Page 1: Assembly Instructions
TREADMILL PRO-SERIES Model: T714 Assembly Instructions... -
Page 2: Required Assembly Tools
IMPORTANT Please read assembly instructions completely before beginning. • Due to the treadmill’s size and weight, the unit requires two people to move and assemble. Several steps of the assembly process will also require two people to perform. • Carefully unpack the machine and check to ensure all parts have been included in the box. •... -
Page 3: Assembly Procedure
Assembly Procedure Note For ease of assembly, install Console Assembly before folding Treadmill Uprights into position. Step 1 - Install Console • Plug the four connectors on the Console Assembly (#10) into the four connectors on the Treadmill Uprights (#11). •... - Page 4 Step 3 - Attach Side Frame Covers • Use 10 Phillips Head Screws (#1) to attach the left and right Side Frame Covers (#12). Step 4 - Attach Top Motor Cover • Use two Phillips Head Screws (#1) to secure the Top Motor Cover onto the Kick Plate. �...
- Page 5 Assembly of your Nautilus Pro Series Series Treadmill is complete! Please refer to your Pro Series Owners Manual for information on proper use of your treadmill. For more information visit our website Nautilus.com or call: 800-864-1270 (USA), 1-800-636-8316 (French Canadian), or +41-26-460-77-77 (International). P/N - 41252 Rev C...
