- Page 1 Product Manual Seagate 600 Pro SSD ® Standard 2.5” Standard 2.5” Managed Life models Usage Based models ST480FP0001 ST480FP0021 ST400FP0001 ST400FP0021 ST240FP0001 ST240FP0021 ST200FP0001 ST200FP0021 ST120FP0001 ST120FP0021 ST100FP0001 ST100FP0021 100727924 Rev. A May 2013...
- Page 2 Publication number: 100727924, Rev. A May 2013 Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Seagate 600 Pro SSD and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ - Page 4 IGURES Figure 1. Typical 5V Startup and Operation Current Profile ........13 Figure 2.
-
Page 5: Seagate Technology Support Services
• Authorized Service Centers Warranty terms will vary based on type of warranty chosen: “Managed Life” or “Usage Based”. Consult your Seagate sales representative for warranty terms and conditions. For information regarding data recovery services, visit http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM and Distribution partner portal, visit: http://www.seagate.com/partners/... -
Page 6: Introduction
NTRODUCTION ® This manual describes the functional, mechanical and interface specifications for the following Seagate 600 Pro SSD model drives: 2.5" M 2.5" U ANAGED ODEL SAGE ASED ODEL ST480FP0001 ST480FP0021 ST400FP0001 ST400FP0021 ST240FP0001 ST240FP0021 ST200FP0001 ST200FP0021 ST120FP0001 ST120FP0021 ST100FP0001... -
Page 7: Drive Specifications
If you are designing a system which will use one of the models listed or future generation products and need further assistance, please contact your Customer Technical Support Engineer or our global support services group as shown in See “Seagate® Technology Support Services” on page 1. -
Page 8: Formatted Capacity
Max time approximately 30 sec when standby immediate was not issued before power down. Warranty terms will vary based on type of warranty chosen: “Managed Life” or “Usage Based”. Consult your Seagate sales representative for warranty terms and conditions. ORMATTED CAPACITY... -
Page 9: Performance, Recording And Interface Technology
ERFORMANCE ECORDING AND INTERFACE TECHNOLOGY 2.4.1 Interface technology 480GB 400GB 240GB 200GB 120GB 100GB MODELS MODELS MODELS MODELS MODELS MODELS Interface Serial ATA (SATA-II) Interface Speeds 6Gb/s, 3Gb/s, 1.5Gb/s Supported Maximum Burst 600MB/s Transfer Rate Hot Plug Support Native Command Queuing Support Trim Support Lifetime Endurance... -
Page 10: Physical Characteristics
When evaluating performance of SSD devices, it is recommended to measure performance of the device in a method that resembles the targeted application using real world data and workloads. Test time should also be adequately large to ensure that sustainable metrics and measures are obtained. HYSICAL CHARACTERISTICS 2.5”... -
Page 11: Power Specifications
OWER SPECIFICATIONS The drive receives DC power (+5V) through a native SATA power connector. See Figure 2 on page 19. 2.8.1 Power consumption Power requirements for the drives are listed in the table on page 9. Typical power measurements are based on an average of drives tested, under nominal conditions, at 35°C ambient temperature. - Page 12 Table 3 400GB DC power requirements Parameter ST400FP00x1 (6.0Gb) Voltage Power Regulation +/- 5% (watts) Average Idle Current 0.45 2.27 Average Sleep Current 0.10 0.52 Maximum Start Current DC (Peak DC) 0.58 2.89 AC (Peak AC) 0.98 4.90 Delayed Motor Start (DC max) 0.10 0.49 Peak Operating Current (random read):...
- Page 13 Table 4 240GB DC power requirements Parameter ST240FP00x1 (6.0Gb) Voltage Power Regulation +/- 5% (watts) Average Idle Current 0.47 2.37 Average Sleep Current 0.10 0.49 Maximum Start Current DC (Peak DC) 0.56 2.78 AC (Peak AC) 0.90 4.50 Delayed Motor Start (DC max) 0.10 0.48 Peak Operating Current (random read):...
- Page 14 Table 5 200GB DC power requirements Parameter ST200FP00x1 (6.0Gb) Voltage Power Regulation +/- 5% (watts) Average Idle Current 0.45 2.25 Average Sleep Current 0.09 0.47 Maximum Start Current DC (Peak DC) 0.56 2.80 AC (Peak AC) 0.88 4.40 Delayed Motor Start (DC max) 0.10 0.48 Peak Operating Current (random read):...
