Genie GCL-T Product Manual

GCL-T
STANDARD-DUTY TROLLEY OPERATOR
The GCL-T is designed for standard lift sectional
doors that have a 30-cycle/hour or less duty
requirement. Advanced features and robust
mechanical design combine to provide a standard-
duty operator that sets a new standard for
productivity.
UL325-2010 APPROVED
• Allows for monitored entrapment protection and
momentary operation when used with select photo eyes
and/or edge-sensing devices.
• See back for approved list of monitored devices.
GCL-T Advantages
• MultiVolt - Order phase specific operator for the job and
™
have the ability to select the right voltage on the job site.
- Single Phase: 115/208/230 VAC
- Three Phase: 208/230/460 VAC
- 575VAC voltage models available separately
• Modular design with optional expansion boards for
advanced timer to close, and auxiliary output functionality.
• LCD display with intuitive setup menu. Provides real-time
status and trouble-shooting assistance.
• Internal receiver with ability to individually add/delete up to
50 Intellicode I transmitters directly from LCD display..
®
• EZ Limit provides for push to set limits that remain
™
synchronized with door even during long term loss
of power.
• TensiBelt primary drive reduction eliminates need to
™
adjust belt tension.
• Open/close/stop and setup keys included on control board.
Keeps all controls near the LCD display convenient for set up.
www.GenieCompany.com/commercial
GCL-T operators are covered by the following U.S. patents: 6737823, 7878931, 8014966, 8113263
GENIE CommErCIAL opErATors
®
Standard Features
• 11.5 inches per second door speed.
• EZ Limit electro-mechanical limits.
™
• MultiVolt voltage simplification.
™
• Max run timer automatically adjusts to up and down run time.
• TensiBelt primary reduction.
™
• Delay on reverse.
• 16-character LCD display.
• UL325-2010 approved.
• Advanced radio receiver displays and stores activation by transmitter
ID number on the LCD screen.
• 3-button control station.
• 2-year/20,000-cycle warranty.
• Programmable mid-stop.
• Drawbar disconnect for emergency manual operation.
| 800.843.4084
