DVD Entertainment System
PKG-2100P
OWNER'S MANUAL
Please read before using this equipment.
ALPINE ELECTRONICS OF AUSTRALIA PTY, LTD.
161-165 Princess Highway, Hallam
Victoria 3803, Australia
Phone 03-8787-1200
ALPINE ELECTRONICS GmbH
Wilhelm-Wagenfeld-Straße 1-3,
80807 München, Germany
Phone 089-32 42 640
ALPINE ELECTRONICS OF U.K., LTD.
ALPINE House
Fletchamstead Highway, Coventry CCV4 9TW, U.K.
Phone 0870-33 33 763
ALPINE ELECTRONICS (BENELUX) GmbH
Leuvensesteenweg 510-B6,
1930 Zaventem, Belgium
Tel.: 02-725 1315
R R
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue de la Belle Etoile, Z.I. paris Nord II,
B.P. 50016, 95945 Roissy Charles de Gaulle
Cedex, France
Phone 01-48638989
ALPINE ITALIA S.p.A.
Viale C. Colombo 8, 20090 Trezzano
Sul Naviglio (MI), Italy
Phone 02-484781
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava)-APDO 133, Spain
Phone 945-283588
Designed by Alpine Electronics (Europe) GmbH
Printed In China
EN

Advertisement

Table of Contents
loading

Related Manuals for Alpine PKG-2100P

Summary of Contents for Alpine PKG-2100P

  • Page 1 DVD Entertainment System PKG-2100P OWNER'S MANUAL Please read before using this equipment. ALPINE ELECTRONICS MARKETING, INC. ALPINE ELECTRONICS OF AUSTRALIA PTY, LTD. ALPINE ELECTRONICS FRANCE S.A.R.L. 161-165 Princess Highway, Hallam (RCS PONTOISE B 338 101 280) 1-1-8 Nishi Gotanda Shinagawa-ku Victoria 3803, Australia 98, Rue de la Belle Etoile, Z.I.

  • Page 3: Table Of Contents

    ENGLISH Contents Slow Motion Playback ........14 Operating Instructions Searching by Title/Folder Number ....14 Searching Directly by Chapter or Track / WARNING File Number ..........14 Chapter/Track/Title Repeat Playback ..... 15 WARNING ..........3 Switching the Audio Tracks ......15 CAUTION ...........
  • Page 4 DVD Player Setup SETUP Operation ..........21 Setting items ..........21 Setting the Language ........21 Setting the Country Code ......22 Setting the Rating Level (Parental Lock) ..22 Change the Password ........22 Playing back a Main Story directly ....22 Setting the Rating Level (Parental Lock) ..

  • Page 5: Operating Instructions

    Failure to do so may cause personal injury or damage to the KEEP THE VOLUME AT A LEVEL WHERE YOU CAN product. Return it to your authorized Alpine dealer or the nearest STILL HEAR OUTSIDE NOISE WHILE DRIVING. Alpine Service Center for repairing.

  • Page 6: Precautions

    Installation Location contrast temporarily. After a short warm-up period, it will return to normal. Make sure the PKG-2100P will not be installed in a location subjected to: • The LCD panel is manufactured using an extremely high precision manufacturing technology. Its effective pixel ratio •...

  • Page 7: Discs Playable On This Unit

    Using such accessories can cause ® DivX 12 cm operational problems. We recommend not using these accessories Video on discs played in Alpine DVD players. * Two-layer DVD disc compatible The formatted discs listed below can be played on this unit. CD-R/ DVD-R/ DVD+R/...
  • Page 8 On handling compact discs (CD/CD-R/CD-RW) Discs that cannot be played • Do not touch the surface. DVD-ROMs, DVD-RAMs, CD-ROMs, photo CDs, etc. • Do not expose the disc to direct sunlight. • Do not affi x stickers or labels. DVD region number (playable region number) •...

  • Page 9: Getting Started

    Getting Started Closing the cover Slide the cover as illustrated until a click is heard. When Using the Remote Control • Point the remote control at the remote sensor within about 2 meters. • It may not be possible to operate the remote control if the remote control sensor is exposed to direct sunlight.

  • Page 10: Overhead Monitor

    Overhead Monitor IR Transmitter and Receiver IR transmitter sends the sound to the Headphone. IR receiver receives the signal from the remote control. Eject Button Eject Button Pressing Eject button unloads Disc. If the ignition key is set to ACC or ON, a disc can be removed even when the power is OFF.