- Page 15 Table 6 120GB DC power requirements Parameter ST120FP00x1 (6.0Gb) Voltage Power Regulation +/- 5% (watts) Average Idle Current 0.45 2.24 Average Sleep Current 0.09 0.46 Maximum Start Current DC (Peak DC) 0.53 2.66 AC (Peak AC) 0.96 4.78 Delayed Motor Start (DC max) 0.10 0.48 Peak Operating Current (random read):...
- Page 16 Table 7 100GB DC power requirements Parameter ST100FP00x1 (6.0Gb) Voltage Power Regulation +/- 5% (watts) Average Idle Current 0.42 2.10 Average Sleep Current 0.09 0.46 Maximum Start Current DC (Peak DC) 0.54 2.68 AC (Peak AC) 0.89 4.46 Delayed Motor Start (DC max) 0.10 0.48 Peak Operating Current (random read):...
-
Page 17: Figure 1. Typical 5V Startup And Operation Current Profile
2.8.2.1 Typical current profiles Figure 1. Typical 5V Startup and Operation Current Profile 600 P SSD P EAGATE RODUCT ANUAL... -
Page 18: Environmental Specifications
NVIRONMENTAL SPECIFICATIONS 2.9.1 Temperature Temperature is defined as the drive's internal temperature as reported by SMART attribute 194 for operation or the drive case temperature for non-operating. Above 1000 feet (305 meters), the maximum temperature is derated linearly to 112°F (44°C) at 10,000 feet (3048 meters). Operating: 0°... -
Page 19: Electromagnetic Immunity
2.9.6.1 Operating vibration The maximum random vibration levels that the drive may experience while meeting the performance standards specified in this document are specified below. This specification does not cover connection issues that may result from testing at this level. 20–2000 Hz 11.08 Grms 2.9.6.2... -
Page 20: Reliability
50% duty cycle) Warranty Warranty terms will vary based on type of warranty chosen: “Managed Life” or “Usage Based” Consult your Seagate sales representative for warranty terms and conditions. Preventive maintenance None required. Typical Data Retention with Power removed (at 40°C) -
Page 21: Agency Certification
As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate Technology LLC has tested this device in enclosures as described above to ensure that the total assembly (enclosure, drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. -
Page 22: Environmental Protection
The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. -
Page 23: Configuring And Mounting The Drive
For installations which require cables, you can connect the drive as illustrated in Figure 2. Signal connector Power connector Signal cable Power cable Figure 2. Attaching SATA cabling Each cable is keyed to ensure correct orientation. Seagate 600 Pro SSD drives support latching SATA connectors. 600 P SSD P EAGATE RODUCT ANUAL... -
Page 24: Drive Mounting
RIVE MOUNTING You can mount the drive in any orientation using four screws in the side-mounting holes or four screws in the bottom- mounting holes. Follow these important mounting precautions when mounting the drive: • Allow a minimum clearance of 0.030 in (0.76 mm) around the entire perimeter of the drive for cooling as a guideline. Please refer to Section 3.5 for final cooling requirements. -
Page 25: Cooling
OOLING Cabinet cooling must be designed by the customer so that the ambient temperature immediately surrounding the drive will not exceed temperature conditions specified in Section 2.9.1, "Temperature." The rack, cabinet, or drawer environment for the drive must provide heat removal. You should confirm that adequate heat removal is provided using the temperature measurement guidelines described in Section 2.9.1. -
Page 26: Serial Ata (Sata) Interface
For detailed information about the Serial ATA interface, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. LUG COMPATIBILITY Seagate 600 Pro SSD drives incorporate connectors which enable you to hot plug these drives in accordance with the Serial ATA II: Extension to Serial ATA 1.0a specification. This specification can be downloaded from www.serialata.org. ERIAL DEVICE PLUG CONNECTOR PIN DEFINITIONS Table 9 summarizes the 2.5”... - Page 27 Power 5V power to Drive LED Signal Activity LED: Driven low to light Keyway Optional Reserved for Seagate use. Leave unconnected. Optional Notes: Ground pins 3 and 4 mate first on micro SATA backplane connectors The two V pins are unused but connected together on the drive. They can be used for a drive-in-place detection.
