Installation
Installation, cont'd
Installation Overview
To install an SW AV Series switcher, do the following:
1
2
3
4
5
6
7
8
Mounting the Switcher
Tabletop use
For tabletop use, affix a self-adhesive rubber foot to each corner of the bottom of
the switcher.
Rack mounting the switcher
The SW AV switcher models are housed in rack-mountable, 1U high, 17" wide
metal enclosures. The appropriate rack mount kit is included with each switcher.
Rack mount the switcher as follows:
1.
2.
3.
4.
Furniture mounting the switcher
The SW AV switcher models can be mounted under a table or other horizontal
surface with an optional Extron MBD 129 Through-Desk Mount Kit, part #70-077-02.
1.
2.
2-2
SW AV Series Switchers • Installation
Turn off the input and output devices, and unplug their power cords.
If desired, mount the switcher in a rack or under furniture (see Mounting the
Switcher below).
Connect the input and output devices to the switcher (see Cabling and Rear
Panel Views on page 2-3).
(SW 8 and SW 12 models) If desired, connect a computer or an RS-232
control system to the RS-232 connector (see Remote connection on page 2-6).
(SW 4 and SW 6 models) If desired, connect a computer, an RS-232 control
system, an IR device (such as the IR 102 remote control kit), or a contact
closure device (such as a KP 6 Keypad Remote Control) to the Remote
connector (see Remote connection on page 2-6).
If desired, connect a black burst (genlock) signal to the external sync
connectors (see External sync connection on page 2-6).
Plug the switcher and, if appropriate, the input devices and output devices
into a grounded AC source.
Turn on the input and output devices.
The image from each input device should appear on the output devices when
you switch from one input device to another. If this does not happen, double
check steps 3 through 5 and make adjustments as needed.
If feet were previously installed on the bottom of the switcher, remove them.
Attach the rack mount brackets to the switcher with the eight #8 machine
screws provided (figure 2-1).
Insert the switcher into the rack, align the holes in the mounting bracket with
those of the rack.
Secure the switcher to the rack using the supplied machine screws.
Secure the optional table/wall mounting brackets to the switcher with the
eight machine screws provided in the mounting kit (figure 2-1).
Hold the switcher with attached brackets against the underside of the desk or
other furniture. Mark the location of holes for screws on the underside of the
desk.