  • Page 11: Key Map Of Remote Control Function

    Key Map of Remote Control Function RUE-4159 Remote Control Key Assignment KEY FUNCTION DVD/ DVD-HU DVB-T TV Tuner EXE-DVD (Europe only) MONITOR POWER DEVICE POWER MUTE DIMMER VISUAL EQ AUX1 AUX2 DEVICE MODE: EXT-DVD DEVICE MODE: DVD-HU DEVICE MODE: TV TUNER DEVICE MODE: DVB-T DEVICE MODE: ISDB-T MEMORY FOR DEVICE MODE: MEM...

  • Page 12: Basic Operations

    Loading and Unloading Discs Basic Operations Turn on the power before loading and unloading discs. EJECT POWER Loading discs Insert the disc with the label side facing upwards. Once the disc is partially inserted, it is drawn in automatically. Playback starts. Top Front Side SELECT Front Control Keys...

  • Page 13: Adjusting The Volume

    Adjusting the Volume Device Control Volume can be controlled from the headphone or your own radio Device modes (TV, DVB-T, ISDB-T, DVD-HU and EXT-DVD) are volume function. available on the remote control by pressing the device control. Turn on POWER on the headphone. Adjust the volume level by turning clockwise for louder and counter-clockwise for lower on the headphone.

  • Page 14: Dvd

    Insert a disc with the label side facing up. To load discs, see “Loading and Unloading Discs” on page 10. Playback starts. • The reverse side of a double-sided DVD will not be played The instruction includes Built-In DVD, EXT-DVD, automatically.

  • Page 15: Fast-Forwarding/Fast-Reversing

    Displaying a Folder/File Menu List Fast-forwarding/Fast-reversing If a fi le from the folder menu list is selected: During playback, press and hold (fast-reverse) (fast-forward). During playback, press TOP MENU. When pressed for more than 1 second, the disc is The folder list in a disc is displayed. forwarded/reversed at double speed.

  • Page 16: Frame-By-Frame Playback

    Searching Directly by Chapter or Frame-by-frame Playback Track / File Number In the pause mode, press The picture advances or reverses by one frame each time the button is pressed. Use this function to easily move to the beginning of the chapters or tracks on the disc.

  • Page 17: Chapter/Track/Title Repeat Playback

    Repeat Playback Switching the Audio Tracks Use this function to play the disc’s titles, chapters or tracks repeatedly. DVDs can have up to 8 different audio tracks. These alternate tracks can be switched during playback. During playback, press REPEAT. During playback, press AUDIO. The repeat mode switches each time the button is pressed.

  • Page 18: Displaying The Disc Status

    Displaying the Disc Status DVB-T Control This function is available only for Europe. To control DVB-T from Use the procedure described below to display the status (title number, the Front Control Keys, set source name to DVB-T in the System chapter number, etc.) of the currently playing DVD on the monitor Setup.

  • Page 19: Monitor Setup

    • “OFF” will change to “CUSTOM”, when any of the picture Monitor Setup mode (Brightness, Color, Tint, Contrast and Sharpness) has been adjusted • NIGHT MOVIE, SOFT, SHARP and HIGH CONT. are fi xed values. Adjusting Picture They cannot be set manually. If the picture mode is changed, they automatically change to CUSTOM mode.

  • Page 20: Adjusting The Tint

    Adjusting the Tint Resetting the Picture Adjustment Press and select TINT. Press and select RESET. Press to adjust the tint. Tint tone can be Press t o reset the picture adjustments. adjusted from G15 (G MAX) to R15 (R MAX). •...

  • Page 21: Setting The Source Name

    Setting the Source Name Setting the Screen Modes Display mode on the screen can be adjusted to Press and select SOURCE NAME. Wide, Cinema and Normal. (Default: WIDE) The currently selected source name Press to select WIDE/CINEMA/NORMAL The currently selected source displays on Source Name menu Video Signal menu is...

  • Page 22: Setting System Control

    • To activate SKIP mode, a disc must be ejected and reloaded Press SETUP button on Remote Control. after setting. (Note: SKIP mode can not be activated, when a disc is inserted or reloaded while Alpine logo is shown on Press SELECT/SETUP to switch to SYSTEM the screen monitor.) setting menu from AUDIO&SCREEN setting menu.

