Fan / Blower - Regency I1200 Owners & Installation Manual

Installer: Please record unit serial number here before installing blower.
Serial No.______________________________
Your fan should only be installed once the unit
is in place in order to prevent any damage to
the fan.
1) Align the fan support with the offset clip on
the bottom of the ashlip.
2) Slide the supports into the clips. The tension
holding the clips in place may be adjusted by
increasing or decreasing the offset spacing
of the clips.
3) Ensure that the power cord is not in contact
with any hot stove surfaces.
120V AC
60 Hz
Fan Thermodisc
(normally open)
I1200 Regency Wood Insert
Do not turn fan ON until your insert has
reached operating temperature or at least
30 minutes after starting fi re.
CAUTION: Label all wires prior
to disconnection when servic-
ing controls. Wiring errors can
cause improper and dangerous
operation.
Neutral
Green
Live
Ground

FAN / BLOWER

Manual/
Auto
Switch
Black
Black
Fan
Blower / Fan Wiring Diagram
INSTALLATION
WARNING:
Electrical Grounding Instructions
This appliance is equipped with a
three pronged (grounding) plug for
your protection against shock hazard
and should be plugged directly into
a properly grounded three-prong
receptacle. Do not cut or remove the
grounding prong from this plug.
Fan
Switch
Black
Fan
Ground
