Figure 36 Rear panel LEDs
1. LAN network speed LED indicator
2. LAN activity status LED indicator

Fibre Channel card LEDs

If you have the Fibre Channel version of the HP D2D, there are three LEDs adjacent to each FC port.
Table 3 FC card LEDs
Yellow LED
Off
On
Flashing
Alternately flashing
Off
Off
On
Flashing
Green LED Amber LED
Off Off
On On
Flashing Flashing
Alternately flashing Alternately flashing
On
Off
Flashing
On
Off
Flashing
Off Off
D2D Backup SystemHP D2D4004 and HP D2D4009
Steady green: The LAN connection is using 10
Mbps/100 Mbps link.
Steady amber: The LAN connection is using a GbE
link.
Off: No connection.
Flashing green: Ongoing network data activity.
Off: No network data activity or no connection.
Activity
Power Off (OK)
Power on before or after firmware
initialization. Awaiting HBA
firmware initialization.
Power on after firmware
initialization. Link not initialized.
Firmware fault (OK)
Connected at 1 Gb/s
Activity at 1 Gb/s (OK)
Connected at 2 Gb/s
Activity at 2 Gb/s (OK)
Connected at 4 Gb/s
Activity at 4 Gb/s (OK)
65
