever to position N. Use the brakes to bring your vehicle to a safe stop. After your vehicle has stopped, switch the engine off and move the transmission selector lever to position P.
Page 185 Starting and Stopping the Engine 2. Select position P or N. 3. Turn the key to start the engine. The engine may continue cranking for up to 15 seconds or until the vehicle starts. Note: If the engine does not start on the first try, wait for a short period of time and try again.
Page 186: Engine Block Heater
Starting and Stopping the Engine If the Engine Fails to Start Using the Preceding Instructions (Flexible Fuel Vehicles Only) 1. Press and hold down the accelerator 1/3 to 1/2 way to floor, then crank the engine. 2. When the engine starts, release the key, then gradually release the accelerator pedal as the engine speeds up.
Page 187 Starting and Stopping the Engine We recommend that you do the following for safe and correct operation: • Use a 16-gauge outdoor extension cord that is product certified by Underwriter’s Laboratory or Canadian Standards Association. This extension cord must be able to be used outdoors, in cold temperatures, and be clearly marked Suitable for Use with Outdoor Appliances.
Page 188: Fuel And Refueling
Fuel and Refueling IMPORTANT SAFETY PRECAUTIONS WARNING: Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. WARNING: The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 189 Fuel and Refueling Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle. • Always turn off the vehicle before fueling. • Automotive fuels can be harmful or fatal if swallowed. Fuels such as gasoline and ethanol are highly toxic and if swallowed can cause death or permanent injury.
Page 190: Fuel Quality
Fuel and Refueling During the summer season, fuel ethanol may contain a maximum of 85% denatured ethanol (Ed85) and 15% unleaded gasoline. The fuel ethanol has a higher octane rating than unleaded regular or premium gasoline and this allows the design of engines with greater efficiency and power. Winter blends may contain up to 75% denatured ethanol (Ed75) and up to 25% unleaded gasoline to enhance cold engine starts.
Page 191 Fuel and Refueling Octane Recommendations Regular unleaded gasoline with a pump (R+M)/2 octane rating of 87 is recommended. Some stations offer fuels posted as Regular with (R+M)/2 METHOD an octane rating below 87, particularly in high altitude areas. Do not use fuels with a posted octane rating below 87.
Page 192: Refueling
Fuel and Refueling Use the following directions when filling from a portable fuel container: 1. Remove the fuel cap by rotating it counter clockwise. 2. Slowly insert the portable fuel container into the fuel filler opening. 3. Fill the vehicle with fuel from the portable fuel container. 4.
Page 193 Ford, Motorcraft® or other certified fuel filler cap is not used. Your fuel tank filler cap has an indexed design with a 1/4th turn on and off feature.
Page 194: Fuel Consumption
Fuel and Refueling FUEL CONSUMPTION Filling the Tank The advertised capacity is the indicated capacity and the empty reserve combined. Indicated capacity is the difference in the amount of fuel in a full tank and a tank when the fuel gauge indicates empty. Empty reserve is the amount of fuel in the tank after the fuel gauge indicates empty.
Page 195 Information are essential to the life and performance of your vehicle and to its emissions system. If other than Ford, Motorcraft® or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 196 Fuel and Refueling sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent it from working. Information about your vehicle’s emission system is on the Vehicle Emission Control Information Decal located on or near the engine.
Page 197 Fuel and Refueling Readiness for Inspection/Maintenance (I/M) Testing Some state, provincial and local governments may have Inspection/Maintenance (I/M) programs to inspect the emission control equipment on your vehicle. Failure to pass this inspection could prevent you from getting a vehicle registration. If the service engine soon indicator is on or the bulb does not work, the vehicle may need to be serviced.
Page 198: Transmission
Transmission AUTOMATIC TRANSMISSION OPERATION Understanding the Shift Positions of the 5–Speed Automatic Transmission (If Equipped) WARNING: Do not use the tow/haul feature when driving in icy or slippery conditions as the increased engine braking can cause the rear wheels to slide and the vehicle to swing around with the possible loss of vehicle control.
Page 199 Transmission D (Overdrive) with Tow/Haul On The tow/haul feature improves transmission operation when towing a trailer or a heavy load. All transmission gear ranges are available when using tow/haul. To activate tow/haul, press the button on the end of the gearshift lever.
Page 200 Transmission 1 (First) • Provides maximum engine braking. • Allows upshifts by moving gearshift lever. • The transmission will not downshift into 1 (First) at high speeds; it will downshift to a lower gear and then shift into 1 (First) when the vehicle reaches slower speeds.
Page 201 Transmission To put your vehicle in P (Park): 1. Come to a complete stop 2. Move the gearshift lever and securely latch it in P (Park) R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse).
Page 202 Transmission Tow/haul may be automatically activated (without pressing the tow/haul button). This provides engine braking to assist the vehicles braking system when going downhill and repetitive braking is sensed. Once the tow/haul mode has been automatically activated it will not automatically deactivate.
Page 203 Transmission Understanding your SelectShift Automatic® transmission This vehicle is equipped with a SelectShift Automatic™ transmission gearshift lever. SelectShift Automatic™ transmission gives you the ability to change gears up or down (without a clutch) as desired. Use the buttons on the shifter to lock or unlock gears and manually select gears.
Page 204 Transmission Recommended shift speeds Upshift according to the following chart: Upshifts when accelerating (recommended for best fuel economy) Shift from: Gasoline engines Diesel engines 1 – 2 15 mph (24 km/h) 12 mph (19 km/h) 2 – 3 25 mph (40 km/h) 19 mph (31 km/h) 3 –...
Page 205 Transmission Brake-shift interlock WARNING: Do not drive your vehicle until you verify that the brake lamps are working. WARNING: When doing this procedure, you will be taking the vehicle out of park which means the vehicle can roll freely. To avoid unwanted vehicle movement, always fully set the parking brake prior to doing this procedure.
Page 206 Transmission 6. Remove the three fasteners under the column that secure the lower shroud half to the column. 7. Pull the lock lever into the full unlocked position and remove the lower shroud cover by pulling the lever handle through the slot in the cover.
Page 207: Hill Start Assist
Transmission HILL START ASSIST WARNING: The hill start assist feature does not replace the parking brake. When you leave the vehicle, always apply the parking brake and shift the transmission into P (Park). WARNING: You must remain in the vehicle once you have activated the hill start assist feature.
Page 208: Four-Wheel Drive (If Equipped)
Four-Wheel Drive (If Equipped) USING FOUR-WHEEL DRIVE (4WD) (IF EQUIPPED ) WARNING: For important information regarding safe operation of this type of vehicle, see General Information in the Wheels and Tires chapter. Note: Do not use 4X4 mode on dry, hard surfaced roads. Doing so will produce excessive noise, increase tire wear and may damage drive components.
Page 209 Four-Wheel Drive (If Equipped) For proper operation, make sure that each hub is fully engaged and that both hub locks are set to the same position (both set to LOCK or both set to AUTO). To engage LOCK, turn the hub locks completely clockwise;...
Page 210 Four-Wheel Drive (If Equipped) 4X4 LOW - Continuously illuminates when 4L is selected. CHECK 4X4 - Displays when a 4X4 fault is present. Using a Manual Shift On Stop (MSOS) 4wd system (if equipped) Note: High shift efforts may be encountered when attempting to shift into and out of 4x4 modes.
Page 211 Four-Wheel Drive (If Equipped) • Move the transfer case lever from 4H (4x4 High) to 2H (2WD) at a stop or a vehicle speed below 3 mph (5 km/h), then disengage the locking hubs (optional) by rotating the hub lock control from LOCK to FREE .
Page 212 Four-Wheel Drive (If Equipped) Using the Electronic Shift on the Fly 4WD system (If Equipped) 2H (2WD) - For general on-road driving. Sends power to the rear wheels only and should be used for street and highway driving. Provides optimal smoothness and fuel economy at high speeds.
Page 213 Four-Wheel Drive (If Equipped) Shifting to/from 4L (4X4 low) Note: Some noise may be heard as the system shifts or engages; this is normal. Note: 4x4 low mode is not intended for use on dry pavement. 1. Bring the vehicle to a speed of 3 mph (5 km/h) or less. 2.
Page 214 • The left and right rear wheel speed difference is too high during an engagement attempt. • The system has malfunctioned and will be accompanied by a message in the information display. See your authorized Ford dealer for assistance. 2013 F-250/350/450/550 (f23)
Page 215 Four-Wheel Drive (If Equipped) How Your Vehicle Differs From Other Vehicles WARNING: Vehicles with a higher center of gravity such as utility and four-wheel drive vehicles handle differently than vehicles with a lower center of gravity. Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
Page 216 Four-Wheel Drive (If Equipped) Power is supplied to all four wheels through a transfer case. On 4WD vehicles, the transfer case allows you to select 4WD when necessary. Information on transfer case operation and shifting procedures can be found in this chapter. Information on transfer case maintenance can be found in the Maintenance chapter.
Page 217 Four-Wheel Drive (If Equipped) Note: Do not rock the vehicle for more than a few minutes or damage to the transmission and tires may occur or the engine may overheat. If your vehicle gets stuck in mud or snow it may be rocked out by shifting between forward and reverse gears, stopping between shifts, in a steady pattern.
Page 218 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by treading lightly.
Page 219 Four-Wheel Drive (If Equipped) Apply just enough power to the wheels to climb the hill. Too much power will cause the tires to slip, spin or lose traction, resulting in loss of vehicle control. Descend a hill in the same gear you would use to climb up the hill to avoid excessive brake application and brake overheating.
Page 220 Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).
Page 221: Brakes
Brakes GENERAL INFORMATION Note: Occasional brake noise is normal. If a metal-to-metal, continuous grinding or continuous squeal sound is present, the brake linings may be worn-out and should be inspected by an authorized dealer. If your vehicle has continuous vibration or shudder in the steering wheel while braking, it should be inspected by an authorized dealer.
Page 222: Hints On Driving With Anti-Lock Brakes
Brakes If the anti-lock brake system is disabled, normal braking is still effective. If the brake warning lamp illuminates with the parking brake released, have your brake system serviced immediately. HINTS ON DRIVING WITH ANTI-LOCK BRAKES When the system is operating, the brake pedal will pulse and may travel further.
Page 223: Traction Control
Traction Control PRINCIPLES OF OPERATION The traction control system helps avoid drive wheel spin and loss of traction. If your vehicle begins to slide, the system applies the brakes to individual wheels and, when needed, reduces engine power at the same time. If the wheels spin when accelerating on slippery or loose surfaces, the system reduces engine power in order to increase traction.
Page 224 Traction Control System indicator lights and messages WARNING: If a failure has been detected within the Traction Control System, the stability control light will illuminate steadily. Verify that the Traction Control System was not manually disabled using the stability control button. If the stability control light still illuminates steadily, have the system serviced by an authorized dealer immediately.
Page 225 Stability Control PRINCIPLES OF OPERATION WARNING: Vehicle modifications involving braking system, aftermarket roof racks, suspension, steering system, tire construction or wheel and tire size may change the handling characteristics of the vehicle and may adversely affect the performance of the AdvanceTrac® system. In addition, installing any stereo loudspeakers may interfere with and adversely affect the AdvanceTrac®...
Page 226: Stability Control Advancetrac
Stability Control A Vehicle without AdvanceTrac® with RSC® skidding off its intended route. B Vehicle with AdvanceTrac® with RSC® maintaining control on a slippery surface. USING ADVANCETRAC® WITH RSC® (Single rear wheel vehicles only) The system automatically activates when you start your engine. The electronic stability control and roll stability control portions of the system can be turned off below 35 mph (56 km/h) and are disabled when the transmission is in position R.
Page 227 Stability Control AdvanceTrac® with RSC® Features (Single rear wheels only) Stability Button functions control RSC® light Button pressed Illuminated Enabled Enabled Disabled momentarily solid Button pressed and held for more than Flashes then 5 seconds at vehicle illuminated Disabled Disabled Disabled speed under 35 mph solid...
Page 228: Terrain Response
Terrain Response Hill descent control (if equipped) Hill descent control allows the driver to set and maintain vehicle speed while descending steep grades in various surface conditions. WARNING: Hill descent control cannot control descent in all surface conditions and circumstances, such as ice or extremely steep grades.
Page 229 Terrain Response Whether accelerating or decelerating, once the desired descent speed is reached, remove your feet from the pedals and the chosen vehicle speed will be maintained. Note: Noise from the ABS pump motor may be observed during hill descent control operation. This is a normal characteristic of the ABS and should be no reason for concern.
Page 230: Parking Aids
Parking Aids SENSING SYSTEM (IF EQUIPPED) WARNING: To help avoid personal injury, please read and understand the limitations of the system as contained in this section. Sensing is only an aid for some (generally large and fixed) objects when moving in reverse on a flat surface at parking speeds. Traffic control systems, inclement weather, air brakes, and external motors and fans may also affect the function of the sensing system;...
