- Page 1 SIZE : 148 X 210mm DVD HOME THEATER SYSTEM CD PLAYBACK CD-R CD-RW AV I N P U T OWNER'S MANUAL...
-
Page 2: Important Safety Instruction
IMPORTANT SAFETY INSTRUCTIONS WARNING CAUTION WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. - Page 3 Important Safety Instructions 1. Read Instructions - All the safety and operating instructions should be read before the appliance is operated. 2. Retain Instructions - The safety and operating instructions should be retained for future reference. 3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to. 4.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Important Safety Instruction ...1-2 Disc Formats ... 4 Before You Start ... 5 Using the remote control ... 5 Parts and Functions ... 6-8 Remote Control ... 6-7 Front Panel ... 8 Display ... 9 Front Panel Display ... 9 Display Information ... -
Page 5: Disc Formats
The Unit can playback discs bearing any of the following marks: DVDs [8cm(3")/12cm(5”) disc] Audio CDs [8cm(3")12cm(5”) disc] Region Management Information Region Management Information: This Unit is designed and manufactured to respond to the Region Management Information that is encoded on DVD discs. If the Region number printed on the DVD disc does not correspond to the Region number of this Unit, this Unit cannot play that disc. -
Page 6: Before You Start
Using the Remote Control • Point the Remote Control at the REMOTE SENSOR located on the Unit. • When there is a strong ambient light source, the performance of the infrared REMOTE SENSOR may be degraded, causing unreliable operation. • The recommended effective distance for remote operation is about 16 feet (5 meters). To install Batteries 1.Open the battery door. -
Page 7: Parts And Functions
PARTS AND FUNCTIONS Remote Control OPEN/ STANDBY/ON CLOSE RETURN FUNCTION GOTO P. SCAN/ MEMORY SOUND CVBS DIMMER PRO LOGIC II VOLUME SETUP MENU ENTER SLOW SLOW PLAY STOP PAUSE PREV TUNING NEXT ZOOM/ CLEAR DISPLAY AUDIO TV MODE ANGLE SUBTITLE FM MODE BAND DISC REPEAT... -
Page 8: Remote Control
PARTS AND FUNCTIONS Remote Control OPEN/ STANDBY/ON CLOSE RETURN FUNCTION GOTO P. SCAN/ SOUND MEMORY CVBS DIMMER PRO LOGIC II VOLUME SETUP MENU ENTER SLOW SLOW PLAY STOP PAUSE PREV TUNING NEXT ZOOM/ CLEAR DISPLAY AUDIO TV MODE ANGLE SUBTITLE FM MODE BAND DISC REPEAT... -
Page 9: Front Panel
PARTS AND FUNCTIONS Front and Top Panel 1) Disc tray Open or close tray by pushing OPEN/CLOSE button. Place a disc on the disc tray, label side up. 2) STANDBY indicator When the Unit is turned on by pressing the STANDBY/ON button. -
Page 10: Display
Front Panel Display MEMORY indicator Displayed during programmed playback. DOLBY DIGITAL indicator Displays while Dolby Digital sound processing is being performed or when the loaded disc contains Dolby Digital sound PRO LOGIC II indicator When PRO LOGIC sound is selected in AV-IN mode, the light will illuminate. -
Page 11: Setup
For better reception Connect FM antenna (included) to the FM ANTENNA jacks. AM(MW) Connect the loop antenna (included) to the AM(MW) LOOP ANTENNA terminals. A.Connecting your TV The unit can be connected to your TV in several different ways, depending on the design of your TV. - Page 12 Component video outputs (DVD) Some TVs or monitors are equipped with component video inputs. Using the Audio cable (not supplied), connect the left/right AUDIO OUT jacks on your Unit to the left/right AUDIO IN jacks on your TV and the Component video cable (not supplied), connect the Green plug Y VIDEO OUT jack on your Unit to Y VIDEO IN jack on your TV, the Blue plug P and the Red plug P VIDEO OUT jack on your Unit to P...
