- Page 1 SATA Product Manual Standard models Standard Models ST8000VX002 ST8000VX008 ST6000VX011 ST6000VX010 ST4000VX005 ST4000VX013 ST3000VX017 ST3000VX016 ST2000VX012 ST2000VX015 100870481, Rev. A Gen 17 - July 2020...
- Page 2 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. SkyHawk and SeaTools are either trade- marks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ - Page 4 S.M.A.R.T. commands............. . 30 Seagate SkyHawk Product Manual, Rev. A...
- Page 5 Mounting dimensions (8TB & 6TB models)............20 Seagate SkyHawk Product Manual, Rev. A...
-
Page 6: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM and Distribution partner and Seagate reseller portal, visit: http://www.seagate.com/partners Seagate SkyHawk Product Manual, Rev. A... -
Page 7: Introduction
• Transient power on management - <=1.8A spin-up current • Uncompromising reliability supports flexible surveillance design with case temperatures up to 70ºC • Workload ratings of 180TB/year • Worldwide Name (WWN) capability uniquely identifies the drive Seagate SkyHawk Product Manual, Rev. A... -
Page 8: About The Sata Interface
SATA ports are represented to host software as a Device 0 (master) and Device 1 Note (slave) accessed at the same set of host bus addresses. A host adapter that emulates a master/slave environment manages two sets of shadow registers. This is not a typical SATA environment. Seagate SkyHawk Product Manual, Rev. A... -
Page 9: Drive Specifications
Power-on to ready (typ) 15.0s 10.0s 8.0s Standby to ready (typ) 15.0s 10.0s 8.0s Startup current (typical) 12V 1.8A 1.1A 5V ±5% Voltage tolerance (including noise) 12V ±10% Non-Operating (Ambient °C) –40° to 70° Seagate SkyHawk Product Manual, Rev. A... - Page 10 † Seagate does not recommend operating at sustained case temperatures above 60°C. Operating at higher temperatures will reduce useful life of the product. The operating case temperature is 0 to 70°C (32 to 158°F).
-
Page 11: Formatted Capacity
6TB & 3TB 8TB, 4TB & 2TB Interface SATA Recording method Recording density (kBPI) 2197 Track density (ktracks/inch avg) Areal density (Gb/in 1186 Interface transfer rate (MB/s) Data transfer rate (MB/s) up to 180 Seagate SkyHawk Product Manual, Rev. A... -
Page 12: Physical Characteristics
8 (typical) (in seconds) Ready to spindle stop 18 (typical) 12 (typical) 10 (typical) (in seconds) Time-to-ready may be longer than normal if the drive power is removed without going through normal OS powerdown procedures. Seagate SkyHawk Product Manual, Rev. A... -
Page 13: Power Specifications
• Using 5-volt power, the drive is expected to operate with a maximum of 100 mV peak-to-peak square-wave injected noise at up to 10MHz. Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current. Note Seagate SkyHawk Product Manual, Rev. A... -
Page 14: Voltage Tolerance
If the standby timer reaches zero before any drive activity is required, the drive makes a transition to Standby mode. In both Idle and Standby mode, the drive accepts all com- mands and returns to Active mode when disk access is necessary. Seagate SkyHawk Product Manual, Rev. A... -
Page 15: Environmental Specifications
† Operating (Drive case max °C) 70° (158°F) † Seagate does not recommend operating at sustained case temperatures above 60°C. Operating at higher temperatures will reduce useful life of the product. HDA Temp. Check Point Figure 1 Location of the HDA temperature check point Note Image is for reference only, may not represent actual drive. -
Page 16: Altitude
The maximum non-operating vibration levels that the drive may experience without incurring physical damage or degradation in performance when subsequently put into operation are specified below. 5Hz to 22Hz 3.0 Gs (Limited displacement) 22Hz to 350Hz 3.0 Gs 350Hz to 500Hz 3.0 Gs Seagate SkyHawk Product Manual, Rev. A... -
