Important Safety Instructions The lightning flash with an arrowhead symbol, CAUTION within the equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to cause an electric shock.
Page 3
Important Safety Instructions (For USA) 1. Read Instructions - All the safety and operating instructions should be read before the appliance is operated. 2. Retain Instructions - The safety and operating instructions should be retained for future reference. 3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to. 4.
Table of Contents Important Safety Instruction ..... 1-2 Repeat Playback ......... 25 Disc Formats ..........4 Repeating a title/chapter (DVD) ......25 Repeating a single track/whole disc (CD) ... 25 Before You Start ........... 5 Repeating a specific section (DVD) ...... 25 Using the remote control ..........
Disc Formats The Unit can playback. DVDs [12cm(5”) disc] Compatible Audio CDs [12cm(5”) disc] Region Management Information Region Management Information: This Unit is designed and manufactured to respond to the Region Management Information that is encoded on DVD discs. If the Region number printed on the DVD disc does not correspond to the Region number of this Unit, this Unit cannot play that disc.
Before You Start Using the Remote Control • Point the Remote Control at the REMOTE SENSOR located on the Unit. • When there is a strong ambient light source, the performance of the infrared REMOTE SENSOR may be degraded, causing unreliable operation. •...
Parts and Functions Front Panel 5 6 7 8 6) STOP button 1) 5 Disc tray Open or close tray by pushing button. Place discs Press to stop playing a disc. on the disc tray, label side up. PLAY button 2) Display window Press to start or resume playback.
Parts and Functions Remote Control 1) FUNCTION button Display the FUNCTION screen where you can check or STANDBY/ON FUNCTION change various settings. TUNING buttons : Fast reverse playback. PREV TUNING NEXT : Fast forward playback. TUNING : Scan all available radio stations. RETURN DISPLAY AUDIO...
Page 9
Parts and Functions Remote Control 18) STANDBY / ON button Turns the Unit on and puts it in standby mode. STANDBY/ON FUNCTION 19) NEXT button Move forward through titles, chapters or tracks on a disc. Tune to the presetted stations. PREV TUNING NEXT...
Display Front Panel Display REPEAT playback DOLBY PRO LOGIC II indicator indicator Displayed during repeat When Dolby Pro Logic of CD/DVD playback. sound is selected in AV_IN mode, light will illuminate. DOLBY DIGITAL indicator REPEAT A-B playback Displays while Dolby indicator Digital sound processing Displayed during repeat...
Setup For better reception Connect FM antenna (included) to the FM ANTENNA jacks. Connect the loop antenna (included) to the AM LOOP ANTENNA terminals. FM antenna AM(MW) loop To wall outlet antenna (supplied) A.Connecting a TV The Unit can be connected to your TV in several different ways, depending on the design of your TV. RCA Audio/Video Jacks Use the supplied Audio/Video cable.
Page 12
Setup Component video outputs (DVD) Some TVs or monitors are equipped with component video inputs. Using the Audio cable (not supplied), connect the left/right AUDIO OUT jacks on your Unit to the left/right AUDIO IN jacks on your TV and using a Component video cable (not supplied), connect the Green plug Y VIDEO OUT jack on your Unit to Y VIDEO IN jack on your TV, the Blue plug P VIDEO OUT jack on your Unit to P VIDEO IN jack on your...
Setup B. Connecting a VCR 1. Using the supplied Audio/Video cable, connect the yellow plug from VIDEO OUT jack on your Unit to VIDEO IN jack on your TV, connect the left/right AUDIO OUT jacks on your Unit to left/right AUDIO IN jacks on your TV. If you want the sound come from the speakers of the Main Unit, you need not to connect the left/right AUDIO OUT jacks from the Main Unit to your TV.
Setup C. Connecting another source Analog connection Using the Audio cable (not supplied), connect the left/right AUDIO OUT jack on your Unit to the AUDIO IN jack on the other analog equipment. Digital connection Using the Coaxial Digital Audio cable (not supplied), connect the DIGITAL AUDIO OUT on your Unit to the DIGITAL AUDIO IN jack on your another equipment.
Setup D. Connecting the speakers & subwoofer 1. The speaker cords have been REAR (LEFT) FRONT (LEFT) FRONT (RIGHT) REAR (RIGHT) color-coded simplify connection. Just plug the POSITIVE (+) and NEGATIVE (-) ends of each speaker wire into the corresponding jacks on the rear of the Unit, matching the color tube on the end of the speaker wire to the color-coded...
Setup Mounting rear surround speakers 1) Mark the correct mounting position on the wall. 2) Insert a fixing screw(s) at the marked position on the wall. 3) Align the slot hole(s) of the speaker over the screw and pull the speaker downward until it is firmly hooked. Need More Help? Please visit online help at http://www.18002526123.com Turning on the Unit and TV...
Adjusting the Sound To adjust the surround sound balance while Dolby Digital and Pro Logic II decoding is in effect Use the remote control to make the following changes to speaker balance: BASS control • Press the SOUND button repeatedly to display "BAS", then press the CURSOR button to adjust the sound level.
Page 18
Adjusting the Sound Pro Logic Emulation Mode The Pro Logic emulation mode offers users the same robust surround processing as original Pro Logic, in case the source content is not of optimum quality, or if there is a desire to hear the program more "as it used to be". When this mode is used, it is called Pro Logic, as before.
Playing a Disc Basic playback This owner’s manual explains the basic instructions of this DVD Unit. Some DVD discs are produced in a manner that allows specific or limited operation during playback. As such, the DVD Unit may not respond to all operating commands.