Page 231 Parking Aids The sensing system warns the driver of obstacles within a certain range of the bumper area. The system turns on automatically whenever the ignition is switched on. When receiving a detection warning, the radio volume is reduced to a predetermined level.
Page 232: Rear-View Camera System
Parking Aids REAR VIEW CAMERA SYSTEM (IF EQUIPPED) WARNING: The rear view camera system is a reverse aid supplement device that still requires the driver to use it in conjunction with the interior and exterior mirrors for maximum coverage. WARNING: Objects that are close to either corner of the bumper or under the bumper, might not be seen on the screen due to the limited coverage of the camera system.
Page 233 Parking Aids 2. Centerline: Helps align the center of the vehicle with an object (i.e. a trailer). Note: If the image comes on while the transmission is not in R (Reverse), have the system inspected by your authorized dealer. Note: When towing, the camera only sees what is being towed behind the vehicle.
Page 234 Parking Aids Always use caution while reversing. Objects in the red zone are closest to your vehicle and objects in the green zone are further away. Objects are getting closer to your vehicle as they move from the green zone to the yellow or red zones.
Page 235: Cruise Control
Cruise Control PRINCIPLES OF OPERATION Cruise control lets you maintain a set speed without keeping your foot on the accelerator pedal. USING CRUISE CONTROL (IF EQUIPPED) WARNING: Do not use cruise control in heavy traffic or on roads that are winding, slippery or unpaved. Note: Vehicle speed may vary momentarily when driving up or down a steep hill.
Page 236 Cruise Control Changing the Set Speed Note: If you accelerate by pressing the accelerator pedal, the set speed will not change. When you release the accelerator pedal, you will return to the speed that you previously set. • Press and hold SET + or SET –. Release the control when you reach the desired speed.
Page 237: Driving Aids
Driving Aids Steering To help prevent damage to the power steering system: • Never hold the steering wheel at its furthest turning points (until it stops) for more than three to five seconds when the engine is running. • Do not operate the vehicle with a low power steering pump fluid level (below the MIN mark on the reservoir).
Page 238: Load Carrying
Load Carrying LOAD LIMIT Vehicle Loading – With and Without a Trailer This section will guide you in the proper loading of your vehicle and/or trailer, to keep your loaded vehicle weight within its design rating capability, with or without a trailer. Properly loading your vehicle will provide maximum return of vehicle design performance.
Page 239 Load Carrying WARNING: The appropriate loading capacity of your vehicle can be limited either by volume capacity (how much space is available) or by payload capacity (how much weight the vehicle should carry). Once you have reached the maximum payload of your vehicle, do not add more cargo, even if there is space available.
Page 240 Load Carrying Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
Page 241 Load Carrying • Example only: WARNING: Exceeding the Safety Compliance Certification Label vehicle weight rating limits could result in substandard vehicle handling or performance, engine, transmission and/or structural damage, serious damage to the vehicle, loss of control and personal injury. 2013 F-250/350/450/550 (f23) Owners Guide gf, 1st Printing USA (fus)
Page 242 Load Carrying GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
Page 243 Load Carrying WARNING: Do not use replacement tires with lower load carrying capacities than the original tires because they may lower the vehicle’s GVWR and GAWR limitations. Replacement tires with a higher limit than the original tires do not increase the GVWR and GAWR limitations.
Page 244 Load Carrying • Suppose your vehicle has a 1400 lb. (635 kg) cargo and luggage capacity. You and one of your friends decide to pick up cement from the local home improvement store to finish that patio you have been planning for the past 2 years.
Page 245: Tailgate
Load Carrying TAILGATE Tailgate Lock The tailgate lock is designed to help prevent theft of the tailgate. Insert the ignition key into the tailgate lock. Turn it to the right to lock or to the left to unlock the tailgate. Tailgate Removal WARNING: Always properly secure cargo to prevent shifting cargo or cargo falling from vehicle, which could result in...
Page 246 Load Carrying 4. Lower the tailgate. 5. Using a screwdriver, gently pry the spring clip (on each connector) past the head of the support screw. Disconnect cable. 6. Disconnect the other cable. 7. Lift tailgate to a 45-degree angle from horizontal. 8.
Page 247 Load Carrying Opening the Tailgate Step 1. Flip down the tailgate. 2. Pull the yellow latch lever to the unlock position to release the grab handle from its stowed position. 3. Raise the handle upright until you feel it latch and see the latch lever in the lock position.
Page 248 Load Carrying BED EXTENDER (IF EQUIPPED) Note: This feature is not intended for off-road usage. Note: Make sure the locking pins and knobs are fully engaged when the vehicle is in motion. Note: Make sure all cargo is secured. Note: The tailgate load must not exceed 150 pounds (68 kilograms) when the vehicle is in motion.
Page 249 Load Carrying 3. Rotate the panels toward the tailgate. Repeat Steps 1–3 for the other side of the bed extender. 4. Connect the two panels, then rotate both knobs a quarter-turn clockwise to secure the panels. 5. Make sure the latch rod is inserted into the tailgate hole and the locking pins on both sides are engaged into their holes in the...
Page 250: Towing
Towing TOWING A TRAILER WARNING: Do not exceed the GVWR or the GAWR specified on the certification label. WARNING: Towing trailers beyond the maximum recommended gross trailer weight exceeds the limit of the vehicle and could result in engine damage, transmission damage, structural damage, loss of vehicle control, vehicle rollover and personal injury.
Page 251 Towing This feature applies the vehicle brakes at individual wheels and, if necessary, reduces engine power. If the trailer begins to sway, the stability control light flashes and the message TRAILER SWAY REDUCE SPEED appears in the information display. The first thing to do is slow the vehicle down, then pull safely to the side of the road and check for proper tongue load and trailer load distribution.
Page 252 Towing • Driver weight • Passenger(s) weight • Payload, cargo and luggage weight • Aftermarket equipment weight. 3. This equals the maximum loaded trailer weight (for this combination). Note: The trailer tongue load is considered part of the payload for your vehicle so the total payload should be reduced by the final trailer tongue weight.
Page 253 Towing Hitches WARNING: ON PICK-UP TRUCKS, the trailer hitch provided on this vehicle enhances collision protection for the fuel system. DO NOT REMOVE! Do not use a hitch that either clamps onto the bumper or attaches to the axle. You must distribute the load in your trailer so that 10–15% for conventional towing or 15–25% for fifth-wheel towing of the total weight of the trailer is on the tongue.
Page 254 Towing Fifth-Wheel Trailer Hitch (If Equipped) WARNING: The mounting pads in the bed are specifically designed for certain fifth-wheel trailer hitches and gooseneck ball hitches. Do not use these mounting pads for other purposes. Doing so could result in vehicle structural damage, loss of vehicle control, and personal injury.
Page 255: Trailer Brake Controller-Integrated
1500 pounds (680 kilograms) when loaded. Integrated Trailer Brake Controller (If Equipped) WARNING: The Ford TBC has been verified to be compatible with trailers having electric-actuated drum brakes (one to four axles) and some electric-over-hydraulic (EOH) brakes. It will not activate hydraulic surge-style trailer brakes.
Page 256 Towing The Ford TBC has been tested to be compatible with several major brands of electric-over-hydraulic trailer brakes; contact your authorized dealer for information on which brands can be used. The TBC user interface consists of the following: A. +/- (GAIN adjustment buttons): Pressing these buttons adjusts the TBC’s power output to the trailer brakes (in 0.5 increments).
Page 257 Towing B. Manual control lever: Slide the control lever to the left to activate power to the trailer’s electric brakes independent of the tow vehicle’s brakes (see the following Procedure for adjusting GAIN section for instructions on proper use of this feature). If the manual control is activated while the brake is also applied, the greater of the two inputs determines the power sent to the trailer brakes.
Page 258 Note: Your TBC can be diagnosed by your authorized dealer to determine exactly which trailer fault has occurred. However, if the fault is with the trailer this diagnosis is not covered under your Ford warranty. TRAILER BRAKE MODULE FAULT: Displays in response to faults sensed by the TBC (accompanied by a single chime).
Page 259 The TBC module and display turn on when the ignition is turned from the off position to the on position. • The TBC is only a factory-installed or dealer-installed item. Ford is not responsible for warranty or performance of the TBC due to misuse or customer installation.
Page 260 Towing • Shift to a lower gear when driving down a long or steep hill. Do not apply the brakes continuously, as they may overheat and become less effective. • If your transmission is equipped with the tow/haul feature, use this when towing.
Page 261 Towing Exceeding these limits may allow water to enter vehicle components: • Causing internal damage to the components. • Affecting driveability, emissions, and reliability. Replace the rear axle lubricant anytime the rear axle has been submerged in water. Water may have contaminated the rear axle lubricant, which is not normally checked or changed unless a leak is suspected or other axle repair is required.
Page 262: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. If the vehicle is towed incorrectly, or by any other means, vehicle damage may occur.
Page 263 Towing Ford Motor Company produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle. Two-wheel drive (2WD) vehicles can be towed with the front wheels on the ground and the rear wheels off the ground.
Page 264: Recreational Towing
Towing Recreational Towing Note: Put your climate control system in recirculated air mode to prevent exhaust fumes from entering the vehicle. See the Climate Control chapter. Follow these guidelines if you have a need for recreational (RV) towing. An example of recreational towing would be towing your vehicle behind a motorhome.
Page 265: Driving Hints
Driving Hints BREAKING-IN You need to break in new tires for approximately 300 mi (480 km). During this time, your vehicle may exhibit some unique driving characteristics. Avoid driving too fast during the first 1000 mi (1600 km). Vary your speed frequently and change up through the gears early. Do not labor the engine.
Page 266 Driving Hints • Add particular accessories to your vehicle (e.g.; bug deflectors, rollbars or light bars, running boards, ski racks). • Drive with the wheels out of alignment. Conditions • Heavily loading a vehicle or towing a trailer may reduce fuel economy at any speed.
Page 267: Floor Mats
Driving Hints If driving through deep or standing water is unavoidable, proceed very slowly. Never drive through water that is higher than the bottom of the hubs (for trucks) or the bottom of the wheel rims (for cars). Once through the water, always try the brakes. Wet brakes do not stop the vehicle as effectively as dry brakes.
Page 268 • To remove the floor mat, reverse the installation procedure. SNOWPLOWING Ford recommends that the Super Duty F-Series used for snow removal includes the snow plow package option. Installing the Snowplow...
Page 269 Note: Do not use your vehicle for snow removal until it has been driven at least 500 miles (800 kilometers). Ford recommends vehicle speed does not exceed 45 mph (72 km/h) when snowplowing. The attached snowplow blade restricts airflow to the radiator, and may...
Page 270 WARNING: Do not attempt to service, repair, or modify the air bag supplemental restraint system (SRS) or its fuses. See your Ford or Lincoln Mercury dealer. WARNING: Additional equipment such as snowplow equipment may effect the performance of the air bag sensors increasing the risk of injury.
Page 271 Ford Super Duty Vehicles are approved for use as a stationary (including split shaft capability) or mobile power source, within limits and operating guidelines detailed in the Ford Truck Body Builders Layout Book, found at www.fleet.ford.com/truckbbas, and through the Ford Truck...
Page 272: Roadside Emergencies
ROADSIDE ASSISTANCE Vehicles Sold in the U.S. : Getting Roadside Assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...
Page 273 U.S. Ford vehicle customers who require Roadside Assistance, call 1-800-241-3673. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest dealership within 35 miles (56 kilometers). To obtain reimbursement information, U.S.
Page 274: Hazard Flasher Control
WARNING: Failure to inspect and if necessary repair fuel leaks after a collision may increase the risk of fire and serious injury. Ford Motor Company recommends that the fuel system be inspected by an authorized dealer after any collision. In the event of a moderate to severe collision, this vehicle is equipped with a fuel pump shut-off feature that stops the flow of fuel to the engine.
Page 275: Jump-Starting The Vehicle
Roadside Emergencies JUMP-STARTING THE VEHICLE WARNING: The gases around the battery can explode if exposed to flames, sparks, or lit cigarettes. An explosion could result in injury or vehicle damage. WARNING: Batteries contain sulfuric acid which can burn skin, eyes and clothing, if contacted. Do not attempt to push-start your automatic transmission vehicle.
Page 276 Roadside Emergencies Connecting the Jumper Cables WARNING: Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped. A spark may cause an explosion of the gases that surround the battery. Note: Do not attach the negative (-) cable to fuel lines, engine rocker covers, the intake manifold or electrical components as grounding points.
Page 277 Roadside Emergencies Jump Starting 1. Start the engine of the booster vehicle and run the engine at a moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
Page 278: Customer Assistance
A reasonable time must be allowed to perform a repair after taking your vehicle to the authorized dealer. Repairs will be made using Ford or Motorcraft parts, or remanufactured or other parts that are authorized by Ford.
Page 279 • The name of the authorized dealer and city where located • The vehicle’s current odometer reading. In some states, you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states.