-
Page 13: Connecting A Vcr
C. Connecting a VCR 1. Using the supplied Audio/Video cable, connect the yellow plug from VIDEO OUT jack on your Unit to VIDEO IN jack on your TV, connect the left and right AUDIO OUT jacks on your Unit to AUDIO IN jacks on your TV. If you want the sound come from the speakers of the Main Unit, you need not to connect these left and right Audio cable from the Main Unit to your TV. -
Page 14: Connecting The Speakers & Subwoofer
SETUP D. Connecting the speakers & subwoofer The speaker cords have been color-coded to simplify connection. Just plug the POSITIVE (+) and NEGATIVE (-) ends of each speaker wire into the corresponding jacks on the rear of the Unit, matching the color tube on the end of the speaker wire to the color-coded connector. -
Page 15: Positioning The Speakers & Subwoofer
E. Positioning the speakers and subwoofer FRONT SPEAKERS Place on both sides of the TV, equal distances apart. SUBWOOFER Can be placed anywhere. 10-17_ssq2.pmd SETUP CENTER Place on the top of or below the TV. REAR SPEAKERS Place right beside or slightly behind your listening position, and a little higher than your ears. -
Page 16: Mounting Rear Surround Speakers
Mounting rear surround speakers 1) Mark the correct mounting position on the wall. 2) Insert a fixing screw(s) at the marked position on the wall. 3) Align the slot hole(s) of the speaker over the screw and pull the speaker downward until it is firmly hooked. DO NOT RETURN THIS TO THE STORE Please call Customer Service at 1-800-252-6123 or visit online help at http://www.18002526123.com... -
Page 17: Adjusting The Sound
ADJUSTING THE SOUND To adjust the surround sound balance while Dolby Digital and Pro Logic II decoding is in effect Use the remote control to make the following changes to speaker balance: Front speaker (left) • Press the SOUND button repeatedly to display the sound level. -
Page 18: Adjusting The Sound
ADJUSTING THE SOUND Pro Logic Emulation Mode The Pro Logic emulation mode offers users the same robust surround processing as original Pro Logic, in case the source content is not of optimum quality, or if there is a desire to hear the program more "as it used to be". When this mode is used, it is called Pro Logic, as before. -
Page 19: Playing A Disc
PLAYING A DISC Basic playback This owner’s manual explains the basic instructions of this DVD Unit. Some DVD discs are produced in a manner that allows specific or limited operation during playback. As such, the DVD Unit may not respond to all operating commands. This is not a defect in the DVD Unit. Refer to the instruction notes of discs. -
Page 20: Fast Foward/Fast Reverse
Fast Forward/Fast Reverse 1.Press the TUNING TUNING button when a disc is playing. • The disc begins fast scan at x2 speed. • Four speeds are available. Each time TUNING button is pressed, the speed of fast scan changes in the following sequence: 2.Press the PLAY Y button when you reach the desired point to resume playback at normal speed. -
Page 21: Angle Selection
Angle selection Some DVDs contain scenes which have been shot from a number of different angles. For these discs, the same scene can be viewed from each of these different angles. 1.While you are playing a DVD with different angles recorded, press the ANGLE button to view the number of the current angle. -
Page 22: Special Functions
SPECIAL FUNCTIONS Basic playback DISPLAY function Using DISPLAY, you can check and change the current settings of the following items: ANGLE, AUDIO and SUBTITLE. • While the disc is playing, press the DISPLAY button to display the screen shown below. Elapsed time: Elapsed time from the beginning of the chapter which is currently playing. -
Page 23: Locating A Specific Title
SPECIAL FUNCTIONS Basic playback Locating a specific title If a DVD disc contains title numbers, you can locate a specific title by directly selecting a title number. 1.In stop mode, press the GOTO button. 2.Press , button to highlight a specific field and press the corresponding number button(s) for the title you want. -
Page 24: Locating A Specific Time
SPECIAL FUNCTIONS Basic playback Locating a specific time You can move to a specific location by entering its corresponding time (hours, minutes, seconds) 1.Press the GOTO button. 2.Press button to highlight time. 3.Press the corresponding number buttons for the setting point you want. •... -
Page 25: Cd / Dvd Programmable Memory
Advanced CD / DVD PROGRAMMABLE MEMORY playback Programmable memory The two types of programmed playback provided by this Unit are title programmed playback and chapter programmed playback. Title / Chapter programmed playback 1. Press the MEMORY button while the disc is stopped. 2. -
Page 26: Repeat Playback
Advanced playback You can play a specific title or chapter repeatedly. (Title repeat, chapter repeat, A-B repeat) Repeating a title You can play the same title repeatedly. 1.While the disc is playing, press the REPEAT DISC button until the “ indicator displays on the screen. -
