Summary of Contents for Genie 1022
- Page 2 If you have questions or do NOT understand the information presented, contact The Genie Company or an authorized Genie®Dealer. The safety alert symbol and following signal words DANGER, WARNING, and CAUTION are used throughout this manual to call attention to and identify different levels of hazard and special instructions.
- Page 3 INTELLICODE ® Rolling Code Security System. An electronic rolling code system that enhances the security of the door opener by continuously changing the access code each time the remote control is used. The door opener responds to each new code only once. An access code copied from a working system and tried again will not control the door opener.
- Page 4 Check your ceiling where the power You need a properly grounded 110-120 Volt head of your new unit will be mounted. power supply available. The outlet should Plan how you will be mounting the power head. no more than 3 feet from the power head once it is It is possible that ceiling joists may not be in the mounted.
- Page 5 Pg. 13 Pg. 12-13 TYPICAL SUPPORT ADDED BRACKET HEADER BRACKET (NOT PROVIDED) MOUNTING BOARD BRACES POWER CORD (APPROX. 45 IN.) TO 120V GROUNDED OUTLET EXTENSION SPRING TORSION SPRING NOTE: This opener is designed use with SECTIONAL doors only. Pg. 17-18 Pg.
- Page 6 Pencil 3/16" Drill Bit Carpenter's level Drill Wire strippers Adjustablewrench Ratchet Tapemeasure Safety Glasses Hammer Step ladder 1/4", 7/16", 3/8" and Phillipsscrewdriver 1/2" Sockets ARRA.GI.G_×CO.TE.TSrORASSe,,B_ Child pinned under automatic 9arage door Dea*hor _eriou_ injury can re_ul_ ° Neverle_ ch Id walkor ,un undermovingdoor¸ °Newt le_ ch Id us_ doo,opener contTol_ °AIway_ke_pmovingdoor_n_ght °.
- Page 7 RAIL SECIlON CLAMP RAIL CLAMP BOLT - 5/16"-18 x 5/8" HEX FLANGE NU1- 5/16"-18 BOLl - 5/16"-18 x 1/2" Rail Clamp Bolt - 5/16"-18 x 5/8" CLEVIS PiN, LONG ---5/16" x 3" COI1ER HEADER BRACKE 1 LAG SCREW - 5/16" x 2" HEX BOLt - 5/16".18 x 3/4"...
- Page 8 Power Cord Carriage Assembly Rail with chain Chain Connector Power H ea d CHAIN Tensioner Chain Clevis Pin, Long Header & Cotter Pin Bracket Power Cord Carriage Assembly Rail with chain Rail Clamps Chain Connector Power Head Rail Clamp Bolts CHAIN Release Knob...
- Page 9 IMPORTANT iNSTALLATiON iNSTRUCTiONS 1. READ AND FOLLOW ALL SAFETY, INSTALLATION Do NOT connect the opener to source of power until instructed to do so. AND OPERATION INSTRUCTIONS. f v:_ d n_i nd_)nd_n Locate the control button: ,:: ,::.., >' ..
- Page 10 Rail Assembly for CHAIN DRIVE OPENER CHAIN DRIVE RAILS 3. Remove the two rail sections that are not connected to the chain and place them on floor (Fig. 1-2, A). 4. Carefully remove the third rail section with chain and plastic sleeve.
- Page 11 NOTE: Standing at the powerhead, facing the door, the bullet MUST be on the RIGHT side of the rail. 1. Attach rail assembly to power head by aligning Chain Pulley Bracket the sprocket onto the motor shaft. Use (3) (at wall end of rail) 2-'Ose 1, "soc,et bolts, 5/16"-18 ×...
- Page 12 b) - extend vertical line 1. Finding header bracket mounting location. • Close garage door. -Use a pencil and level. a) Mark center of garage door (one-half overall width) on the wall with 6" vertical line at top edge of door. b) Continue this line on wall above door for about 12"...
- Page 13 1. Getting started. , Position assembled rail on wall next to header bracket (Fig. 2-4). -Place material on floor under power head to protect from scratching. (A box, stool, or similar device may be needed to clear a torsion spring.) Sos<...
- Page 14 oc,s, e S_?{;I fro_, £!;os' 2 Finding door bracket mounting location. . Door bracket is mounted as high on door as possible along vertical centerline and NO LOWER THAN top set of rollers (Fig. 2-7). Mounting the door bracket. • Proper bracing should be verified at this point. - Align door bracket centered on your vertical centerline (Fig.
- Page 15 Wire from _oOW e r head wan console. Wall console "Ent_ment'[ warning laDel Separate entry door This is an example of wire routing NOTE: For 14,9}If Console, _,Nre and ,_}suia_d when NOT pre-wired. Your wire staples tecate _9-s 6 and 7 Dom Box 2, EXAMPLE ONLY! ------------ routing may be different.
