Modifying graphs
1. Open the Performance Monitor window.
2. Select File > Display Canvas Configurations.
3. Select a canvas from the list and click Edit.
4. Select a graph from the list and click Edit.
5. Make changes in the Edit dialog box, as necessary.
6. Click OK to close the Edit dialog box.
7.
8. Click Close to close the Canvas Configuration List.
102
The Canvas Configuration List displays. A message "No Canvas configuration to display"
displays if there are no saved canvas configurations.
The Performance Monitor Canvas: Canvas Name dialog box displays.
NOTE
The Edit button is enabled only for the graphs that are configurable or editable.
Click Save to save the changes and close the Performance Monitor Canvas dialog box.