Page 280 In the case of 1 or 2 above, the consumer must also notify the manufacturer of the need for the repair of the nonconformity at the following address: Ford Motor Company 16800 Executive Plaza Drive Mail Drop 3NE-B Dearborn, MI 48126...
Page 281 BBB Auto Line dispute, and decision, are admissible in the court action. Should you choose to accept the BBB AUTO LINE decision, Ford is then bound by the decision, and must comply with the decision within 30 days of receipt of your acceptance letter.
Page 282 (CANADA ONLY) This pertains to vehicles delivered to authorized Canadian dealers. In those cases, where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation or arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 283 Asia-Pacific Region, Sub-Saharan Africa, U.S. Virgin Islands, Central America, the Caribbean, and Israel, contact the nearest authorized dealer. If the authorized dealer cannot help you, contact: FORD MOTOR COMPANY FORD EXPORT OPERATIONS & GLOBAL INITIATIVES 1555 Fairlane Drive Fairlane Business Park #3 Allen Park, Michigan 48101 U.S.A.
Page 284 If you are in another foreign country, contact the nearest authorized dealer. If the authorized dealer employees cannot help you, they can direct you to the nearest Ford affiliate office. Customers in the U.S. should call 1-800-392-3673. ORDERING ADDITIONAL OWNER’S LITERATURE...
Page 285: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...
Page 286: Fuses
Fuses CHANGING A FUSE Fuses WARNING: Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. If electrical components in the vehicle are not working, a fuse may have blown.
Page 287: Fuse Specification Chart
Fuses FUSE SPECIFICATION CHART Power Distribution Box WARNING: Always disconnect the battery before servicing high current fuses. WARNING: To reduce risk of electrical shock, always replace the cover to the power distribution box before reconnecting the battery or refilling fluid reservoirs. The power distribution box is located in the engine compartment.
Page 288 Fuses Fuse or relay Fuse amp Protected circuits location rating 50A* Rear window defroster, Heated mirrors 30A* Passenger seat 30A* Driver seat — Not used — Not used 30A* Smart window motor — Not used — Not used Diode Fuel pump (diesel engine) —...
Page 289 Fuses Fuse or relay Fuse amp Protected circuits location rating 15A** Vehicle power 4 (diesel engine) 20A** Vehicle power 4 (gas engine) 10A** Vehicle power 5 (diesel engine) Relay Powertrain control module (diesel engine), Electronic control module (gas engine) 10A** 4x4 hub lock 15A** 4x4 electronic lock...
Page 290 Fuses Fuse or relay Fuse amp Protected circuits location rating — Not used — Not used — Not used — Not used — Not used — Not used — Not used 20A** Fuel pump — Not used 10A** Fuel pump relay coil —...
Page 291 Fuses Fuse or relay Fuse amp Protected circuits location rating 20A* Auxiliary power point #6 40A* Starter motor 25A* Trailer tow battery charge — Not used 20A* Auxiliary power point #4 20A* Auxiliary power point #3 25A* Upfitter #1 25A* Upfitter #2 50A* Anti-lock brake system pump...
Page 292 Fuses To remove the fuse panel cover, pull the panel toward you. When the clips of the panel disengage, let the panel fall easily. To remove a fuse, use the fuse puller tool provided on the fuse panel cover. The fuses are coded as follows. Fuse or relay Fuse amp Protected circuits...
Page 293 Fuses Fuse or relay Fuse amp Protected circuits location rating Smart window motor Interior lights, Hood lamp Moonroof Driver seat module 7.5A Driver seat switch, Driver lumbar motor Power mirror switch Upfitter relay #3 Run/accessory relay, Customer access feed Instrument cluster Interior lighting, Lighted running board lamps Right turn signals and brake...
Page 294 Fuses Fuse or relay Fuse amp Protected circuits location rating Steering wheel control module, Diagnostic connector, Power fold mirror relay, Remote keyless entry, Electronic finish panel Not used (spare) Steering wheel control module Not used (spare) Ignition switch SYNC, GPS module, Radio faceplate Parking lamp relay, Trailer tow parking lamp relay...
Page 295: Upfitter Controls
Fuses Fuse or relay Fuse amp Protected circuits location rating 7.5A Passenger airbag deactivation indicator Not used (spare) Wiper relay Upfitter switches Not used (spare) Climate control Fog lamps, Fog lamp indicator (in switch) 30A Circuit Power windows switch, Power Breaker rear sliding window switch Relay...
Page 296 Yellow AUX 2 CAC06 Green with Brown Trace AUX 3 CAC07 Violet with Green Trace AUX 4 CAC08 Brown More detailed information about upfitter switches can be found at https://www.fleet.ford.com/truckbbas/. 2013 F-250/350/450/550 (f23) Owners Guide gf, 1st Printing USA (fus)
Page 297: Maintenance
Have your vehicle serviced regularly to help maintain its roadworthiness and resale value. There is a large network of Ford authorized dealers that are there to help you with their professional servicing expertise. We believe that their specially trained technicians are best qualified to service your vehicle properly and expertly.
Page 298: Opening And Closing The Hood
Maintenance Working with the Engine Off 1. Set the parking brake and shift to P (Park). 2. Turn off the engine and remove the key (if equipped). 3. Block the wheels. Working with the Engine On WARNING: To reduce the risk of vehicle damage or personal burn injuries, do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 299: Under Hood Overview
Maintenance UNDER HOOD OVERVIEW Refer to the diesel supplement for diesel engine component locations. 6.2L V8 Gasoline Engine A. Windshield washer fluid reservoir B. Engine oil dipstick C. Automatic transmission fluid dipstick D. Brake fluid reservoir E. Engine coolant reservoir F.
Page 300 Maintenance 6.8L V10 Gasoline Engine A. Windshield washer fluid reservoir B. Battery C. Automatic transmission fluid dipstick D. Engine oil filler cap E. Engine oil dipstick F. Power steering fluid reservoir G. Brake fluid reservoir H. Engine coolant reservoir I. Air filter assembly J.
Page 301: Engine Oil Dipstick
Maintenance ENGINE OIL DIPSTICK A. – MIN B. – MAX ENGINE OIL CHECK Note: For diesel engine information, refer to the diesel supplement. Refer to the scheduled maintenance information for the appropriate intervals for checking the engine oil. 1. Make sure the vehicle is on level ground. 2.
Page 302: Engine Coolant Check
Note: For best results, coolant concentration should be tested with a refractometer such as Rotunda tool 300-ROB75240 available from your dealer. Ford does not recommend the use of hydrometers or coolant test strips for measuring coolant concentrations. Note: Coolant expands when it is hot. The level may extend beyond the MAX mark.
Page 303 Maintenance Adding Engine Coolant WARNING: Do not add engine coolant when the engine is hot. Steam and scalding liquids released from a hot cooling system can burn you badly. Also, you can be burned if you spill coolant on hot engine parts.
Page 304 Severe Climates If you drive in extremely cold climates: • It may be necessary to have a Ford authorized dealer increase the coolant concentration above 50%. • A coolant concentration of 60% will provide improved freeze point protection.
Page 305 Maintenance What You Should Know About Fail-Safe Cooling (If Equipped) WARNING: If fail-safe cooling activates, pull off the road as soon as safely possible and turn the engine off. The engine may automatically shut off while driving without further indication. If the engine coolant supply is depleted, this feature allows the vehicle to be driven temporarily before incremental component damage is incurred.
Page 306 Maintenance You have limited engine power when in the fail-safe mode, so drive the vehicle with caution. The vehicle will not be able to maintain high-speed operation and the engine will run rough. Remember that the engine is capable of completely shutting down automatically to prevent engine damage;...
Page 307: Automatic Transmission Fluid Check
Maintenance If you notice any of the following: • the engine coolant temperature gauge moves fully into the red (hot) area • the coolant temperature warning light illuminates • the service engine soon indicator illuminates 1. Pull off the road as soon as safely possible and place the vehicle in P (Park).
Page 308 Maintenance 3. With the engine running, parking brake engaged and your foot on the brake pedal, move the gearshift lever through all of the gear ranges. Allow sufficient time for each gear to engage. 4. Latch the gearshift lever in P (Park) and leave the engine running. 5.
Page 309 Maintenance Correct Fluid Level For vehicles equipped with 5-speed transmissions, the fluid should be checked at normal operating temperature 150°F-170°F (66°C-77°C) on a level surface. For vehicles equipped with 6-speed transmissions, the fluid should be checked at normal operating temperature 196°F-216°F (91°C-102°C) on a level surface.
Page 310 Maintenance Adjusting Automatic Transmission Fluid Levels Note: Use of a non-approved automatic transmission fluid may cause internal transmission component damage. Before adding any fluid, make sure the correct type is used. The type of fluid used is normally indicated on the dipstick handle and also in the Capacities and Specifications chapter.
Page 311 3. Add only enough fluid through the filler opening so that the fluid level is at the bottom of the opening. Use only fluid that meets Ford specifications. Refer to the Capacities and Specifications section . 2013 F-250/350/450/550 (f23) Owners Guide gf, 1st Printing...
Page 312: Brake Fluid Check
Maintenance BRAKE FLUID CHECK Fluid levels between the MIN and MAX lines are within the normal operating range; there is no need to add fluid. If the fluid levels are outside of the normal operating range, the performance of the system could be compromised;...
Page 313: Washer Fluid Check
Add fluid to fill the reservoir if the level is low. Only use a washer fluid that meets Ford specifications. See the technical specifications chart in the Capacities and Specifications chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive.
Page 314 Maintenance WARNING: Keep batteries out of reach of children. Batteries contain sulfuric acid. Avoid contact with skin, eyes or clothing. Shield your eyes when working near the battery to protect against possible splashing of acid solution. In case of acid contact with skin or eyes, flush immediately with water for a minimum of 15 minutes and get prompt medical attention.
Page 315 Maintenance 3. Run the engine until it reaches normal operating temperature. 4. Allow the engine to idle for at least one minute. 5. Turn the A/C on and allow the engine to idle for at least one minute. 6. Release the parking brake. With your foot on the brake pedal and with the A/C on, put the vehicle in D (Drive) and allow the engine to idle for at least one minute.
Page 316: Checking The Wiper Blades
When a battery replacement is required, the battery should only be replaced with a Ford recommended replacement battery which matches the electrical requirements of the vehicle. After battery replacement, or in some cases after charging the battery with the external charger, the BMS requires eight hours of vehicle sleep time (key off with doors closed) to relearn the new battery state of charge.
Page 317 Maintenance CHANGING THE WIPER BLADES 1. To remove the wiper blade, pull the wiper arm away from the vehicle. Pry open the lock cover (A) with your thumb to release the blade. 2. Press the retaining clip to disengage the wiper blade, then pull the wiper blade down (C) toward the windshield to remove it from the arm.
Page 318: Air Filter(S)
Maintenance AIR FILTER CHECK Refer to Scheduled Maintenance Information for the appropriate intervals for changing the air filter element. When changing the air filter element, use only the Motorcraft® air filter element listed. Refer to the Motorcraft® Part Numbers. The following procedure is for vehicles equipped with a gasoline engine. If your vehicle is equipped with a diesel engine, refer to the diesel supplement.
Page 319 Maintenance 3. Clean the area around the air tube to air cover connection to prevent debris from entering the system and then loosen the bolt on the air tube clamp so the clamp is no longer snug to the air tube. It is not necessary to completely remove the clamp.
Page 320: Adjusting The Headlamps
Maintenance 10. Reconnect the mass air flow sensor electrical connector to the outlet tube. Make sure the locking tab on the connector is in the “locked” position (connector shown from below for clarity). ADJUSTING THE HEADLAMPS The headlamps on your vehicle are properly aimed at the assembly plant. If your vehicle has been in an accident, the alignment of your headlamps should be checked by your authorized dealer.
Page 321: Changing A Bulb
Maintenance 4. On the wall or screen you will observe a light pattern with a distinct horizontal edge towards the right. If this edge is not at the horizontal reference line, the beam will need to be adjusted so the edge is at the same height as the horizontal reference line.
Page 322 Maintenance These are examples of unacceptable moisture (usually caused by a lamp water leak): • Water puddle inside the lamp. • Large water droplets, drip marks or streaks present on the interior of the lens. Take your vehicle to a dealer for service if any of the above conditions of unacceptable moisture are present.
Page 323 Maintenance 10. For the headlamp bulb, remove the bulb by turning it counterclockwise and pulling it straight out. 11. For the park or turn lamp bulb, remove the bulb by turning it counterclockwise and pulling it straight out. WARNING: Handle a halogen headlamp bulb carefully and keep out of children’s reach.
Page 324 Maintenance Replacing Front Clearance and Identification Lamp Bulbs (If Equipped) 1. Make sure the headlamps are off. 2. Remove the screw and lens from the lamp assembly. 3. Pull the bulb straight out of the socket. Install the bulb(s) in reverse order. Replacing Fog Lamp Bulbs (If Equipped) 1.
