20. While a second person holds the Console (33)
near the Handlebar (10), connect the console
wires to the Upright Wire (60) and to the Pulse
Wire (135).
Insert the excess wire into the Console (33) or
into the Handlebar (10).
Tip: Avoid pinching the wires. Attach the
Console (33) to the Handlebar (10) with four M4
x 16mm Screws (93).
21. Attach the Console Cover (11) to the Console
(33) with two M4 x 16mm Screws (93).
22. Plug the Power Adapter (59) into the receptacle
on the frame of the elliptical.
To plug the Power Adapter (59) into an outlet,
see HOW TO PLUG IN THE POWER ADAPTER
on page 15.
23. Make sure that all parts of the elliptical are properly tightened. Note: Some hardware may be left over
after assembly is completed. To protect the floor or carpet from damage, place a mat under the elliptical.
20
33
21
33
22
14
Avoid pinching
the wires
135
10
60
93
11
59
93