  • Page 23: Dvd Player Setup

    DVD Player Setup After setting, press and hold SETUP for at least 2 seconds. Save the setting to exit the setting mode. DVD CONTENTS SETUP • When settings are changed, old settings are overwritten. Make a note of the current settings before making changes. The settings are not cleared even when the vehicle's battery.

  • Page 24: Setting The Country Code

    Setting the Country Code • Write down the password on a piece of paper and store the piece of paper somewhere in case you forget it. Set the country code when setting the rating level (Parental lock). • On unrated DVDs, playback will not be restricted even if the rating level is set.

  • Page 25: Setting The Tv Screen

    Setting the TV Screen CD CONTENT SETUP Use the procedure described below to set the output screen according • When settings are changed, old settings are overwritten. Make a note of the current settings before making changes. The settings to the type of TV monitor being used. are not cleared even when the vehicle’s battery is disconnected.

  • Page 26: Setting The Display

    Setting the Display Wireless Headphone The disc usage conditions described in “Displaying the Disc Status” (pages 16) are displayed on the wallpaper, or the upper part of the image during playback. (Except DVD video). Headphone Receivers Setting item: AUTO DISPLAY Setting contents: OFF / ON (Initial setting) OFF: Usage status is not displayed.

  • Page 27: Installation And Connections

    Using such parts could disable do so may result in damage to the unit and/or the vehicle. When in control of the vehicle and cause fi re, etc. doubt, consult your ALPINE dealer. KEEP SMALL OBJECTS SUCH AS BATTERIES OUT •...

  • Page 28: Connections

    TV Tuner with audio output connectors. POWER +12V • Power Control Connect this lead to any ALPINE video source product's ACC line, which is red. It controls turning the power ON/OFF for the ALPINE video products correspond to unit power.

  • Page 29: Mount Side

    Mount Side AV Connector 2 Power Connector FM Switching Box Connector The direction of AV The detail of dome light polarity switch Dome Light Polarity AV Connector 1 connector ports Dome Light Wire Dome light wire connects the built-in Dome Light to the cable from the vehicle’s Dome Light Switch.

  • Page 30: System Connections

    System Connections ALPINE TV tuner ALPINE Multi Media Station PKG-2100P DVD Built-In Overhead Monitor When the game port and AUX2 are connected at the same time, the game port has a priority.

  • Page 31: Information

    Information List of Language Codes (For details, see page 21.) Abbreviation Code Language Abbreviation Code Language Abbreviation Code Language 6565 Afar 7369 Interlingue 8278 Kirundi 6566 Abkhazian 7375 Inupiak 8279 Romanian 6570 Afrikaans 7378 Indonesian 8285 Russian 6577 Amharic 7383 Icelandic 8287 Kinyarwanda...

  • Page 32: List Of Country Codes

    List of Country Codes (For details, see page 22.) Abbreviation Code Country Abbreviation Code Country Abbreviation Code Country 6568 Andorra 6877 Dominica 7573 Kiribati 6569 United Arab Emirates 6879 Dominican Republic 7577 Comoros 6570 Afghanistan 6890 Algeria 7578 Saint Kitts and Nevis 6571 Antigua and Barbuda 6967...
  • Page 33 Abbreviation Code Country Abbreviation Code Country Abbreviation Code Country 8065 Panama 8374 Svalbard and Jan 8487 Taiwan, Province of 8069 Peru Mayen China 8070 French Polynesia 8375 Slovakia 8490 Tanzania, United Republic of Ukraine 8071 Papua New Guinea 8376 Sierra Leone 8565 8072 Philippines...

  • Page 34: In Case Of Diffi Culty

    Otherwise, make sure the rest of your • Monitor's parking brake is not set. system is properly connected or consult your authorized Alpine - Connect the monitor's parking brake cord and set the parking dealer.

  • Page 35: System Indication

    If the disc does not eject, press and hold for at least 3 seconds and eject the disc. If the disc still does not eject, consult your Alpine dealer. Mechanism error. • 2) When the error indication remains after ejecting, press 1) Press and eject the disc.

  • Page 36: Accessories

    Installation of Bracket and Trim Ring *1 Installation Bracket is used to stabilize the monitor at the time ceiling shape at the time of installing the monitor. Ask ALPINE of installing the monitor. Ask ALPINE dealer for detail. dealer for detail.