Page 325 Maintenance Replacing Brake/Tail/Turn/Reverse Lamp Bulbs (Pickups Only) 1. Make sure the headlamps are off, then open the tailgate to expose the lamp assemblies. 2. Remove the two bolts from the tail lamp assembly and carefully pull the lamp assembly from the tailgate pillar by releasing the two retaining tabs.
Page 326: Bulb Specification Chart
Maintenance Replacing License Plate Lamp Bulbs The license plate bulbs are located behind the rear bumper. To change the license plate lamp bulbs: 1. Reach behind the rear bumper to locate the bulb. 2. Twist the bulb socket counterclockwise and carefully pull to remove it from the lamp assembly.
Page 327 Maintenance Function Number Trade number of bulbs Map lamp 12V6W Dome/reading lamps Interior visor lamp (if equipped) Mirror turn signal 2825 Mirror clearance lamp 2825 * Front clearance lamps (2) and front identification lamps (3) * Rear fender clearance LED** * Rear identification 193** Underhood Lamp...
Page 328: Vehicle Care
Vehicle Care GENERAL INFORMATION Your Ford or Lincoln authorized dealer has many quality products available to clean your vehicle and protect its finishes. CLEANING PRODUCTS For best results, use the following products or products of equivalent quality: Motorcraft® Bug and Tar Remover (ZC-42) Motorcraft®...
Page 329 Vehicle Care • Dry the vehicle with a chamois or soft, terry cloth towel in order to eliminate water spotting. • It is especially important to wash the vehicle regularly during the winter months, as dirt and road salt are difficult to remove and cause damage to the vehicle.
Page 330: Waxing
Vehicle Care Cleaning Plastic Exterior Parts Use only approved products to clean plastic parts. • For routine cleaning, use Motorcraft® Detail Wash. • If tar or grease spots are present, use Motorcraft® Bug and Tar Remover. WAXING • Wash the vehicle first. •...
Page 331: Cleaning The Windows And Wiper Blades
Vehicle Care CLEANING THE WINDOWS AND WIPER BLADES The windows and wiper blades should be cleaned regularly. If the wipers do not wipe properly, substances on the vehicle’s glass or the wiper blades may cause squeaking or chatter noise from the blades, and streaking and smearing of the windshield.
Page 332: Cleaning The Instrument Panel And Instrument Cluster Lens
Vehicle Care For fabric, carpets, cloth seats, safety belts and seats equipped with side airbags: • Remove dust and loose dirt with a vacuum cleaner. • Remove light stains and soil with Motorcraft® Professional Strength Carpet & Upholstery Cleaner. • If grease or tar is present on the material, spot-clean the area first with Motorcraft®...
Page 333 Vehicle Care If a staining liquid like coffee or juice has been spilled on the instrument panel or on interior trim surfaces, clean as follows: 1. Wipe up spilled liquid using a clean, white, cotton cloth. 2. Wipe the surface with a damp, clean, white, cotton cloth. For more thorough cleaning, use a mild soap and water solution.
Page 334 Vehicle Care Low gloss paint area The low gloss area of the instrument panel’s upper dash should be cleaned with mild, soapy water and a soft, damp cloth, then dried with a clean, dry cloth. When cleaning the low gloss areas: •...
Page 335: Cleaning The Alloy Wheels
Vehicle Care For routine cleaning, wipe the surface with a soft, damp cloth. For more thorough cleaning, wipe the surface with a mild soap and water solution. • Clean spills as quickly as possible. • Test any cleaner or stain remover on an inconspicuous part of the leather as cleaners may darken the leather.
Page 336: Vehicle Storage
Vehicle Care • Never apply any cleaning chemical to hot or warm wheel rims or covers. • Some automatic car washes may cause damage to the finish on your wheel rims or covers. Industrial-strength (heavy-duty) cleaners, or cleaning chemicals, in combination with brush agitation to remove brake dust and dirt, could wear away the clear coat finish over time.
Page 337 Vehicle Care Engine • The engine oil and filter should be changed prior to storage, as used engine oil contains contaminates that may cause engine damage. • Start the engine every 15 days. Run at fast idle until it reaches normal operating temperature.
Page 338 Vehicle Care Miscellaneous • Make sure all linkages, cables, levers and pins under vehicle are covered with grease to prevent rust. • Move vehicles at least 25 ft (8 m) every 15 days to lubricate working parts and prevent corrosion. Removing Vehicle from Storage When your vehicle is ready to come out of storage, do the following: •...
Page 339: Wheels And Tires
Wheels and Tires GENERAL INFORMATION Notice to Utility Vehicle, Van and Truck Owners WARNING: Utility vehicles have a significantly higher rollover rate than other types of vehicles. To reduce the risk of serious injury or death from a rollover or other collision you must: •...
Page 340 Wheels and Tires Four-Wheel Drive System (If Equipped) WARNING: Do not become overconfident in the ability of four-wheel drive vehicles. Although a four-wheel drive vehicle may accelerate better than two-wheel drive vehicle in low traction situations, it will not stop any faster than two-wheel drive vehicles. Always drive at a safe speed.
Page 341 Wheels and Tires How Your Vehicle Differs from Other Vehicles Sport-utility vehicles, vans and trucks can differ from some other vehicles in a few noticeable ways. Your vehicle may be: • Higher – to allow higher load carrying capacity and to allow it to travel over rough terrain without getting hung up or damaging underbody...
Page 342: Tire Care
10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 343 Wheels and Tires Traction AA A B C WARNING: The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. The traction grades, from highest to lowest are AA, A, B, and C. The grades represent the tire’s ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete.
Page 344 Wheels and Tires • Inflation pressure: A measure of the amount of air in a tire. • Standard load: A class of P-metric or Metric tires designed to carry a maximum load at 35 psi [37 psi (2.5 bar) for Metric tires]. Increasing the inflation pressure beyond this pressure will not increase the tire’s load carrying capability.
Page 345 Wheels and Tires INFORMATION CONTAINED ON THE TIRE SIDEWALL Both U.S. and Canada Federal regulations require tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire and also provides a U.S. DOT Tire Identification Number for safety standard certification and in case of a recall.
Page 346 Wheels and Tires E. 15: Indicates the wheel or rim diameter in inches. If you change your wheel size, you will have to purchase new tires to match the new wheel diameter. F. 95: Indicates the tire’s load index. It is an index that relates to how much weight a tire can carry.
Page 347 Wheels and Tires H. U.S. DOT Tire Identification Number (TIN): This begins with the letters DOT and indicates that the tire meets all federal standards. The next two numbers or letters are the plant code designating where it was manufactured, the next two are the tire size code and the last four numbers represent the week and year the tire was built.
Page 348 Wheels and Tires M. Maximum Inflation Pressure: Indicates the tire manufacturers’ maximum permissible pressure and/or the pressure at which the maximum load can be carried by the tire. This pressure is normally higher than the manufacturer’s recommended cold inflation pressure which can be found on the Safety Compliance Certification Label (affixed to either the door hinge pillar, door-latch post, or the door edge that meets the door-latch post, next to the driver’s seating position), or Tire...
Page 349 Wheels and Tires Information on T Type Tires T type tires have some additional information beyond those of P type tires. These differences are described below. T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 350 You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
Page 351 Note: Do not reduce tire pressure to change the ride characteristics of the vehicle. If you do not maintain the inflation pressure at the levels specified by Ford, your vehicle may experience a condition known as shimmy. Shimmy is a severe vibration and oscillation in the steering wheel after the vehicle travels over a bump or dip in the road that does not dampen out by itself.
Page 352 Wheels and Tires 2. Remove the cap from the valve on one tire, then firmly press the tire gauge onto the valve and measure the pressure. 3. Add enough air to reach the recommended air pressure. Note: If you overfill the tire, release air by pushing on the metal stem in the center of the valve.
Page 353 Wheels and Tires WARNING: Stay out of the trajectory (1) as indicated in the illustration. 2013 F-250/350/450/550 (f23) Owners Guide gf, 1st Printing USA (fus)
Page 354 Wheels and Tires Inspecting Your Tires and Wheel Valve Stems Periodically inspect the tire treads for uneven or excessive wear and remove objects such as stones, nails or glass that may be wedged in the tread grooves. Check the tire and valve stems for holes, cracks, or cuts that may permit air leakage and repair or replace the tire and replace the valve stem.
Page 355 Wheels and Tires Damage Periodically inspect the tire treads and sidewalls for damage (such as bulges in the tread or sidewalls, cracks in the tread groove and separation in the tread or sidewall). If damage is observed or suspected, have the tire inspected by a tire professional. Tires can be damaged during off-road use, so inspection after off-road use is also recommended.
Page 356 B-Pillar or edge of the driver’s door. If this information is not found on these labels then you should contact your authorized dealer as soon as possible. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 357 The tire pressure sensors mounted in the wheels are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your tire pressure monitoring system(if equipped).
Page 358 Wheels and Tires Tire and Wheel Alignment A bad jolt from hitting a curb or pothole can cause the front end of your vehicle to become misaligned or cause damage to your tires. If your vehicle seems to pull to one side when you are driving, the wheels may be out of alignment.
Page 359 Wheels and Tires Rotating your tires at the recommended interval (as indicated in the scheduled maintenance information) will help your tires wear more evenly, providing better tire performance and longer tire life. • Rear-wheel drive vehicles/Four-wheel drive vehicles (front tires at top of diagram) •...
Page 360 USING SNOW CHAINS WARNING: Snow tires must be the same size, load index, speed rating as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 361: Tire Pressure Monitoring System (Tpms)
Wheels and Tires TIRE PRESSURE MONITORING SYSTEM WARNING: The tire pressure monitoring system is not a substitute for manually checking tire pressure. The tire pressure should be checked periodically (at least monthly) using a tire gauge. See Inflating Your Tires in this chapter. Failure to properly maintain your tire pressure could increase the risk of tire failure, loss of control, vehicle rollover and personal injury.
Page 362 Wheels and Tires vehicle to ensure that the replacement or alternate tires and wheels allow the system to continue to function properly. The tire pressure monitoring system complies with part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 363 Wheels and Tires When you believe your system is not operating properly The main function of the tire pressure monitoring system is to warn you when your tires need air. It can also warn you in the event the system is no longer capable of functioning as intended.
Page 364 Wheels and Tires Low tire Possible cause Customer action required pressure warning light Flashing warning Spare tire in use Repair the damaged road wheel and light tire and reinstall it on the vehicle to restore system function. For a description on how the system functions, see When your temporary spare tire is installed in this section.
Page 365 • To reduce the chances of interference from another vehicle, the system reset procedure should be performed at least three feet (one meter) away from another Ford Motor Company vehicle undergoing the system reset procedure at the same time. • Do not wait more than two minutes between resetting each tire sensor or the system will time-out and the entire procedure will have to be repeated on all four wheels.
Page 366 Wheels and Tires Performing the System Reset Procedure Read the entire procedure before attempting. 1. Drive the vehicle above 20 mph (32 km/h) for at least two minutes and then park in a safe location where you can easily get to all four tires and have access to an air pump.
Page 367: Changing A Road Wheel
However, if you must use a sealant, the tire pressure monitoring system sensor and valve stem on the wheel must be replaced by an authorized Ford dealer. WARNING: See Tire Pressure Monitoring System in this chapter for important information.
Page 368 Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 369 Wheels and Tires 3. Full-size dissimilar spare without label on wheel When driving with the full-size dissimilar spare tire and wheel assembly, do not: • exceed 70 mph (113 km/h). • use more than one dissimilar spare tire and wheel at a time. •...
Page 370 Wheels and Tires Tool Location Jack handle, lug wrench, lug wrench Regular cab: Fastened to floor extension (only available on Dual behind driver seat Rear Wheel [DRW] vehicles) and SuperCab: Fastened to floor under wheel chock (only available on rear seat Single Rear Wheel [SRW] vehicles Crew Cab: Fastened to floor behind equipped with a diesel engine)
Page 371 Wheels and Tires 2. Attach the spare tire lock key (A) to the jack handle (B). 3. Fully insert the jack handle (with one extension) through the bumper hole and into the guide tube. The key and lock will engage with a slight push and counterclockwise turn.
Page 372: Tire Change Procedure
Wheels and Tires Tire Change Procedure WARNING: When one of the front wheels is off the ground, the transmission alone will not prevent the vehicle from moving or slipping off the jack, even if the transmission selector lever is in position P.
Page 373 Wheels and Tires 1. Turn the engine off and block the wheel that is diagonally opposite of the flat tire using the wheel chock, if equipped. Note: If the vehicle is a 4x4, lock the manual hub on the wheel. 2.
Page 374 Wheels and Tires • Front driver side (4x4) Note: Make sure the jack fits onto the flat area on the outboard side of the differential. • Front passenger side (4x4) Note: View shown from the rear of the vehicle to clearly identify the jack point.
Page 375 Wheels and Tires 7. Turn the jack handle clockwise until the wheel is completely off the ground and high enough to install the spare tire. 8. Remove the lug nuts with the lug wrench. 9. Replace the flat tire with the spare tire, making sure the valve stem is facing outward for all front wheels and single rear wheel vehicles.
