Owners &
Installation
LISTINGS AND CODE APPROVALS
These gas appliances have been tested in
accordance with AS4553, NZS 5262 and
have been certified by the Australian Gas
Association for installation and operation as
described in these Installation and Operating
Instructions.
Your unit should be serviced annually by
an authorised service person.
IP28 GAS INBUILT
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE
WARNING:
Improper installation, adjustment, altera-
tion, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional in-
formation consult an authorised installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flam-
mable vapours and liquids in the vicinity of
this or any other appliance.
Installation and service must be performed
by an authorised installer, service agency or
the gas supplier.
918-938f
Models:
REFERENCE
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appli-
ance
Do not touch any electri-
cal switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the fire
department.
IP28-NG
IP28-PROPANE
IP28-ULPG
04/07/15

Advertisement

Table of Contents
loading

Summary of Contents for Regency IP28-PROPANE

  • Page 1 Owners & Installation IP28 GAS INBUILT Models: IP28-NG IP28-PROPANE IP28-ULPG PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, altera- What to do if you smell gas: tion, service or maintenance can cause Do not try to light any appli- injury or property damage.
  • Page 2 GAS INBUILT FIREPLACE TO THE NEW OWNER Congratulations! You are the owner of a state-of-the-art Gas Inbuilt Fireplace by FPI. The Regency Gas Fireplace Series of appliances has been designed to provide you with all the warmth and charm of a fireplace, at the flick of a switch. The model IP28 of this series has been approved by Australian Gas Association for both safety and efficiency.
  • Page 3 DIMENSIONS UNIT DIMENSIONS W/ CONTEMPORARY FACEPLATE 27.298 (694mm) 37.150 (944mm) MODULAR FACEPLATE AND INFILL PANEL 1-5/8" (41mm) 38-5/16" 3/8" (973mm) (10mm) 33-1/2" (848mm) Regency IP28 Gas Inbuilt Fireplace...
  • Page 4: Copy Of Data Badge

    DIMENSIONS UNIT DIMENSIONS W/ SLIM LINE FACEPLATE 27-5/16” (693mm) 40-1/2” (1030mm) Regency IP28 Gas Inbuilt Fireplace...
  • Page 5 DIMENSIONS DIMENSIONS - OPTIONAL MODULAR FIREPLACE SOLUTION 50-3/16” (1275mm) 18-5/16”(465mm) 49”(1245mm) DIMENSIONS - OPTIONAL WEATHER BOX 775mm 410mm 819mm Regency IP28 Gas Inbuilt Fireplace...
  • Page 6: Table Of Contents

    Contemporary faceplate Installation ......25 Contemporary Faceplate Assembly......42 Hearth trim Installation..........26 Slim line Faceplate Assembly ........42 Slim line faceplate Installation ........27 Optional infill panel Installation ........28 Modular faceplate Installation ........29 WARRANTY Final Check..............30 Wiring ................30 Standard wiring............30 Warranty ..............43 Regency IP28 Gas Inbuilt Fireplace...
  • Page 7: Data Badge

    This is a copy of the label that accompanies each Regency IP28 Gas Inbuilt fireplace. We have printed a copy of the contents here for your review. DATA BADGE NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one.
  • Page 8: Installation

    INSTALLATION IMPORTANT MESSAGE BEFORE YOU START The Regency Gas Inbuilt must be installed in ac- INSTALLATION AND REPAIR SHOULD cordance with these instructions. Carefully read all BE DONE ONLY BY AN AUTHORISED the instructions in this manual first. PERSON. Note: Failure to follow these instructions could...
  • Page 9: Masonary Minimum Fireplace Opening Dimensions

    The minimum fireplace dimensions for the Sides 2" / 51mm The minimum fireplace dimensions for the Regency gas space heater when using the Ceiling 39-3/8" / 1000mm Regency gas space heater when installing into Contemporary Fascia are shown in the follow- Mantel 11"...
  • Page 10: Optional Modular Fireplace Solution Clearances

    INSTALLATION OPTIONAL MODULAR FIREPLACE SOLUTION CLEARANCES 36” 51-7/16” (1305mm) (914mm) 51-7/16” (1305mm) 39-3/8” (1000mm) 1-7/16” (37mm) 25-7/8” 20-5/8” (655mm) (523mm) 33-7/16” (848mm) Regency IP28 Gas Inbuilt Fireplace...
  • Page 11: Mock Fireplace Kit (Zero Clearance) Installation

    Side standoffs x 2 1 on each side NOTE: Please adjust nailing fl anges in relationship to either Contemporary or Low Profi le Faceplate. Faceplate needs to be fl ush against fi nished wall. Regency IP28 Gas Inbuilt Fireplace 918-971 11/24/10...
  • Page 12: Gas Pipe Pressure Testing

    6) When finished reading manometer, turn off the gas valve, disconnect the hose and tighten the screw (clockwise) with a 1/8" flat screwdriver. Screw should be snug, but do not over tighten. Install to AS5601 (Australia) / NZS 5262 (New Zealand) Regency IP28 Gas Inbuilt Fireplace...
  • Page 13: Exterior Flue Termination Locations