Playing a Disc Fast Forward/Fast Reverse 1. Press the TUNING TUNING button when a disc is playing. The speed of fast scan • The disc begins fast scan at x2 speed. • Four speeds are available. Each time TUNING TUNING button is pressed, the speed of fast scan changes in the following sequence: 2.
Playing a Disc Angle selection Some DVDs contain scenes which have been shot from a number of different angles. For these discs, the same scene can be viewed from each of these different angles. 1. While you are playing a DVD with different angles recorded, Number changes to show the number of the current press the ANGLE button to view the number of the current angle.
Special Functions Basic playback DISPLAY function Using DISPLAY, you can check and change the current settings of the following items: ANGLE, AUDIO and SUBTITLE. • While the disc is playing, press the DISPLAY button to display the screen shown below. Elapsed time: Elapsed time from the beginning of the chapter which is currently playing.
Special Functions Basic playback Locating a specific title If a DVD disc contains title numbers, you can locate a specific title by directly selecting a title number. 1. In stop mode, press the GOTO button. 2. Press button to highlight a specific field and press the corresponding number button(s) for the title you want.
Special Functions Basic playback Locating a specific time You can move to a specific location by entering its corresponding time (hours, minutes, seconds). 1. Press the GOTO button. 2. Press button to highlight time. 3. Press the corresponding number buttons for the setting point you want. •...
Advanced CD / DVD programmable memory playback Programmable memory The two types of programmed playback provided by this Unit are title programmed playback and chapter programmed playback. Title / Chapter programmed playback 1. Press the MEMORY button while the disc is stopped. 2.
Advanced Repeat Playback playback You can play a specific title or chapter repeatedly. (Title repeat, chapter repeat, A-B repeat) Repeating a title You can play the same title repeatedly. 1. While the disc is playing, press the REPEAT DISC button until the “ ”...
Playing MP3 and Digital Picture Files This Unit will play MP3 and Picture files recorded on CD-R / CD-RW discs Playing MP3 files 1. Press the OPEN/CLOSE button, the disc tray opens. 2. Insert a MP3 file disc on the disc tray with the label side up. 3.
Playing MP3 and Digital Picture Files Playing Digital Picture files 1. Press the button, the disc tray opens. 2. Insert a Picture CD on the disc tray with the label side up. 3. Press the button, the disc tray closes. 4.
Radio Operation Tuning into a station manually 1. Press FUNCTION button on the remote or on the front panel until the frequency band appears on the display. 2. Press the BAND button to select the desired band. 3. Press the TUNING button on the remote to tune in the desired station.
Customizing the Function Settings LANGUAGE setting 1. Press the FUNCTION button until DVD appears on the display. 2. Press the STOP button so that no disc is playing. 3. Press the SETUP button. 4. Use button to highlight your desired Language, then press the ENTER button.
Customizing the Function Settings Notes : • The displayable picture size is preset on the DVD disc. Therefore the playback picture of some DVD discs may not conform to the picture size you select. • When you play DVD discs recorded in the 4:3 picture size only, the playback picture always appears in the 4:3 picture size regardless of the TV shape setting.
Customizing the Function Settings Edges 1. Press the SETUP button. 2. Use button to select Video, then press the ENTER button. 3. Use button to select Edges, and then press the ENTER button. 4. Use button to shift and select the Sharpen / Soften / Off, then press the ENTER button. 5.
Customizing the Function Settings L/R Speaker 1. Press the SETUP button. 2. Use button to select the Audio, press the ENTER button. 3. Use button to L/R Speaker, and then press the ENTER button. 4. Use button to select the desired setting, and then press the ENTER button. 5.
Customizing the Function Settings Subwoofer 1. Press the SETUP button. 2. Use button to select the Audio, press the ENTER button. 3. Use button to Subwoofer, and then press the ENTER button. 4. Use button to select the desired setting, and then press the ENTER button. 5.
Customizing the Function Settings Center Delay 1. Press the SETUP button. 2. Use button to select the Audio, press the ENTER button. 3. Use button to Center delay, then repeatedly press the ENTER button to select the desired Center Delay type.
Customizing the Function Settings RATING setting Password/Parental lock DVD discs equipped with the password function are rated according to their content. This function may vary from DVD to DVD. It's ability to block content is dependent on the rating assigned by the movie manufacturer. For example, if the disc allowed, you could edit out violent scenes unsuitable for children and replace them with more suitable scenes, or you could lock out playback of the disc altogether.
Customizing the Function Settings Factory Set If you want to reset all the settings to the factory default, do the following: 1. Press the SETUP button. 2. Use button to select the Rating, then press the ENTER button. 3. Use button to shift and select the Factory Set, then press the ENTER button.
Language Code List for Disc Language Code Language Name Code Language Name Code Language Name Code Language Name Afar Frisian Malagasy Slovenian Abkhazian Irish Maori Samoan Afrikaans Scots Gaelic Macedonian Shona Ameharic Galician Malayalam Somali Arabic Guarani Mongolian Albanian Assamese Gujarati Moldavian Serbian...
Maintenance Cleaning Disc A defective or soiled disc inserted into the Unit can cause sound to drop out during playback. Handle the disc by holding its inner and outer edges. • Do NOT touch the surface of the unlabeled side of the disc. •...
Page 40
Trouble Shooting Guide SYMPTOM CAUSE (AND REMEDY) • The location and orientation of the antenna are incorrect. If you use an indoor antenna, change to an outdoor antenna. • The TV antenna wire is too close to the Unit. Separate the antenna wire of the TV set from the Unit.