Page 376 Wheels and Tires • Front driver side (4x4): F–350 Note: Make sure the jack fits onto the flat area on the outboard side of the differential housing. • Front passenger side (4x4): F-350 DRW Note: View shown from the rear of the vehicle to clearly identify the jack point.
Page 377 Wheels and Tires • Rear: F-450/F-550 13. Insert the jack handle into the pump linkage. 14. Use an up-and-down motion with the jack handle to raise the wheel completely off the ground. Note: Hydraulic jacks are equipped with a pressure release valve that prevents lifting loads which exceed the jack’s rated capacity.
Page 378 Wheels and Tires Note: The following steps apply to all vehicles: 18. Remove the jack and fully tighten the lug nuts in the order shown. See Wheel lug nut torque specifications in this chapter for the proper lug nut torque specification.
Page 379 Wheels and Tires If the ornament retention towers are aligned between the studs or lug nuts, the ornament is improperly installed. This improper installation may appear and sound correct, but will not keep the ornament on the vehicle. Ornaments improperly installed in this manner will fall off or become loose with minimal force or impact.
Page 380: Stowing The Flat/Spare Tire
Wheels and Tires 4. Be sure to install all the clips on the nuts over the flanges so that there is an even gap all around and the retention clips are fully seated. Stowing the flat/spare tire Note: Failure to follow spare tire stowage instructions may result in failure of cable or loss of spare tire.
Page 381: Technical Specifications
Wheels and Tires 3. Lay the tire on the ground with the valve stem facing up. 4. Slide the wheel partially under the vehicle and install the retainer through the wheel center. Pull on the cable to align the components at the end of the cable.
Page 382 N•m M14 x 1.5 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. It is important to follow the proper wheel mounting and lug nut torque procedures. On all two-piece flat wheel nuts, apply one drop of motor oil between the flat washer and the nut.
Page 383: Capacities And Specifications
Capacities and Specifications ENGINE SPECIFICATIONS Engine 6.2L V8 engine 6.8L V10 engine Cubic inches Minimum 87 octane or Minimum 87 octane Required fuel Ethanol (E85) Firing order 1-5–4–8–6–3–7–2 1-6-5-10-2-7-3-8-4-9 0.041–0.047 inch 0.039–0.043 inch Spark plug gap (1.04–1.20 mm) (1.0–1.1 mm) Ignition system Coil on plug Coil on plug...
Page 384 Capacities and Specifications 6.8L V10 engine - without A/C 2013 F-250/350/450/550 (f23) Owners Guide gf, 1st Printing USA (fus)
Page 385 Capacities and Specifications 2013 F-250/350/450/550 (f23) Owners Guide gf, 1st Printing USA (fus)
Page 386 Capacities and Specifications 2013 F-250/350/450/550 (f23) Owners Guide gf, 1st Printing USA (fus)
Page 387 Capacities and Specifications 2013 F-250/350/450/550 (f23) Owners Guide gf, 1st Printing USA (fus)
Page 388 Capacities and Specifications 2013 F-250/350/450/550 (f23) Owners Guide gf, 1st Printing USA (fus)
Page 389: Part Numbers
Note: Replace the spark plugs with ones that meet Ford material and design specifications for your vehicle, such as Motorcraft® or equivalent replacement parts. The customer warranty may be void for any damage to the engine if such spark plugs are not used.
Page 390: Vehicle Identification Number
Capacities and Specifications VEHICLE IDENTIFICATION NUMBER The vehicle identification number is located on the driver side instrument panel. XXXXXXXXXXXXXXXXX Please note that in the graphic, XXXX is representative of your vehicle identification number. The Vehicle Identification Number (VIN) contains the following information: A.
Page 391: Vehicle Certification Label
Capacities and Specifications VEHICLE CERTIFICATION LABEL The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label shall be affixed to either the door hinge pillar, the door latch post, or the edge of the door near the door latch, next to the...
Page 392: Accessories
Accessories.Ford.com (U.S. only). Ford Custom Accessories are available for your vehicle through your local Ford or Ford of Canada dealer. Ford Motor Company will repair or replace any properly dealer-installed Ford Custom Accessories found to be defective in factory-supplied materials or workmanship during the warranty period, as well as any component damaged by the defective accessories.
Page 393 Ford Motor Company engineering requirements. Contact your Ford dealer for details regarding the manufacturer’s limited warranty and/or a copy of the FLA product limited warranty offered by the accessory manufacturer.
Page 394: Ford Extended Service Plan
BaseCare – Covers 84 components. PowertrainCare – Covers 29 critical components. Ford ESP is honored by all Ford and Lincoln Dealers in the U.S. and Canada. It is the only extended service plan authorized and backed by Ford Motor Company. That means you get: •...
Page 395 Protect Yourself from the Rising Cost of Vehicle Repairs with a Ford Extended Service Plan To learn more, call our Ford ESP specialists at 800–367–3377, and do not forget to ask about our interest free payment program, allowing you all the security and benefits Ford ESP has to offer while paying over time.
Page 396 Ford ESP coverage. This information is subject to change. For more information, visit your local Ford of Canada dealer or www.ford.ca to find the Ford Extended Service Plan that is right for you. 2013 F-250/350/450/550 (f23) Owners Guide gf, 1st Printing...
Page 397: Scheduled Maintenance
Motor Company’s specifications. Parts installed at your dealership carry a nationwide, 12 month/12000 mile (20000 kilometer) parts and labor limited warranty. If you do not use Ford authorized parts, they may not meet Ford specifications and, depending on the part, it could affect emissions compliance.
Page 398 Ford Motor Company has recommended maintenance intervals for various parts and component systems based upon engineering testing. Ford Motor Company relies upon this testing to determine the most appropriate mileage for replacement of oils and fluids to protect your vehicle at the lowest overall cost to you and recommends against maintenance schedules that deviate from the scheduled maintenance information.
Page 399 Scheduled Maintenance Owner Checks and Services Certain basic maintenance checks and inspections should be performed every month or at six month intervals. Check Every Month Engine oil level. Function of all interior and exterior lights. Tires (including spare) for wear and proper pressure. Windshield washer fluid level.
Page 400 In order to keep your vehicle running right, it is important to have the systems on your vehicle checked regularly. This can help identify potential issues and prevent major problems. Ford Motor Company recommends the following multi-point inspection be performed at every scheduled maintenance interval to help make sure your vehicle keeps running great.
Page 401 Scheduled Maintenance 2013 F-250/350/450/550 (f23) Owners Guide gf, 1st Printing USA (fus)
Page 402: Normal Scheduled Maintenance And Log
Scheduled Maintenance NORMAL SCHEDULED MAINTENANCE AND LOG Normal Scheduled Maintenance – 6.2L and 6.8L Engines Only Every 7500 miles Change engine oil and filter. (12000 km) or six Rotate tires , inspect tire wear and measure months (whichever tread depth. comes first) Inspect wheels and related components for abnormal noise, wear, looseness or drag.
Page 403 Scheduled Maintenance Additional Maintenance Items Every 30000 miles Replace climate-controlled (heated and (48000 km) cooled) seat filter (if equipped). Replace engine air filter. Every 60000 miles Change automatic transmission fluid and filter (96000 km) on 5–speed transmission. Consult dealer for requirements.
Page 404 Scheduled Maintenance Maintenance Schedule Log EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS...
Page 405 Scheduled Maintenance EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE...
Page 406 Scheduled Maintenance EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE...
Page 407 Scheduled Maintenance SPECIAL OPERATING CONDITIONS – 6.2L AND 6.8L ENGINES ONLY Note: If your vehicle is equipped with the 6.7L diesel engine, see the diesel supplement for special operating condition maintenance. If you operate your vehicle primarily in one of the more demanding conditions listed below, you need to have some items maintained more frequently.
Page 408 Scheduled Maintenance Extensive Idling or Low-speed Driving for Long Distances as in Heavy Commercial Use (i.e., Delivery, Taxi, Patrol Car or Livery) Every 5000 miles Change engine oil and filter. (8000 km) or six Inspect and lubricate U-joints. months Every 30000 miles Replace front wheel bearing grease and grease (48000 km) seals if non-sealed bearings are used.
Page 409 Scheduled Maintenance Off-road Operation Inspect frequently, Inspect steering linkage, ball joints and U-joints, service as required Lubricate if equipped with grease fittings. Replace engine air filter. Every 5000 miles Change engine oil and filter. (8000 km) or six Inspect the wheels and related components for months abnormal noise, wear, looseness or drag.
Page 410 Scheduled Maintenance Special Operating Condition Log EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#:...
Page 411 Scheduled Maintenance EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE...
Page 412 Normal vehicle axle maintenance: Rear axles and power take-off (PTO) units with synthetic fluid and light-duty trucks equipped with Ford-design axles are lubricated for life; do not check or change fluid unless a leak is suspected, service is required or the assembly has been submerged in water.
Page 413: Engine Coolant Change Log
Scheduled Maintenance ENGINE COOLANT CHANGE RECORD Initial change Six years or 105000 miles (168000 km) (whichever comes first) After initial change Every three years or 45000 miles (72000 km) Engine Coolant Change Log EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS...
Page 414: Sync
SYNC® SYNC is an in-vehicle communications system that works with your Bluetooth-enabled cellular phone and portable media player. This allows you to: • Make and receive calls. • Access and play music from your portable music player. • Use 911 Assist®, Vehicle Health Report and SYNC Services (Traffic, Directions &...
Page 415 Safety Information WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
Page 416 Master Reset to erase all stored information. System data cannot be accessed without special equipment and access to the vehicle’s SYNC module. Ford Motor Company and Ford of Canada do not access the system data for any purpose other than as described...
Page 417 SYNC® USING VOICE RECOGNITION This system helps you control many features using voice commands. This allows you to keep your hands on the wheel and focus on what is in front of you. Initiating a Voice Session Push the voice icon; a tone sounds and Listening appears in the display.
Page 418 SYNC® Adjusting the Interaction Level Push the voice icon; when prompted, say “Voice settings”, then any of the following: When you say: The system: “Interaction mode standard” Provides more detailed interaction and guidance. “Interaction mode advanced” Provides less audible interaction and more tone prompts.
Page 419: Pairing Your Phone For The First Time
SYNC® • Speak naturally, without long pauses between words. • At any time you can interrupt the system while it is speaking by pressing the voice icon. USING SYNC WITH YOUR PHONE Hands-free calling is one of the main features of SYNC. While the system supports a variety of features, many are dependent on your cellular phone’s functionality.
Page 420 SYNC® 6. The display indicates when the pairing is successful. 7. Depending on your phone’s capability and your market, the system may prompt you with questions such as setting the current phone as the primary phone (the phone SYNC automatically tries to connect with first upon vehicle start-up), downloading your phone book, etc.
Page 421 SYNC® “PHONE” “Menu” “Join” “Call <name> at home” “Call <name> at work” OR “Call <name> in office” “Dial” “Phone book <name>” “Phone book <name> at work” OR “Phone book <name> at office” “Call history incoming” “Connections” “Go to privacy” “Hold” These commands do not require you to say “Phone”...
Page 422 SYNC® Phone book commands: When you ask SYNC® to access a phone book name, number, etc., the requested information appears in the display to view. Press the phone button and say “Call” to call the contact. “DIAL” “411” (four-one-one), “911” (nine-one-one), etc. “700 (seven hundred)”...
Page 423 SYNC® Phone Options during an Active Call During an active call, you have additional menu features which become available such as putting a call on hold, joining calls, etc. Use the arrow buttons to scroll through the menu options. To access: 1.
Page 424 SYNC® When you select: You can: Call History Access your call history log. 1. Press OK to select, then scroll through your call history options (incoming, outgoing or missed). 2. Press OK when the desired selection appears in the display. 3.
Page 425 SYNC® When you select: You can: Allows you to access your downloaded phonebook. Phonebook 1. Press OK to confirm and enter. If your phonebook has fewer than 255 listings, they appear alphabetically in flat file mode. If there are more, they are organized into alphabetical categories.
Page 426 SYNC® Text Messaging Note: This is a phone-dependent feature. SYNC allows you to receive, send, download and delete text messages. The system can also read incoming text messages to you so that you do not have to take your eyes off the road. Receiving a Text Message Note: This is a phone-dependent feature.
Page 427 6. Press OK when the contact appears and press OK again to confirm when the system asks if you would like to send the message. Each text message is sent with the following signature: “This message was sent from my <Ford or Lincoln>”. Pre-defined text message options Can’t talk right now...
Page 428 SYNC® Pre-defined text message options I need more directions I love you Too funny Can’t wait to see you I’m stuck in traffic Accessing Your Phone Settings These are phone-dependent features. Your phone settings allow you to access and adjust features such as your ring tone, text message notification, modify your phone book and also set up automatic download.
