IMPORTANT SAFETY INFORMATION: Always read this manual first before attempting to service this
fireplace. For your safety, always comply with all warnings and safety instructions contained in this
manual to prevent personal injury or property damage.
Dimplex North America Limited
1367 Industrial Road Cambridge ON Canada N1R 7G8
1-888-346-7539 www.dimplex.com
In keeping with our policy of continuous product development, we reserve the right to make changes without notice.
© 2014 Dimplex North America Limited
Service Manual
Model Number:
DF2024
UL Part Number
6908891459
6908891559
REV
PCN
DATE
00
-
11-JUL-14
01
14284
16-SEP-14
7400810100R01
Advertisement
Table of Contents
Related Manuals for Dimplex DF2024
Summary of Contents for Dimplex DF2024
- Page 1 Dimplex North America Limited 11-JUL-14 1367 Industrial Road Cambridge ON Canada N1R 7G8 1-888-346-7539 www.dimplex.com 14284 16-SEP-14 In keeping with our policy of continuous product development, we reserve the right to make changes without notice. © 2014 Dimplex North America Limited 7400810100R01...
-
Page 2: Table Of Contents
NOTE: Procedures and techniques that are considered important enough to emphasize. CAUTION: Procedures and techniques which, if not carefully followed, will result in damage to the equipment. WARNING: Procedures and techniques which, if not carefully followed, will expose the user to the risk of fire, serious injury, or death. www.dimplex.com... -
Page 3: Operation
OPERATION Figure 2 Figure 1 again. On Screen D & E. Thermostat Controls Display Adjusts the temperature set point to your individual require- The unit can be controlled by either the manual controls ments. Once the desired set temperature is reached the which are located on the upper right of the fireplace or the heater will turn off. -
Page 4: Maintenance
Compact Fireplace Surface Cleaning Use warm water only to clean painted surfaces of the Com- pact Fireplace. Do not use abrasive cleaners. Servicing Except for the cleaning described above, an authorized ser- vice representative should perform any other servicing. www.dimplex.com... -
Page 5: Exploded Parts Diagram
EXPLODED PARTS DIAGRAM REPLACEMENT PARTS 1. Flicker Motor ....2000220100RP 11. Display/ Control Board ... . 3001350300RP 2. -
Page 6: Wiring Diagram
WIRING DIAGRAM Relay Board Switchboard Thermistor 2-LED LIGHT HARNESS, OR 3-LED LIGHT HARNESS Display Board www.dimplex.com... -
Page 7: Switchboard Replacement
SWITCHBOARD REPLACEMENT RELAY BOARD REPLACEMENT Tools Required: Phillips Head Screwdriver Tools Required: Phillips Head Screwdriver Flat Head Screwdriver Flat Head Screwdriver Needle Nose Pliers CAUTION: If unit was operating prior to servicing allow at least 10 minutes for lights, heating elements and top CAUTION: If unit was operating prior to servicing allow panel to cool off to avoid accidental burning of skin. -
Page 8: Ac/Dc Adapter Replacement
9. Reassemble in the reverse order as above. brackets to the mantel. 3. Remove the three screws along the back of the unit, www.dimplex.com... -
Page 9: Power Cord Replacement
POWER CORD REPLACEMENT WARNING: Disconnect power before attempting any maintenance to reduce the risk of electric shock or damage Tools Required: Phillips Head Screwdriver to persons. CAUTION: If unit was operating prior to servicing allow 1. Unplug the unit from power outlet. at least 10 minutes for lights, heating elements and top panel to cool off to avoid accidental burning of skin. -
Page 10: Led Light Assembly Replacement
This can be done by removing the two screws on the right hand side of the unit, reaching between the partially reflective panel and the back of the unit, to remove the display/ www.dimplex.com... -
Page 11: Glass Media Assembly And Partially Reflective Panel Replacement
GLASS MEDIA ASSEMBLY AND THERMISTOR REPLACEMENT PARTIALLY REFLECTIVE PANEL Tools Required: Phillips Head Screwdriver REPLACEMENT CAUTION: If unit was operating prior to servicing allow at least 10 minutes for lights, heating elements and top Tools Required: Phillips Head Screwdriver panel to cool off to avoid accidental burning of skin. CAUTION: If unit was operating prior to servicing allow WARNING: Disconnect power before attempting any at least 10 minutes for lights, heating elements and top... -
Page 12: Troubleshooting Guide
Log 3001390100RP Glass 3001390200RP Defective display/control board Replace the display/control board 3001350300RP Flame Shudder Defective Flicker Motor Replace Flicker Motor 2000220100RP Light leaking around the log Log set not positioned properly Check log set for proper fit set (if applicable) www.dimplex.com... - Page 13 PROBLEM CAUSE SOLUTION Heater Heater is not turning off Improper operation Refer to Operation Section Defective switchboard Replace switchboard 3001370100RP Defective thermistor Replace thermistor 3001380100RP Defective relay board Replace the relay board 3001360100RP Defective display/control board Replace the display/control board 3001350300RP Heater is not turning on, but Improper operation...