    (IV) A flue terminal of this type shall not be located under a roofed area unless the roofed area is fully open on at least two sides and a free flow of air at the appliance is achieved. Regency IP28 Gas Inbuilt Fireplace...
  • Page 14: Venting And Termination

    Be sure not to damage the gasketing. Ensure both the inner and the outer are flush on the ‘’terminal side’’ and measurements are correct. Once the venting is properly secured to the unit at the correct measurements for the cavity, the unit is now ready for installation. Regency IP28 Gas Inbuilt Fireplace...
  • Page 15: Aeration Settings

    (Close the aeration for a more yellow flame, or open it to make the flame bluer). Please adjust and lock into place via screw. 7.94mm open 15mm open ULPG 15mm open Note: Any damage due to carboning resulting from improperly setting the aeration is NOT covered under warranty. Regency IP28 Gas Inbuilt Fireplace...
  • Page 16: Conversion Kit For Ng To Lpg Model

    When adjusting maximum pres- sure do not screw the nut in fully. If unable to obtain 2.49kPa outlet, check inlet pressure is adequate. Damage may occur to the gas valve if maximum pressure adjustment is fully screwed in. Regency IP28 Gas Inbuilt Fireplace...
  • Page 17: Conversion Kit For Ng To Ulpg Model

    If unable to obtain 2.49kPa outlet, check inlet pressure is adequate. Damage may occur to the gas valve if maximum pressure adjustment is fully screwed in. Regency IP28 Gas Inbuilt Fireplace 919-107 01/20/12...
  • Page 18 3) Ensure venting is secured to unit and slide unit carefully into the MFS. NOTE: SLIDE UNIT IN PARTIALLY TO ALLOW ACCESS TO CONNECT GAS AND ELECTRICAL. Once gas and electrical are connected, slide unit in completely. Regency IP28 Gas Inbuilt Fireplace 05/02/11...
  • Page 19 See installation manual for detailed instructions. Install decorative log kit as referenced in the installation manual. 6) Install the faceplate as referenced in the installation manual, under slimline faceplate. 7) Ensure the proper gas pressure. Regency IP28 Gas Inbuilt Fireplace 919-017 05/02/11...
  • Page 20 Side panels attached to back 9. Install unit. 2. Attach the top to the sides with 3 screws on each side. Install insulation - secure by bending tabs Attach top to sides Regency IP28 Gas Inbuilt Fireplace 10/09/12 919-192...
  • Page 21: Optional Stainless Steel Inner Panel Install

    Final installation of optional stainless panels. Orient the stainless side panels with the angled corner facing the back of the fi rebox. Angled corner in panel Regency IP28 Gas Inbuilt Fireplace 09/16/10 918-957...
  • Page 22: Switch Operation

    ON | OFF | REMOTE HIGH | LOW (FAN) HIGH | LOW (Mj) HIGH | LOW (FAN) ON | OFF | REMOTE HIGH | LOW (Mj) Switch operation - Slim line Faceplate Switch operation - Contemporary Faceplate Regency IP28 Gas Inbuilt Fireplace...
  • Page 23: Log Set Installation

    Place lava rocks on fi rebox base in front of logs - do not block Install left front log (0115). porting and spread out evenly. Install right front log (0115). Final install. Regency IP28 Gas Inbuilt Fireplace 01/13/11 918-963...
  • Page 24: Glass Door Installation

    4) With new glass installed in correct position, reinstall all glass retainers and screws. Ensure all screws are tightened to create a proper seal. Do not over tighten. NOTE: Unit will not operate with glass removed Regency IP28 Gas Inbuilt Fireplace...
  • Page 25: Contemporary Faceplate Installation

    Install four (4) screws in locations shown below to secure faceplate 5) Final install. 2) Hook up wire harness from faceplate to connection to under unit and check gas connections. 3) Reinstall bottom louver and install 2 screws in locations shown below. 11/24/10 918-972 Regency IP28 Gas Inbuilt Fireplace...
  • Page 26: Hearth Trim Installation

    Line up the hearth trim with the bottom of the fascia until it is flush with the fascia. From the backside of the fascia - secure the hearth trim with 3 screws on each side in locations shown below. Regency IP28 Gas Inbuilt Fireplace...
  • Page 27: Slim Line Faceplate Installation

    4 screws, see below. 4) Reinstall bottom louver and install 2 screws in locations shown below 5) Re install front frame. 2) Install four (4) screws in locations shown below to secure faceplate 6) Final install. Regency IP28 Gas Inbuilt Fireplace 12/16/10 918-973...
  • Page 28: Optional Infill Panel Installation

    Infi ll Panel 5. Please see Modular Faceplate instructions to complete installation. NOTE: Infi ll panel is required for mock fi replace applications and optional for masonry applications when installing Modular faceplate. Regency IP28 Gas Inbuilt Fireplace 918-973a 05/02/12...
  • Page 29: Modular Faceplate Installation