Page 429 SYNC® When you select: You can: Modify the contents of your phone book (i.e., Modify Phonebook add, delete, download). Press OK to select and scroll between: Add Contacts: Press OK to add more contacts from your phone book. Push the desired contact(s) on your phone.
Page 430 SYNC® System Settings System Settings provide access to your Bluetooth Devices and Advanced menu features. Use the arrow buttons to scroll through the menu options. The Bluetooth Devices menu allows you to add, connect, delete and set a phone as primary as well as turn your Bluetooth feature on and off. The Advanced menu allows you to access and set prompts, languages, defaults, perform a master reset, install an application and view system information.
Page 431 SYNC® If you select: You can: Set Bluetooth On/Off Turn the Bluetooth feature on and off. Press OK and scroll to toggle between On and Off. When the desired selection is chosen, press OK. Note: Turning Bluetooth off disconnects all Bluetooth devices and deactivates all Bluetooth features.
Page 432 SYNC® If you select: You can: Languages Choose between English, Espanol and Francais. Once selected, all of SYNC’s radio displays and prompts are in the selected language. 1. Press OK to select and then scroll through the languages. 2. Press OK when the desired selection appears in the display.
Page 433: Assist
SYNC® SYNC APPLICATIONS AND SERVICES (IF EQUIPPED) Note: In order for the following features to work, your cellular phone must be compatible with SYNC. To check your phone’s compatibility, visit www.SYNCMyRide.com, www.SYNCMyRide.ca or www.syncmaroute.ca. • SYNC Services (if equipped, U.S. only): Provides access to traffic, directions and information such as travel, horoscopes, stock prices and more.
Page 434 SYNC® Note: Every phone operates differently. While SYNC 911 Assist works with most cellular phones, some may have trouble using this feature. If a crash deploys an airbag (excludes knee airbags and rear inflatable safety belts [if equipped]) or activates the fuel pump shut-off, your SYNC equipped vehicle may be able to contact emergency services by dialing 911 through a paired and connected Bluetooth-enabled phone.
Page 435 SYNC® In the Event of a Crash Not all crashes deploy an airbag or activate the fuel pump shut-off (which would activate 911 Assist); however, if 911 Assist is triggered, SYNC tries to contact emergency services. If a connected phone is damaged or loses connection to SYNC, SYNC searches for, and tries to connect to, any available previously paired phone and tries to make the call to 911.
Page 436: Vehicle Health Report
SYNC® Vehicle Health Report WARNING: Always follow scheduled maintenance instructions, regularly inspect your vehicle, and seek repair for any damage or problem you suspect. Vehicle Health Report supplements, but cannot replace normal maintenance and vehicle inspection. Vehicle Health Report only monitors certain systems that are electronically monitored by the vehicle and will not monitor or report the status of any other system, (i.e., brake lining wear).
Page 437 Certain versions or updates to Vehicle Health Report may also collect additional vehicle information. Ford may use the vehicle information it collects for any purpose. If you do not want to disclose your cellular phone number or vehicle information, do not run the feature or set up your Vehicle Health Report profile at www.SYNCMyRide.com.
Page 438 For more information, see SYNC Services Terms and Conditions at www.SYNCMyRide.com. If you do not want Ford or its service providers to collect the vehicle travel information or other information identified in the Terms and Conditions, do not activate or use the service.
Page 439 SYNC® 3. Once you are connected to the service, follow the voice prompts to request the desired service, such as “Traffic” or “Directions”. You can also say “What are my choices?” to receive a complete list of available services from which to choose. 4.
Page 440 SYNC® If you miss a turn, SYNC automatically asks if you want the route updated. Just say, “Yes” when prompted and a new route will be delivered to your vehicle. Disconnecting from SYNC Services 1. Press and hold the phone button on the steering wheel. 2.
Page 441 SYNC® SYNC AppLink™ Note: Your smartphone must be paired and connected to SYNC to access AppLink. Note: iPhone® users need to connect the phone to the USB port in order to start the application. It is recommended to lock your iPhone® after starting an application.
Page 442 SYNC® To Access Using Voice Commands 1. Press the voice icon. 2. When prompted, say “Mobile Apps”. 3. Say the name of the application after the tone. 4. The app should start. While an app is running through SYNC, you can press the voice button and speak commands specific to the app, such as “Play Station Quickmix”.
Page 443 SYNC® 6. Press OK and scroll through selections of: • Play All • Artists • Albums • Genres • Playlists • Tracks • Explore USB • Similar Music • Return When the desired selection appears in the display, press OK to build your desired music selection.
Page 444 SYNC® “USB” “Play song <name>” “Play track <name>” “Refine album <name>” “Refine artist <name>” “Refine song <name>” “Refine track <name>” “Repeat off” “Repeat on” “Search album <name>” “Search artist <name>” “Search genre <name>” “Search song <name>” “Search track <name>” “Shuffle off” “Shuffle on”...
Page 445 SYNC® Voice Command Guide “Autoplay” Turn on to listen to music which has already been randomly indexed during the indexing process. Turn off and the system does not begin to play any of your music until all media has all been indexed.
Page 446 SYNC® Media Menu Features The media menu allows you to select your media source, how to play your music (by artist, genre, shuffle, repeat, etc.), and also to add, connect or delete devices. 1. Press AUX and then MENU to enter the Media Menu. 2.
Page 447 SYNC® When you select: You can: Choose to shuffle or repeat your music and select Media Settings your Autoplay settings. Once these selections are turned on, they remain on until turned off. Press SEEK to play the previous or next track. Note: Some digital media players require both USB and line in ports to stream data and music separately.
Page 448 SYNC® If there are no media files to access, the display indicates there is no media. If there are media files, you have the following options to scroll through and select from: When you select: You can: Play All Play all indexed media (tracks) from your playing device in flat file mode, one at a time in numerical order.
Page 449 SYNC® When you select: You can: Access your playlists (from formats such as ASX, Playlists .M3U, .WPL, .MTP.). The system lists your playlists alphabetically in flat file mode. If there are more than 255, they are organized into alphabetical categories. Press OK to select.
Page 450 SYNC® System Settings System settings provide access to your Bluetooth Devices and Advanced menu features. The Bluetooth Devices menu allows you to add, connect and delete a device as turn the Bluetooth feature on and off. Your Advanced menu allows you to access and set prompts, languages, defaults and perform a master reset.
Page 451 SYNC® When you select: You can: Delete a paired media device. Delete Device Press OK and scroll to select the device. Press OK to confirm. Delete all previously paired devices. Delete All Devices Press OK to select. Exit the current menu. Return This is a speed-dependent feature Advanced Menu Options...
Page 452 SYNC® When you select: You can: Factory Defaults Return to the factory default settings. This selection does not erase your indexed information (phonebook, call history, text messages and paired devices). 1. Press OK to select and then press OK again when Restore Defaults? appears in the display.
Page 453 SYNC® Phone Issues Issue Possible Possible Solution(s) Cause(s) During a call, I Possible phone Try turning off the device, can hear the malfunction. resetting the device, removing other person but the device’s battery, then trying they cannot hear again. • This is a •...
Page 454 SYNC® Phone Issues Issue Possible Possible Solution(s) Cause(s) • This is a • Go to the website to review I am having trouble phone-dependent your phone’s compatibility. • Try turning off the device, connecting my feature, OR • Possible phone phone to SYNC.
Page 455 SYNC® USB/Media Issues Issue Possible Possible Solution(s) Cause(s) • Try turning off the device, I am having Possible device trouble connecting malfunction. resetting the device or removing my device. the device’s battery, then trying again. • Make sure you are using the manufacturer’s cable.
Page 456 SYNC® Vehicle Health Report/Services (Traffic, Directions and Information) Issues Issue Possible Possible Solution(s) Cause(s) • Your account • This is a free feature, but you I received a text that the Vehicle may not be must first register online to use it. •...
Page 457 SYNC® Voice Command Issues Issue Possible Possible Solution(s) Cause(s) • You may be • Review the Phone voice SYNC does not understand what using the wrong commands and the Media voice I am saying. voice commands, commands at the beginning of their respective sections.
Page 458 SYNC® Voice Command Issues Issue Possible Possible Solution(s) Cause(s) • You may be • Review the phone voice SYNC does not understand or is using the wrong commands at the beginning of calling the wrong voice commands, the phone section. •...
Page 459: Myford Touch® (If Equipped)
INTRODUCTION WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device or feature that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
Page 460 MyFord Touch® (If Equipped) PHONE Press to select any of the following: • Making and Receiving Calls • Quick Dial • Phonebook • Call History • Text Messaging • Settings NAVIGATION Press to select any of the following: • My Home •...
Page 461 MyFord Touch® (If Equipped) HOME Press to access your home screen. Depending on your vehicle’s option package and software, your screens may vary in appearance from the descriptions in this section. Your features may also be limited depending on your market. Check with your authorized dealer for availability.
Page 462 Safety information WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
Page 463 MyFord Touch® (If Equipped) Speed-restricted Features Some features of this system may be too difficult to use while your vehicle is moving so they are restricted from use unless your vehicle is stationary. • Screens that are too crowded with information, such as Point of Interest reviews and ratings, SIRIUS®...
Page 464: Privacy Information
Master Reset to erase all information stored in SYNC®. SYNC® data cannot be accessed without special equipment and access to the vehicle’s SYNC® module. Ford Motor Company and Ford of Canada will not access SYNC® data for any purpose other than as...
Page 465 MyFord Touch® (If Equipped) How to Use Voice Commands with Your System Press the voice icon. After the tone, speak your command clearly. These commands can be said at any time. “Cancel” “Exit” “Go back” “List of commands” “Main menu” “Next page”...
Page 466 MyFord Touch® (If Equipped) Accessing a List of Available Commands • If you use the touchscreen, press the Settings icon > Help > Voice Command List. • If you use the steering wheel control, press the voice icon. After the tone, speak your command clearly.
Page 467 MyFord Touch® (If Equipped) Phone/Media Candidate Lists: Candidate lists are lists of possible results from your voice commands. The system creates these lists when it has the same confidence level of several options based on your voice command. To access these settings using the touchscreen: 1.
Page 468 MyFord Touch® (If Equipped) Some of the voice commands that are available while viewing this screen are: “DESTINATION” “Destination my home” “Destination street address” “Destination favorites” “Destination previous destinations” “Destination POI” “Destination intersection” “Destination emergency” If you choose Street Address from the navigation screen, you can choose from the following: •...
Page 469 MyFord Touch® (If Equipped) Some of the voice commands that are available while viewing this screen are: “POINTS OF INTEREST” or “POI” “Destination <POI category name>” “Search by name” “Search by category” “Change search area” Note: These are just a sample of the voice commands available within the Points of Interest section;...
Page 470: Listening To Music
MyFord Touch® (If Equipped) ENTERTAINMENT Your system offers many media options. You can access these options using the touchscreen or voice commands. Browsing Device Content When listening to any type of audio, you can browse through other devices without having to change sources. For example, if you are currently listening to the radio, you can browse all the artists that are stored on your USB device.
Page 471 MyFord Touch® (If Equipped) AM/FM Radio Press the lower left corner of the touchscreen and then select the AM or FM tab. To change between AM and FM presets, just touch the AM or FM tab. When you select: You can: Presets Save a station by pressing and holding one of the memory preset areas.
Page 472 MyFord Touch® (If Equipped) When you select: You can: Options Sound Settings allows you to adjust Bass, Midrange, Treble, Balance and Fade, DSP (Digital Signal Processing), Occupancy Mode, and Speed Compensated Volume settings. (Your vehicle may not have all these settings.) Set PTY for Seek/Scan allows you to select a category of music you would like to search for and then choose to either seek or scan for...
Page 473 MyFord Touch® (If Equipped) HD Radio™ Information (If Available) Note: HD Radio broadcasts are not available in all markets. HD Radio technology is the digital evolution of analog AM/FM radio. Your system has a special receiver that allows it to receive digital broadcasts (where available) in addition to the analog broadcasts, it already receives.
Page 474 MyFord Touch® (If Equipped) When HD Radio broadcasts are active, you can access the following functions: When you select: You can: Scan Hear a brief sampling of all available stations. This feature still works when HD Radio reception is on, although it does not scan for HD2-HD7 channels.
Page 475 MyFord Touch® (If Equipped) HD Radio Reception and Station Troubleshooting Potential Reception Issues Reception area If you are listening to a multicast station and you are on the fringe of the reception area, the station may mute due to weak signal strength.
Page 476 HD Radio™ Technology manufactured under license from iBiquity Digital Corp. U.S. and foreign patents. HD Radio™ and the HD and HD Radio logos are proprietary trademarks of iBiquity Digital Corp. Ford Motor Company and iBiquity Digital Corp. are not responsible for the content sent using HD Radio technology.
Page 477 MyFord Touch® (If Equipped) Radio Voice Commands If you are listening to the radio, press the voice button on the steering wheel control. When prompted, say any of the commands in the following chart. If you are not listening to the radio, press the voice button and, after the tone, say “Radio”, then any of the commands in the following chart.