-
Page 28: Supported Ata Commands
UPPORTED COMMANDS The following table lists Serial ATA standard commands that the drive supports. For a detailed description of the ATA commands, refer to the Serial ATA: High Speed Serialized AT Attachment specification. See “S.M.A.R.T. commands” on page 33 for details and subcommands used in the S.M.A.R.T. implementation. Table 11 Supported ATA commands OMMAND NAME OMMAND CODE... - Page 29 OMMAND NAME OMMAND CODE IN HEX Set Multiple Mode Sleep S.M.A.R.T. Disable Operations / D9 S.M.A.R.T. Enable Operations / D8 S.M.A.R.T. Execute Offline / D4 S.M.A.R.T. Read Data / D0 S.M.A.R.T. Read Log Sector / D5 S.M.A.R.T. Return Status / DA S.M.A.R.T.
-
Page 30: Identify Device Command
4.3.1 Identify Device command The Identify Device command (command code EC ) transfers information about the drive to the host following power up. The data is organized as a single 512-byte block of data, whose contents are shown in Table 11 on page 24. All reserved bits or words should be set to zero. - Page 31 ESCRIPTION ALUE Minimum PIO transfer cycle time without flow control (120ns) 0078 Minimum PIO transfer cycle time with IORDY flow control (120ns) 0078 Additional Features and Commands supported. 5D20 Trim Features supported, DMA commands supported Reserved 0000 71–74 Reserved for ATAPI 0000 Queue depth 001F...
- Page 32 ESCRIPTION ALUE Commands and feature sets supported or enabled 401C 121–126 Reserved for expanded supported and enabled settings 0000 Obsolete 0000 Security status 0021 129–159 Vendor specific xxxx 160–167 Reserved for the CompactFlash Association 0000 Device Nominal Form Factor 0003 DATA SET MANAGEMENT features supported 0001 170–173...
- Page 33 Word 69 Read zero after Trim is supported Optional ATA 28-bit commands supported Download Microcode DMA supported Set Max Password DMA and Set Max Unlock DMA supported Write Buffer DMA Supported Read Buffer DMA Supported DEVICE CONFIGURATION IDENTIFY DMA and DEVICE CONFIGURATION SET DMA are supported Long Physical Sector Alignment Error Reporting Control is supported Deterministic read after Trim is supported...
- Page 34 Word 83 DOWNLOAD MICROCODE command is supported Obsolete CFA feature set is supported APM feature set is supported Obsolete PUIS feature set is supported SET FEATURES subcommand is required to spin-up after power-up Reserved SET MAX security extension is supported AAM feature set is supported 48-bit Address feature set is supported DCO feature set is supported...
- Page 35 Word 87 SMART error logging is supported SMART self-test supported The Media Card Pass Through Command feature set is supported The GPL feature set is supported WRITE DMA FUA EXT and WRITE MULTIPLE FUA EXT commands are supported The 64-bit World wide name is supported The IDLE IMMEDIATE command with UNLOAD FEATURE is supported Shall be set to one Shall be cleared to zero...
-
Page 36: Set Features Command
4.3.2 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in the register does not represent a feature that the drive supports, the command is aborted. -
Page 37: Commands
SSD Percentage Endurance Remaining Indicator An application can interrogate the drive through the host to determine an estimate of the percentage of device life that is remaining. Seagate SeaTools diagnostic software has the capability to report the indicator value. 600 P... - Page 38 NDEX European Union (EU) requirements 17 ACA 17 acceleration 15 FCC verification 17 Access time 6 features 2 Agency certification 17 Federal Communications Commission 17 air flow Flush Cache 24 illustrated 21 Flush Cache Extended 24 altitude 14 Formatted capacity 4 ambient temperature 6 Annualized Failure Rate (AFR) 16 ATA commands 24...
- Page 39 Sanitize Freeze Lock Ext 24 Sanitize Status Ext 24 Operating shock 14 SATA 22 Operating vibration 15 screws 14 Seagate Technology Support Services 1 Sectors per track 4 Security Disable Password 24 Page-to-page access 6 Security Erase Prepare 24 page-to-page accesses 6...
- Page 40 NDEX width 6 Write Buffer 25 Write DMA 25 Write DMA Extended 25 Write DMA FUA Extended 25 Write FPDMA queued 25 Write Log Extended 25 Write Multiple 25 Write Multiple Extended 25 Write Multiple FUA Extended 25 Write Sectors 25 Write Sectors Extended 25 write uncorrectable 25 600 P...