    4 screws, see below. 4) Reinstall bottom louver and install 2 screws in locations shown below 5) Re install front frame. 2) Install four (4) screws in locations shown below to secure faceplate 6) Final install. Regency IP28 Gas Inbuilt Fireplace 918-973a 05/02/12...
  • Page 30: Final Check

    CAUTION: Label all wires prior to disconnection not operate if polarity is incorrect. touch any hot surfaces and are away when servicing controls. Wiring errors can cause improper and dangerous operation. from sharp edges. STANDARD WIRING Regency IP28 Gas Inbuilt Fireplace...
  • Page 31: Operating Instructions

    This will burn off after a few minutes of operation. REMOTE CONTROL LIGHTING Use the Regency Remote Control Kit approved INSTRUCTIONS for this unit. Use of other systems may void your warranty. 1) Locate the 3 way switch located on the face-...
  • Page 32: Remote Receiver Installation

    Once you connect the black wire, the other 2 wires are identified by the male-female connec- tor. Place the receiver in the left hand side on the base of the heater. Ensure the receiver aerial is not touching metal components. Regency IP28 Gas Inbuilt Fireplace...
  • Page 33: Copy Of Lighting Instruction Plate

    NOTE: Wait 2 minutes between reset attempts. Appliances incorporating a live fuel effect (designed to oper- " ate with blue flames with slight yellow tips) may exhibit slight carbon deposition." Regency IP28 Gas Inbuilt Fireplace...
  • Page 34 Check the combustion fan & pressure switch are operating (there should be an audible click when the pressure switch makes contact). Providing the spill switch has continuity the electrode should spark and the gas valve open within 5 seconds of the completion of the purge cycle. Regency IP28 Gas Inbuilt Fireplace...
  • Page 35: Maintenance

    The heater is finished in a heat resistant paint and should only be refinished with heat resist- Your Regency stove is supplied with high tem- ant paint (not with wall paint). Regency uses perature, 5 mm Neoceram ceramic glass that WARNING: FAILURE TO INSTALL THIS StoveBright Paint - Metallic Black #6309.
  • Page 36: Convection Fan Replacement

    4) Remove 2 wing nuts + washers securing fan - locations shown below. 5) Unclip wires from base of unit and unplug fan. 6) Disconnect polarized plug. 7) Manoeuvre fan from base of unit and replace. Regency IP28 Gas Inbuilt Fireplace...
  • Page 37: Combustion Fan Replacement

    4) Remove convection fan - see previous page. 5) Remove 4 screws to release fan. 9) Reverse steps to reinstall. 6) Disconnect polarized plug. 7) Disconnect tubing from right side of fan. Tubing 8) Disconnect ground wire. Regency IP28 Gas Inbuilt Fireplace...
  • Page 38: Pressure Switch Replacement

    NOTE: It is important to label wires and hose connections to ensure the new switch is hooked up in the same manner. Remove the two screws on the mounting bracket. Remove 2 screws Slide switch out to the left side. Remove switch and replace. Reverse steps to complete installation. Regency IP28 Gas Inbuilt Fireplace...
  • Page 39: Valve Assembly Replacement

    3) Open the bottom louvre to access valve. 6) Disconnect wire harness plug. 4) Remove screw in location shown below to release valve cover. 7) Remove screw from rectifier, 5) Partially lift out valve cover. 8) Unplug rectifier from valve. Regency IP28 Gas Inbuilt Fireplace...
  • Page 40 MAINTENANCE 9) Disconnect ground wire from valve. 10) Disconnect connection from valve to burner. 11) Disconnect connection from valve to gas outlet. 12) Remove valve and replace. 13) Reverse steps to reinstall. Regency IP28 Gas Inbuilt Fireplace...
  • Page 41: Parts List

    Power Cord Assembly 240V IP28 456-001 Grate Assembly IP28 Manual 918-938 456-044/F Bracket side flange right / IP28 *Not available as a replacement part. 456-049/F Bracket side flange left / IP28 ** Part not shown. Regency IP28 Gas Inbuilt Fireplace...
  • Page 42: Contemporary Faceplate Assembly

    Door Bottom Access Slim F/P IP28 Frame Front Slim Faceplate IP28 Faceplate Front IP28 911-043 Wire Harness Control Switch IP28 911-060 Switch Rocker TC201-TB-B On/Off/On 911-061 Switch Rocker TB201-TB-B On/None/On *Not available as a replacement part. Regency IP28 Gas Inbuilt Fireplace...
  • Page 43: Warranty

    ® Regency shall in no event be liable for any special, indirect consequential damages of any nature whatsoever which are in excess of the original purchase price of the product. Any alteration to the unit which causes sooting or carboning that results in damage to the exterior facia is not the responsibility of Regency Fireplace Products.
  • Page 44 Register your Regency warranty online ® www.regency-fire.com.au Reasons to register your product online today! • View and modify a list of all your registered products. • Request automatic email notification of new product updates. • Stay informed about the current promotions, events, and special offers on related products.