Page 478 MyFord Touch® (If Equipped) “TUNE” “FM” “Preset <#>” “FM <87.9–107.9>” “Help” “FM <87.9-107.9> HD <#>” If available. SIRIUS® Satellite Radio (If Activated) Press the lower left corner of the touchscreen, then select the SIRIUS tab. When you select: You can: Presets Save a station by pressing and holding one of the memory preset areas.
Page 479 Note: SIRIUS does not support the Alert feature on all channels. Ford Motor Company shall not be responsible for Alert feature variation. Electronic Serial Number (ESN) is required when communicating with SIRIUS about your account.
Page 480 MyFord Touch® (If Equipped) Satellite Radio Voice Commands If you are listening to SIRIUS satellite radio, press the voice button on the steering wheel control. When prompted, say any of the commands in the following chart. If you are not listening to SIRIUS satellite radio, press the voice button and, after the tone, say “Sirius”, then any of the commands in the following chart.
Page 481 Note: SIRIUS reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
Page 482 MyFord Touch® (If Equipped) Potential Satellite Radio Reception Issues Station overload When you pass a ground-based broadcast-repeating tower, a stronger signal may overtake a weaker one and the audio system may mute. Satellite radio signal Your display may show ACQUIRING . . . to interference indicate the interference and the audio system may mute.
Page 483 MyFord Touch® (If Equipped) SIRIUS Troubleshooting Tips Radio Display Condition Possible Action Call SIRIUS Your satellite service is Contact SIRIUS at 1–888–539–7474. no longer available. 1-888-539-7474 to resolve subscription issues. No Channels Available. All the channels in the Use the channel guide selected channels are to turn off the Lock either skipped or...
Page 484 MyFord Touch® (If Equipped) CD Voice Commands If you are listening to a CD, press the voice button on the steering wheel control. When prompted, say any of the commands in the following chart. If you are not listening to a CD, press the voice button and, after the tone, say “CD”, then any of the commands in the following chart.
Page 485 MyFord Touch® (If Equipped) USB Port The ports are located either in the center console or behind a small access door in the instrument panel. To access and play music from your device, press the lower left corner of the touchscreen. This feature allows you to plug in media playing devices, memory sticks, flash drives or thumb drives, and charge devices if they support this feature.
Page 486 MyFord Touch® (If Equipped) When you select: You can: Options Sound Settings allows you to adjust Bass, Midrange, Treble, Balance and Fade, DSP (Digital Signal Processing), Occupancy Mode and Speed Compensated Volume. (Your vehicle may not have all these settings.) Media Player Settings allows you to select more settings, which is under Media Player.
Page 487 MyFord Touch® (If Equipped) “USB” or “SD CARD” “Play all” “Play video <name>” “Play artist <name>” “Play video podcast episode <name>” “Play audiobook <name>” “Play video playlist <name>” “Play author <name>” “Previous” “Play composer <name>” “Repeat all” “Play folder <name>” “Repeat off”...
Page 488 MyFord Touch® (If Equipped) Supported Media Players, Formats and Metadata Information SYNC is capable of hosting nearly any digital media player, including iPod®, Zune™, plays from device players, and most USB drives. Supported audio formats include MP3, WMA, WAV and AAC. It is also able to organize your indexed media from your playing device by metadata tags.
Page 489 MyFord Touch® (If Equipped) Bluetooth Voice Commands “Browse all artists” “Browse genre “Play podcast episode <name>” <name>” “Browse all ”Browse playlist “Play similar music” audiobooks” <name>” “Browse all authors” ”Browse podcast “Play song <name>” <name>” “Browse all “Next” “Previous” composers” “Browse all folders”...
Page 490 MyFord Touch® (If Equipped) WARNING: Store the portable music player in a secure location, such as the center console or the glove box, when your vehicle is moving. Hard objects may become projectiles in a crash or sudden stop, which may increase the risk of serious injury. The audio extension cable must be long enough to allow the portable music player to be safely stored while your vehicle is moving.
Page 491: Phone Features
MyFord Touch® (If Equipped) In order to playback video from your iPod® or iPhone® (if compatible), you must have a special combination USB/RCA composite video cable (which you can buy from Apple®). When the cable is connected to your iPod® or iPhone®, plug the other end into both the RCA jacks and the USB port.
Page 492 Pairing Your Phone for the First Time WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
Page 493 MyFord Touch® (If Equipped) Making Calls Press the voice button. When prompted, say, “Call <name>” or say “Dial”, then the desired number. To end the call or exit phone mode, press and hold the phone button. Receiving Calls During an incoming call, an audible tone sounds. Call information appears in the display if it is available.
Page 494 MyFord Touch® (If Equipped) When you select: You can: Phonebook Access and call any contacts in your previously downloaded phone book. The system places the entries in alphabetical categories summarized at the top of the screen. To turn on contact picture settings (if your device supports this feature), press Phone >...
Page 495 MyFord Touch® (If Equipped) Text Messaging Note: Downloading and sending text messages using Bluetooth are phone-dependent features. Note: Certain features in text messaging are speed-dependent and not available when your vehicle is traveling at speeds over 3 mph (5 km/h). Note: SYNC does not download read text messages from your phone.
Page 496 MyFord Touch® (If Equipped) Pre-defined Text Message Options I’m running a few minutes late. I’m ahead of schedule, so I’ll be there early. I’m outside. I’ll call you when I get there. Thanks Stuck in traffic. Call me later. Receiving a Text Message Note: If you select View and your vehicle is traveling over 5 mph (8 km/h), the system offers to read the message to you instead of allowing you to view it while driving.
Page 497 MyFord Touch® (If Equipped) If you select: You can: 911 Assist Turn on or turn off the 911 Assist™ feature. See 911 Assist® in the SYNC Services and Applications section. Phone Ringer Select what ring tone you would like to hear when you receive a call.
Page 498: Information Menu
MyFord Touch® (If Equipped) “PHONE” “Call <name> at work” “Messages” “Call <name> on cell” “Mute call” “Call <name> on other” “Pair phone” “Call voicemail” “Privacy on” “Dial” “Reply to text messages” “Do not disturb off” “Turn ringer off” “Do not disturb on” “Turn ringer on”...
Page 499 For more information, see SYNC Services Terms and Conditions at www.SYNCMyRide.com. If you do not want Ford or its service providers to collect your vehicle travel information or other information identified in the Terms and Conditions, do not subscribe or use the service.
Page 500 MyFord Touch® (If Equipped) Connecting to SYNC Services Using Voice Commands 1. Press the voice button. 2. When prompted, say “Services”. This initiates an outgoing call to SYNC Services using your paired and connected Bluetooth-enabled cellular phone. 3. Once you connect to the service, follow the voice prompts to request the desired service, such as “Traffic”...
Page 501 MyFord Touch® (If Equipped) If your vehicle is not equipped with Navigation: • Turn-by-turn directions appear in the information display, in the status bar of your touchscreen system and on the SYNC Services screen. You also receive driving instructions from audible prompts. •...
Page 502 SIRIUS Travel Link (If Equipped and If Activated) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device or feature that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
Page 503 SIRIUS Travel Link. Note: Neither SIRIUS nor Ford is responsible for any errors or inaccuracies in the SIRIUS Travel Link services or its use in vehicles. When you subscribe to SIRIUS Travel Link, it can help you locate the...
Page 504 MyFord Touch® (If Equipped) SIRIUS Travel Link Voice Commands Note: In order to use SIRIUS Travel Link, your vehicle must be equipped with navigation and your navigation SD card must be in the SD card slot. Press the voice button and when prompted, say any of the following: Travel Link Voice Commands “5–day weather forecast”...
Page 505 MyFord Touch® (If Equipped) “TRAVEL LINK” “College basketball “Motor sports order” “NHL schedule” schedule” “College basketball “Motor sports “NHL scores” scores” schedule” “College football “Movie listings” “Traffic” headlines” “College football “My team headlines” “Weather” schedule” “College football “My teams schedule” “Weather map”...
Page 506 MyFord Touch® (If Equipped) 911 Assist® (If Equipped) WARNING: Unless the 911 Assist setting is set on before a crash, the system will not dial for help, which could delay response time, potentially increasing the risk of serious injury or death after a crash.
Page 507 MyFord Touch® (If Equipped) Setting 911 Assist On Press the Information button > Apps > 911 Assist, then select You can also access 911 Assist by: • Pressing the Settings icon > Settings > Phone > 911 Assist, or • Pressing the Settings icon > Help > 911 Assist. To Make Sure that 911 Assist Works Properly •...
Page 508 MyFord Touch® (If Equipped) 911 Assist May Not Work If • Your cellular phone or 911 Assist hardware sustains damage in a crash. • The vehicle’s battery or SYNC system has no power. • The phone(s) thrown from your vehicle are the ones paired and connected to the system.
Page 509 “Vehicle health report”. Vehicle Health Report Privacy Notice When you create a Vehicle Health Report, Ford Motor Company may collect your cellular phone number (to process your report request) and diagnostic information about your vehicle. Certain versions or updates to Vehicle Health Report may also collect more vehicle information.
Page 510: Settings
MyFord Touch® (If Equipped) SETTINGS Under this menu, you can set your clock, access and adjust the display, sound and vehicle settings as well as access settings for specific modes or the help feature. Clock Note: You cannot manually set the date. Your vehicle’s GPS does this for you.
Page 511 MyFord Touch® (If Equipped) Uploading Photos for Your Home Screen Wallpaper Note: You cannot load photos directly from your camera. You must access the photos either from your USB mass storage device or from an SD card. Note: Photographs with extremely large dimensions (i.e., 2048 x 1536) may not be compatible and appear as a blank (black) image on the display.
Page 512 MyFord Touch® (If Equipped) Ambient Lighting (If Equipped) When activated, ambient lighting illuminates footwells and cupholders with a choice of colors. To access and make adjustments: 1. Press the Settings icon > Vehicle > Ambient Lighting. 2. Touch the desired color. 3.
Page 513 MyFord Touch® (If Equipped) Settings Access and adjust system settings, voice features, as well as phone, navigation and wireless settings. System Press the Settings icon > Settings > System, then select from the following: System Language Select to have the touchscreen display in English, Spanish or French.
Page 514 MyFord Touch® (If Equipped) Voice Control Press the Settings icon > Settings > Voice Control, then select from the following: Voice Control Interaction Mode Standard interaction mode provides more detailed interaction and guidance. Advanced mode has less audible interaction and more tone prompts.
Page 515 MyFord Touch® (If Equipped) Media Player Press the Settings icon > Settings > Media Player, then select from the following: Media Player Autoplay When this feature is on, the system automatically switches to the media source upon initial connection. This allows you to listen to music during the indexing process.
Page 516 MyFord Touch® (If Equipped) Navigation Press the Settings icon > Settings > Navigation, then select from the following: Navigation Map Preferences Turn breadcrumbs on and off. Have the system display your turn list top to bottom or bottom to top. Turn the Parking POI notification on and off.
Page 517 MyFord Touch® (If Equipped) Phone Settings Press the Settings icon > Settings > Phone, then select from the following: Phone Bluetooth Devices Connect, disconnect, add or delete a device, as well as save it as a favorite. Bluetooth Turn Bluetooth on and off. Do Not Disturb Have all calls go directly to your voice mail and not ring inside your vehicle.
Page 518 MyFord Touch® (If Equipped) Wireless & Internet Your system has a Wi-Fi feature that creates a wireless network within your vehicle, thereby allowing other devices (such as personal computers or phones) in your vehicle to speak to each other, share files or play games.
Page 519 MyFord Touch® (If Equipped) Wireless & Internet USB Mobile Instead of using Wi-Fi, your system can also Broadband use a USB mobile broadband connection to access the internet. (You must turn on your mobile broadband device on your personal computer before connecting it to the system.) This screen allows you to set up what is your typical area for your USB mobile broadband connection.
Page 520 MyFord Touch® (If Equipped) Wi-Fi Your system has a Wi-Fi feature which creates a wireless network within your vehicle, thereby allowing other devices (i.e. personal computers or phones) in your vehicle to speak to each other, share files, play games, etc.
Page 521 MyFord Touch® (If Equipped) USB Mobile Broadband Instead of using Wi-Fi, your system can also use a USB mobile broadband connection to access the internet. (You must activate your mobile broadband device on your PC prior to connecting it to the system.) This screen allows you to set up what is your typical area for your USB mobile broadband connection.
Page 522 MyFord Touch® (If Equipped) Help Press the Settings icon > Help, then select from the following: Help Where Am I? View your vehicle’s current location, if your vehicle is equipped with navigation. If your vehicle is not equipped with navigation, nothing displays.
Page 523: Climate Features
MyFord Touch® (If Equipped) CLIMATE Press the lower right corner on the touchscreen to access your climate control features. Depending on your vehicle line and option package, your climate screen may look different from the screen shown here. A. Power: Touch to switch the system off and on. Outside air cannot enter your vehicle when you switch off the system.
