Fireplace Installation

Unpacking Instructions
the fireplace insert is packed with
the front glass panel separated
and uninstalled from the fireplace.
Care must be taken to unpack the
fireplace so as not to damage the
front glass.
1. stand the packaged fireplace
upright as indicated on the
carton (Figure 1).
2. open the top of the carton
and locate which side the
glass is placed.
3. remove remote control and
all plastic bags containing
hardware etc.
4. Lay carton flat on a level sur-
face so that the glass panel
faces up (Figure 2).
5. supporting the glass panel,
remove one of the styrofoam
end caps.
6. Remove glass panel from
styrofoam packaging.
7. remove glass and fireplace
from all packaging and plastic
wrap.
8. Remove the temporary wood
frame from the firebox by
removing the six (6) screws
and washers as shown in
Figure 3.
Figure 1
Figure 2
Glass
Figure 3
End Cap
Wood Frame
7
