Ultra Bar 9
is displayed. This is the 5 Channel DMX Mode.
• To run the 6 Channel Mode, press the MODE button until "Ch.06"
is displayed. This is the 6 Channel DMX Mode.
• To run the 7 Channel Mode, press the MODE button until "Ch.07"
is displayed. This is the 7 Channel DMX Mode.
• To run the 8 Channel Mode, press the MODE button until "Ch.08"
is displayed. This is the 8 Channel DMX Mode.
• To run the 9 Channel Mode, press the MODE button until "Ch.09"
is displayed. This is the 9 Channel DMX Mode.
9 Channel Mode will work with Kling-Net.
• To run the 11 Channel Mode, press the MODE button until
"Ch.11" is displayed. This is the 11 Channel DMX Mode.
4. Please see pages 13-20 for DMX values and traits.
5. After you have chosen your desired DMX Channel mode plug in
the fixture via the XLR connections to any standard DMX control-
ler.
Default Running Mode:
This is a default running mode. When this mode is activated all modes
will return to their default settings and a Auto program will run.
1. Plug the fixture in and press the MODE and SET UP buttons at the
same time.
ADJ RFC:
This function is used to activate and deactivate the ADJ RFC (Remote
Control). When this function is activated you can control the fixture
using the ADJ RFC. Please see page 12 for ADJ RFC controls and
functions.
1. Plug the fixture in and press the MODE button until "Auto" is dis-
played.
2. Press the SET UP button until "rF.XX" is displayed. "XX" repre-
sents either "on" or "oF".
3. Press the UP or DOWN buttons to either activate the remote func-
tion (On) or deactivate it (Off).
Dimming Curve:
This is used to set the dimming curve used with DMX mode. See
page 26 for the different dimming curves. The dimming curves are in
the order they appear in the unit.
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 10
Operating Instructions
Ultra Bar 9
1. Plug the fixture in and press the MODE button until the DMX
address is displayed.
2. Press the SET UP button until "dr-X" is displayed. This is the dim-
mer setting. "X" represents the dimming mode.
3. Use the UP and DOWN buttons to find your desired dimming
curve. Press SET UP when you are finished.
Ultra Bar 9
Master-Slave Configuration:
This function will allows you to link units together to run in a Master-Slave
mode. In Master-Slave operation one unit will act as the controlling unit
and the others will react to the controlling units built-in programs. Any
unit can act as a Master or as a Slave however, only one unit can be pro-
grammed to act as the "Master."
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit.
Use standard XLR data cables to link your units together. Remember
that the Male XLR connector is the input and the Female XLR con-
nector is the ouput. The first unit in the chain (master) will use the
female XLR connector only. The last unit in the chain will use the
male XLR connector only.
2. Set the "Master" unit to your desired operating mode and then
connect the "Slave" unit or units.
3. For the "Slave" unit(s) press the MODE button until "SLAu" is dis-
played. The "Slave" unit(s) will now follow the "Master" unit.
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 11
Operating Instructions
Master-Slave Configuration