Page 524 MyFord Touch® (If Equipped) F. A/C: Touch to turn the air conditioning on or off. • Use with recirculated air to improve cooling performance and efficiency. • Engages automatically in MAX A/C, defrost and floor/defrost. G. AUTO: Touch to engage automatic operation, then set the temperature using the temperature control.
Page 525 MyFord Touch® (If Equipped) Climate Control Voice Commands The following voice commands are available at the main menu level of a voice session. For example, press the voice button and after the prompt, “Say a command”; say any of the following commands: Climate Control Voice Commands “Climate automatic”...
Page 526: Navigation System
MyFord Touch® (If Equipped) “TEMPERATURE” “High” “Low” “<15.5–29.5> degrees” “<60–85> degrees” “Help” NAVIGATION SYSTEM (IF EQUIPPED) Note: The navigation SD card must be in the SD card slot to operate the navigation system. If you need a replacement SD card, see your authorized dealer.
Page 527 MyFord Touch® (If Equipped) 1. Enter the necessary information into the highlighted text fields (in any order). For address destination entry, Go! appears once all the necessary information has been entered. Pressing Go! makes the address location appear on the map. If you choose Previous Destination, the last 20 destinations you have selected appear.
Page 528 MyFord Touch® (If Equipped) Within these main categories, there are subcategories which contain more listings: Subcategories Restaurant Golf Parking Home & Garden Personal Care Services Automobile Dealership Govt. Office Public Transit Education To expand these listings, press the + in front of the point of interest listing.
Page 529 MyFord Touch® (If Equipped) This screen displays point of interest icons, such as: Hotel Coffeehouse Food & Drink Nightlife Attraction This icon appears when your selection exists in multiple categories within the system. When you are viewing more information for hotels, cityseekr also tells you if the hotel has certain services and facilities using icons.
Page 530 MyFord Touch® (If Equipped) Hotel Services and Facilities Handicap Facilities Internet Access Laundry Pool Refrigerator Wi-Fi For restaurants, cityseekr can provide information, such as star rating, average cost, review, handicap access, hours of operation, and website address. For hotels, cityseekr can provide information, such as star rating, price category, review, check-in and check-out times, hotel service icons and website address.
Page 531 MyFord Touch® (If Equipped) When you select: You can: Route Preferences Choose to have the system display the shortest route, fastest route or most ecological route. Avoid freeways, toll roads, ferries and car trains when planning your route. Use high-occupancy vehicle lanes (if available).
Page 532 MyFord Touch® (If Equipped) Map Mode Press the green bar in the upper right area of the touchscreen to view map mode. Map mode shows advanced viewing comprised of both 2D city maps as well as 3D landmarks (when available). 2D city maps show detailed outlines of buildings, visible land use and land elements and detailed railway infrastructure for the most essential cities around the globe.
Page 533 MyFord Touch® (If Equipped) Auto Zoom Press the green bar to access map mode, then select the + or - zoom button to bring up the zoom level and Auto buttons on the touchscreen. When you press Auto, Auto Zoom turns on and Auto displays in the bottom left corner of the screen.
Page 534 MyFord Touch® (If Equipped) Destination symbol indicates the ending point of a planned route. Next maneuver point indicates the location of the next turn on the planned route. No GPS symbol indicates that insufficient GPS satellite signals are available for accurate map positioning. This icon may display under normal operation in an area with poor GPS access.
Page 535 Annual navigation map updates are available for purchase through your dealership, by calling 1-800-NAVMAPS (in Mexico, call 01–800–557–5539) or going to www.navigation.com/ford. You need to specify the make and model of your vehicle to determine if there is an update available.
Page 536 MyFord Touch® (If Equipped) Navigation System Voice Commands “Destination play nametags” “Voice volume decrease” “Destination POI” “Voice volume increase” “Destination POI category” “Where am I?” “Destination previous destination” “Zoom in” “Destination street address” “Zoom out” “Detour” “Help” These commands are only available when a navigation route is active. If you have said the command, “Destination”, you may say any of the above commands or commands in the following Destination chart.
Page 537 MyFord Touch® (If Equipped) “NAVIGATION” “Zoom province” “Zoom state” “Zoom street” “Zoom to <distance>” “Help” If you have said, “Destination”, you may say any of the commands in the Destination chart. One-shot Destination Street Address If your vehicle is equipped with the SD card navigation feature, you have the ability to enter in a street address using a feature called one-shot destination street address.
Page 538: Appendices
SYNC® End User License Agreement (EULA) • You have acquired a device (“DEVICE”) that includes software licensed by FORD MOTOR COMPANY from an affiliate of Microsoft Corporation (“MS”). Those installed software products of MS origin, as well as associated media, printed materials, and “online” or electronic documentation (“MS SOFTWARE”) are protected by international...
Page 539 Neither FORD MOTOR COMPANY nor its suppliers shall be liable for any damages arising out of errors in the speech recognition process.
Page 540 SOFTWARE after the date you obtain your initial copy of the SOFTWARE (“Supplemental Components”). If FORD MOTOR COMPANY or third party software and services suppliers provide or make available to you Supplemental Components and no other EULA terms are provided along with the Supplemental Components, then the terms of this EULA shall apply.
Page 541 DEVICE. UPGRADES AND RECOVERY MEDIA: If the SOFTWARE is provided by FORD MOTOR COMPANY separate from the DEVICE on media such as a ROM chip, CD ROM disk(s) or via web download or other means, and is labeled “For Upgrade Purposes Only” or For Recovery Purposes...
Page 542 For additional information, see http://www.microsoft.com/exporting/. TRADEMARKS: This EULA does not grant you any rights in connection with any trademarks or service marks of FORD MOTOR COMPANY, MS, Microsoft Corporation, third party software or service providers, their affiliates or suppliers.
Page 543 End user notice Microsoft® Windows® Mobile for Automotive Important Safety Information This system Ford SYNC™ contains software that is licensed to Manufacturer FORD MOTOR COMPANY by an affiliate of Microsoft Corporation pursuant to a license agreement. Any removal, reproduction, reverse engineering or other unauthorized use of the software from this system in violation of the license agreement is strictly prohibited and may subject you to legal action.
Page 544 Appendices attempting to access a function of the system requiring prolonged attention. Even occasional short scans to the screen may be hazardous if your attention has been diverted away from your driving task at a critical time. Volume Setting Do not raise the volume excessively. Keep the volume at a level where you can still hear outside traffic and emergency signals while driving.
Page 545 Appendices Potential Map Inaccuracy Maps used by this system may be inaccurate because of changes in roads, traffic controls or driving conditions. Always use good judgment and common sense when following the suggested routes. Emergency Services Do not rely on any navigation features included in the system to route you to emergency services.
Page 546 Appendices You agree to indemnify and hold TeleNav harmless against all claims resulting from any dangerous or otherwise inappropriate use of the TeleNav Software in any moving vehicle, including as a result of your failure to comply with the directions above. 2.
Page 547 Appendices 4. Disclaimers To the fullest extent permissible pursuant to applicable law, in no event will TeleNav, its licensors and suppliers, or agents or employees of any of the foregoing, be liable for any decision made or action taken by you or anyone else in reliance on the information provided by the TeleNav Software.
Page 548 Appendices LIMITED TO THE AMOUNT ACTUALLY PAID BY YOU FOR THE TELENAV SOFTWARE. SOME STATES AND/OR JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. 6.
Page 549 Appendices Software, including without limitation all related intellectual property rights. No licenses or other rights which are not expressly granted in this Agreement are intended to, or shall be, granted or conferred by implication, statute, inducement, estoppel or otherwise, and TeleNav and its suppliers and licensors hereby reserve all of their respective rights other than the licenses explicitly granted in this Agreement.
Page 550 Appendices NavTeq End User License Agreement END USER TERMS The content provided (“Data”) is licensed, not sold. By opening this package, or installing, copying, or otherwise using the Data, you agree to be bound by the terms of this agreement. If you do not agree to the terms of this agreement, you are not permitted to install, copy, use, resell or transfer the Data.
Page 551 Appendices License Limitations on Transfer: Your limited license does not allow transfer or resale of the Data, except on the condition that you may transfer the Data and all accompanying materials on a permanent basis if: (a) you retain no copies of the Data; (b) the recipient agrees to the terms of this End User License Agreement;...
Page 552 Appendices Disclaimer of Liability: NT AND ITS LICENSORS (INCLUDING THEIR LICENSORS AND SUPPLIERS) SHALL NOT BE LIABLE TO YOU IN RESPECT OF ANY CLAIM, DEMAND OR ACTION, IRRESPECTIVE OF THE NATURE OF THE CAUSE OF THE CLAIM, DEMAND OR ACTION ALLEGING ANY LOSS, INJURY OR DAMAGES, DIRECT OR INDIRECT, WHICH MAY RESULT FROM THE USE OR POSSESSION OF THIS DATA;...
Page 553 Appendices Government End Users: If the Data is being acquired by or on behalf of the United States government or any other entity seeking or applying rights similar to those customarily claimed by the United States government, this Data is a “commercial item” as that term is defined at 48 C.F.R.
Page 554 Appendices The software from Gracenote (the “Gracenote Software”) enables this device to do disc and music file identification and obtain music-related information, including name, artist, track, and title information (“Gracenote Data”) from online servers (“Gracenote Servers”), and to perform other functions. You may use Gracenote Data only by means of the intended End User functions of this device This device may contain content belonging to Gracenote’s providers.
Page 555 Appendices WARRANTIES, EXPRESS OR IMPLIED, REGARDING THE ACCURACY OF ANY GRACENOTE DATA FROM THE GRACENOTE SERVERS OR GRACENOTE CONTENT. GRACENOTE COLLECTIVELY AND SEPARATELY RESERVE THE RIGHT TO DELETE DATA AND/OR CONTENT FROM THE COMPANIES’ RESPECTIVE SERVERS OR, IN THE CASE OF GRACENOTE, CHANGE DATA CATEGORIES FOR ANY CAUSE THAT GRACENOTE DEEMS SUFFICIENT.
Page 556: Index
Index 911 Assist™ ......432, 505 All Wheel Drive (AWD), driving off road ......207 Ambient mood/lighting .....511 Ambulance packages ....15 ABS (see Brakes) .....220 AM/FM ........470 Accessing and using your USB Antifreeze port ..........483 (see Engine coolant) ....301 Accessing call history/phone Anti-lock brake system book during active call .....422 (see Brakes) ......220...
Page 557 CD player ......133, 482 refill capacities ......384 CD voice commands ....483 Customer Assistance ....271 Cell phone use ......16 Ford Extended Service Changing a tire ......366 Plan ........393, 395 Changing the air filter ....317 Getting roadside assistance ...271 Getting the service you Child safety seats need .........277...
Page 558 Index Engine oil checking and adding ....300 dipstick ........300 Daytime running lamps filter, specifications ....388 (see Lamps) ........85 refill capacities ......384 Defrost .......145, 147 Event data recording ....12 rear window ......151 Exhaust fumes ......185 Dipstick automatic transmission fluid ..........306 engine oil ......298, 300 Fail safe cooling ......304 Display settings ......509 Filter...
Page 559 Index Fuses ......285–286, 290 Information displays ....102 Inspection/maintenance (I/M) testing ........196 Instrument panel Garage door opener ..167, 171 cleaning ......331–332 Gas cap (see Fuel cap) ....192 cluster ........97 lighting up panel and Gauges .........95 interior ........85 Hazard flashers ......273 Jack ..........366 HD Radio™...
Page 560 Index Lane change indicator MyFord Touch™ system ..458 (see Turn signal) ......86 MyKey ..........66 LATCH anchors ......31 Lights, warning and indicator ..97 Listening to music ....469 Navigation features ....525 Loading instructions ....243 Navigation voice commands ..534 Load limits .........237 Notifications ......504 Locks autolock ........71 childproof ........35...
Page 561 Index Power mirrors ......90 Route preferences ....529 Powerpoint ........177 Power steering ......236 fluid, checking and adding ..311 Safety Belt Maintenance ....45 fluid, refill capacity ....384 Safety belts Power Windows ......88 (see Safety restraints) ..38, 42 Privacy information ..415, 463 Safety defects, reporting ..284 Putting a call on/off hold ..422 Safety information ....414, 461 Safety restraints ....38, 40, 42...
Page 562 Index SecuriLock passive anti-theft Supported media file types ..487 system ..........75 Supported player, media Selecting your media source formats and metadata (USB, Line in, BT audio) ..445 information ........487 Sending new text messages ..494 SYNC® AppLink™ ....440 Setting a destination ....525 SYNC®...
Page 563 Index Touchscreen features (climate) ........522 Vehicle health report ..435, 507 Towing .......249, 261, 263 recreational towing ....263 Vehicle Identification Number Trailer Brake (VIN) ..........389 Controller-Integrated ....254 trailer towing ......249 Vehicle loading ......237 wrecker ........261 Ventilating your vehicle ...185 Traction control ......222 Voice commands in media Traffic, Directions and mode ..........442...
