ASSEMBLY

• A ssembly requires two persons.
• P lace all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you finish all assembly steps.
• A fter shipping, there may be an oily substance
on the exterior of the treadmill or on the shipping
carton. This is normal. If there is an oily sub-
stance on the treadmill, wipe it off with a soft cloth
and a mild, non-abrasive cleaner.
• T o identify small parts, see page 6.
1. Make sure that the power cord is unplugged.
Remove the 3/8" Nut (10), the 3/8" x 2" Bolt (8),
and the shipping bracket (A) from the Base (95).
Remove the shipping bracket from the other
side of the treadmill as described above.
Discard the shipping brackets. Save the Nuts
and the Bolts for steps 3 and 6.
• A ssembly requires the following tools:
the included hex keys
one adjustable wrench
one Phillips screwdriver
scissors
needlenose pliers
To avoid damaging parts, do not use power tools.
1
10
7
A
95
8
