Repeating Defects Appear On Prints; Shadow Images Appear On Prints - Lexmark MS510 Manual

Repeating defects appear on prints

Action
Step 1
Measure the distance between the defects.
Check for a distance between the defects that equals:
• 97 mm (3.82 in.)
•
47 mm (1.85 in.)
•
38 mm (1.5 in.)
Is the distance between defects equal to one of the listed measurements?
Step 2
Replace the imaging unit, and then resend the print job.
Do the repeating defects still appear?

Shadow images appear on prints

Leading edge
A B C D
A B C D
A B C D
A B C D
Trailing edge
Print Quality Guide
Page 10 of 19
Yes No
Go to step 2. 1
2
Contact customer The problem is solved.
support at
http://support.lexmark
.com or your service
representative.
Check if the distance
between the defects
equal to 80 mm (3.15
in.)
Take note of the
distance, and then
contact customer
support at
http://support.lex
mark.com or your
service
representative.