Page 17: Acoustics
Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 18: Warranty
The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. -
Page 19: Configuring And Mounting The Drive
For installations which require cables, users can connect the drive as illustrated in Figure 2 Figure 2 Attaching SATA cabling Each cable is keyed to ensure correct orientation. SkyHawk drives support latching SATA connectors. Seagate SkyHawk Product Manual, Rev. A... -
Page 20: Drive Mounting
3X 6-32 UNC-2B 3 MINIMUM THREAD DEPTH 0.14 MAXIMUM FASTENER PENETRATION BOTH SIDES Max: .795" or 20.20 mm Alterntive: .783" .012" or 19.90 0.30 mm 4X 6-32 UNC-2B 3 MINIMUM THREAD DEPTH 0.14 MAXIMUM FASTENER PENETRATION Seagate SkyHawk Product Manual, Rev. A... - Page 21 Figure 4 Mounting dimensions (8TB & 6TB models) 3X 6-32 UNC-2B 3 MINIMUM THREAD DEPTH 0.14 MAXIMUM FASTENER PENETRATION BOTH SIDES 4X 6-32 UNC-2B 3 MINIMUM THREAD DEPTH 0.14 MAXIMUM FASTENER PENETRATION Seagate SkyHawk Product Manual, Rev. A...
-
Page 22: Sata Interface
There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate back- plane configuration. • All used voltage pins (V ) must be terminated. Seagate SkyHawk Product Manual, Rev. A... -
Page 23: Supported Ata Commands
Read Sectors Extended Read Sectors Without Retries Read Verify Sectors Read Verify Sectors Extended Read Verify Sectors Without Retries Recalibrate Security Disable Password Security Erase Prepare Security Erase Unit Security Freeze Security Set Password Seagate SkyHawk Product Manual, Rev. A... -
Page 24: Standby
Write DMA Extended Write DMA FUA Extended Write DMA Without Retries Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Uncorrectable Seagate SkyHawk Product Manual, Rev. A... -
Page 25: Identify Device Command
Capabilities: (see 7.17.7.17) 15 Shall be cleared to zero 14 Shall be set to one 4000 13:2 Reserved 1 Obsolete 0 Shall be set to one to indicate a vendor specific Standby timer value minimum Seagate SkyHawk Product Manual, Rev. A... - Page 26 6 0 = Optional ATA device 28-bit commands supported 5 Trimmed LBA range(s) returning zeroed data is supported 4 Device Encrypts All User Data 3 Extended Number of User Addressable Sectors is supported 2 All write cache is non-volatile 1:0 Reserved Seagate SkyHawk Product Manual, Rev. A...
- Page 27 112-118 ATA-reserved 0000 Commands and feature sets supported 41DE Commands and feature sets supported or enabled 409C 121-127 ATA-reserved 0000 Security status 0021 129–159 Seagate-reserved xxxx 160–167 ATA-reserved 0000 Device Nominal Form Factor 0002 Seagate SkyHawk Product Manual, Rev. A...
- Page 28 Integrity word xxA5 Advanced Power Management (APM) and Automatic Acoustic Management (AAM) features are not supported. Note See the bit descriptions below for words 63, 84, and 88 of the Identify Drive data. Note Seagate SkyHawk Product Manual, Rev. A...
- Page 29 Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Seagate SkyHawk Product Manual, Rev. A...
-
Page 30: Set Features Command
Disable use of SATA features Enable read look-ahead (read cache) feature (default) Report full capacity available At power-on, or after a hardware or software reset, the Note default values of the features are as indicated above. Seagate SkyHawk Product Manual, Rev. A... -
Page 31: Commands
S.M.A.R.T. Enable Operations S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x04 (abort) is written to the Error register. Seagate SkyHawk Product Manual, Rev. A... - Page 32 Seagate Technology LLC AMERICAS Seagate Technology LLC 47488 Kato Road, Fremont, California 94538, United States, 510-661-1000 Publication Number: 100870481, Rev. A July 2020...