- Page 16 3.Securely fasten wires. • Securely fasten wires to ceiling and wall using insulated staples provided. -Use insulated staples. - Staples should be snug only. Insulated • If rear cover is attached to power head, Staple remove it, • On power head: - Route wall console wires through wire guide on power head.
- Page 17 -If not: a) Mounting bracket extensions are available through an authorized Genie _ Dealer. b) Blocks of wood, etc. may be substituted for extensions. • Center bracket on your mark (Fig. 4-2).
- Page 18 Wiring (pre-wired). Route wire from wall to Safe-T-Beam _ sensors ® (Fig. 4-5b). Splice pre-wiring to shortened sensor wire, match wire pairs dash-to-dash plain-to-plain. - Trim sensor wire to approximately one foot (1 ft) from sensor. - Split and strip ends of sensor wires and 21]or165 pre-wired wires (Fig.
- Page 19 Motor Cover Screws ii!ii!}iiiiii! ¸}iiiii!i!iiiii!iiiiiii ili!i! iii!il ¸ ii i i i! il ¸i • Do NOT use an extension cord. • Do NOT use a portable generator. This product is designed to operate using standard household current. Plug the opener into a properly grounded •...
- Page 20 Open Indicator Light Open Bet Limit Up Force OPEN ..Travel Limit Button Control The OPEN (UP) and CLOSE (DOWN) door positions are controlled by making the adjustments on the ..I II panel located on the bottom of the power head. The (1'_x [ _L_/_)_ustment ',\ "-_'...
- Page 21 The Carriage Lock can be manually engaged or disengaged. • To disengage Carriage Lock -Pull handle towards opener power head. • To engage Carriage Lock - Pull handle towards door. Obtain standard emergency release kit and remove S-hook from the cable end that attaches to the opener carriage.
- Page 22 By turning the Close Force Control _; clockwise, the CLOSE force can be increased. By turning the Close Force Control _; counter-clockwise, the CLOSE force can be decreased. Set the CLOSE force level at the minimum force required to close door without reversing. Once the desiredlevel is selected,this storesthe maximum force levelfor the CLOSE direction in memory.
- Page 23 This device complies with FCC Part 15 and RSS 210 of Industry Canada. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Single Button Remote Programming.
- Page 24 ,_ii_i_ii :¸_:i::_:_ii_iiiii_iiiii_i_ii_i_iii_i_i_ii_iii_i!ii_iiiii!ii_i!_iii_iii_ii!_!i_iii_iiiii_!i_i!i_ii_!i_!_!!_!_!_!_i 1. Battery replacement, • To open gently push straight out on battery cover lock tab as shown (Fig. 8-1). • Flip open battery cover. -Remove old battery. ° Make sure new battery is facing proper direction (Match battery polarity with symbols inside battery cover) (Fig.
- Page 25 SAVE T ESE I STRUCTI If you have any questions, please do not hesitate to contact Genie ®customer service at: 1.800.354.3643 2. Contact reverse. • Place a 2"x 4" board laid flat on floor.
- Page 26 Opener circuit wiring diagram. This wiring diagram is for reference only. Diagrama del circuito del abrelatas. Este diagrama es solo para referencia. Schema de cSblage de I'ouvreur. Ce schema de cSblage est indique a titre de rderence uniquement. POWER CORD CORDON DE SECTEUR CABLE...
- Page 27 The opener can be malfunction. forced to close as follows (See section !fl). Hold the wall console down until door is completely closed, • Disconnect the Safe-T-Beam ;°System from the opener and contact an authorized Genie®Dealer or The Genie Company at 1-800-35-GENIE.
- Page 28 • Check wall console and wiring. (Repeat) Staples can cut insulation and shorts wires. Repair or replace wall console andlor wiring. - Contact The Genie Company at 1-800-35-GENIE • Wall console wires reversed • Reverse wire placement in power in power head connector.
- Page 29 TRANSMITTER COMPLIANCE STATEMENT Transmitters comply with all United States and Canadian legal requirements as of the date of manufacture. No warranty is made that they comply with all legal requirements of any other jurisdiction. If transmitters are to be used in another country, the importer must determine compliance with any local laws and regulations...
- Page 30 LIMITED WARRANTY GMI Holdings, Inc d&ia The Genie Company ("Seller") warrants to the original purchaser of the below identified opener Model 1022 or opener Model 1024 or opener Model 1042 ("Product"), subject to all of the terms and conditions hereof, that the Product and all components thereof will be free from detects in...