Page 27: Playing Mp3 And Picture Cd
PLAYING MP3 AND PICTURE FILE DISC This Unit will play MP3 and Picture files recorded on CD-R disc Playing a MP3 file disc 1. Press the OPEN /CLOSE button, the disc tray opens. 2. Insert a MP3 file disc on the disc tray with the label side up. 3. -
Page 28: Playing A Picture Cd
PLAYING MP3 AND PICTURE FILE DISC Playing a Picture file disc 1. Press the OPEN/CLOSE button, the disc tray opens. 2. Insert a Picture CD on the disc tray with the label side up. 3. Press the OPEN/CLOSE button, the disc tray closes. 4. -
Page 29: Radio Operation
RADIO OPERATION Tuning into a station manually 1.Press the FUNCTION button until the frequency band appears on the display. 2. Press the BAND button on the remote remote or STOP button on the front panel to select the desired band. 3.Press the TUNING button to tune in the desired station. -
Page 30: Customizing The Function Settings
CUSTOMIZING THE FUNCTION SETTINGS LANGUAGE setting 1. Press the FUNCTION button until DVD appears on the display. 2. Press the STOP button so that no disc is playing. 3. Press the SETUP button. 4. Use button to select the Language, then press the ENTER button. 5. -
Page 31: Video Output
CUSTOMIZING THE FUNCTION SETTINGS Cut off when a wide-screen video image is played. 4:3 Pan Scan • When wide-screen video material is played, this mode clips the right and left sides of the image so that it can be viewed on a conventional TV screen. •... -
Page 32: Brightness
CUSTOMIZING THE FUNCTION SETTINGS Brightness 1.Press the SETUP button. 2.Use button to select Video, then press the ENTER button. 3.Use button to select Brightness, and then press the ENTER button. 4.Use button to shift and select the Off/On, then press the ENTER button. 5.If you want to exit the SETUP MENU and return to the normal screen, press the RETURN button. -
Page 33: Audio Setting
CUSTOMIZING THE FUNCTION SETTINGS AUDIO setting Digital Out 1.Press the SETUP button. 2.Use button to select Audio, press the ENTER button. 3.Use button to select Digital Out, and then press the ENTER button repeatedly to select Digital Out type. 4.To exit the FUNCTION SETUP MENU and return to the normal screen, press the RETURN button. Raw : Does not have a Dolby Digital Decode. -
Page 34: Subwoofer
CUSTOMIZING THE FUNCTION SETTINGS Subwoofer 1.Press the SETUP button. 2.Use button to select the Audio, press the ENTER button. 3.Use button to Subwoofer, and then press the ENTER button. 4.Use button to select the desired setting, and then press the ENTER button. 5.To exit the FUNCTION SETUP MENU and return to the normal screen, press the RETURN button. -
Page 35: Center Delay
CUSTOMIZING THE FUNCTION SETTINGS Center Delay 1.Press the SETUP button. 2.Use button to select the Audio, press the ENTER button. 3.Use button to Center delay, then repeatedly press the ENTER button to select the desired Center Delay y type. 0ms, 1ms, 2ms, 3ms, 4ms or 5ms appears. 4.To exit the FUNCTION SETUP MENU and return to the normal screen, press the RETURN button. -
Page 36: Rating Setting
CUSTOMIZING THE FUNCTION SETTINGS RATING setting Password/Parental lock DVD discs equipped with the password function are rated according to their content. The contents allowed by a parental lock level and the way a DVD disc can be controlled may vary from disc to disc. For example, if the disc allowed, you could edit out violent scenes unsuitable for children and replace them with more suitable scenes, or you could lock out playback of the disc altogether. -
Page 37: Factory Set
CUSTOMIZING THE FUNCTION SETTINGS Factory Set If you want to return the initial language setting to the factory default, do the following: 1.Press the SETUP button. 2.Use button to select the Rating, then press the ENTER button. 3.Use button to shift and select the Factory Set, then press the ENTER button. 4.Use button to shift and select Yes, then press the ENTER button. -
Page 38: Language Code List For Disc Language
LANGUAGE CODE LIST FOR DISC LANGUAGE Code Language Name Code Afar Abkhazian Afrikaans Ameharic Arabic Assamese Aymara Azerbaijani Bashkir Byerlorussian Bulgarian Bihari Bislama Bengali Bangla Tibetan Breton Catalan Corsican Czech Welsh Danish German Bhutani Greek English Esperanto Spanish Estonian Basque Persian Finnish Fiji... -
Page 39: Maintenance
Cleaning Disc A defective or soiled disc inserted into the Unit can cause sound to drop out during playback. Handle the disc by holding its inner and outer edges. • Do NOT touch the surface of the unlabeled side of the disc. •... -
Page 40: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE SYMPTOM CAUSE (AND REMEDY) • The location and orientation of the antenna are incorrect. If you use an indoor antenna, change to an outdoor antenna. • The TV antenna wire is too close to the Unit. Separate the antenna wire of the TV set from the Unit.
