Supported maximum configurations

Caster base 22G0544

Caster base 22G0544 for MFPs

Supported MFPs: X646e, X644e, and X642e
Printer Duplex Optional 250-sheet drawers
configur unit
1
ation
A
B
C
D
E
F
G
H
I
J
•
If an optional duplex unit is installed, then:
–
The duplex unit must always be installed directly under the printer.
–
All paper-handling options must be installed below the duplex unit.
• The optional 2,000-sheet drawer must be at the bottom of the stack of drawers.
2 3 4
Optional 500-sheet drawers
1 2 3
Optional Optiona
10-inch l 2,000-
4
cabinet sheet
drawer
37
