Craftsman 113.23611t Owner's Manual page 9

2. Use a small square to set the table at 90 ° to the blade.
If there istoo much space between the square and the
blade, the table must be adjusted.
/
3. When the space between the square and the blade is
minimal, tighten the bevel lock knob.
The table should now be approximately 90 ° to the
blade.
.
Loosen the screw holding the bevel scale pointer and
adjust to 0 °. Tighten screw.
Remember, the bevet scale is a convenient guide but
should not be relied upon for precision.
Make practice cuts in scrap wood to determine if your
angle settings are correct. Adjust the table as required.
NOTE: Avoid settingthe edge of thetable against top
of motor which could cause noise when the saw is
used.
f
BEVEL
POINTER
