Genie IntelliG Setting Limits & Remote Programming

Setting Limits & Remote Programming
for IntelliG
For detailed instructions refer to owner's manual. 800-35-GENIE.
WARNING: DO NOT use wall console until limits have been set.
WARNING: Bullet MUST be engaged to carriage BEFORE set ting limits.
Setting Down Limits:
2
Press and hold the down arrow button (-) for
2 seconds until the long LED comes on blue
(round LED remains off).
PROGRAM
SET
HOLD
HOLD
2 seconds
2 seconds
3
Release down arrow button (-) and the long LED
will begin flashing.
PROGRAM
SET
4
Press and hold the down arrow button (-) until
garage door is fully closed on floor, then release.
PROGRAM
SET
PROGRAM
SET
5
Press and release the Program Set button (both
LEDs flash blue and go off).
PROGRAM
SET
The down limit is now set.
Quick Reference Card
, TriloG
®
PROGRAM
+
SET
+
+
HOLD
+
PROGRAM
+
SET
Programming
& GPower
Setting Up Limits:
6
Press and hold the up arrow button (+) for
2 seconds until the long LED light comes on blue
(round LED remains off).
PROGRAM
SET
7
Release up arrow button (+) and the round LED
will begin flashing.
PROGRAM
8
Press and hold the up arrow button (+) until door
is fully open, then release. Watch carriage as
it approaches the power head to avoid contact
with powerhead.
PROGRAM
PROGRAM
9
Press and release the Program Set button (both
LEDs flash blue and go off).
PROGRAM
SET
The up limit is now set.
*If both LEDs turn RED at this time,
return to Step 1, Setting Down Limits.
Models
+
HOLD
HOLD
2 seconds
2 seconds
+
SET
+
SET
HOLD
+
SET
PROGRAM
+
P999-159 1M 1/13 JAR
PROGRAM
SET
SET
