This appendix provides information about the following:
For information about...

Switch Specifications

Mini-GBIC Input/Output Specifications
Gigabit Ethernet Specifications
Console Port Pinout Assignments
Regulatory Compliance
Enterasys Networks reserves the right to change the specifications at any time without
notice.
Switch Specifications
Table A‐1 provides the I/O ports, processors and memory, physical, and environmental
specifications for the A2H254‐16.
Table A-1 A2H254-16 Switch Specifications
Item
RJ45 odd numbered ports 1
through 15
MT-RJ even numbered ports 2
through 16
RJ45 ports 17 and 18
SFP ports 19 and 20
Specification
Eight 10/100BASE-T compliant ports with auto-sensing and
auto-negotiation through RJ45 UTP connectors.
Eight 100BASE-FX compliant ports
Two 10/100/1000BASE-TX compliant ports with auto-sensing
and auto-negotiation through RJ45 UTP connectors for stacking.
In standalone mode, these ports can be used for host
connections and interswitch links.
Two slots that support optional Mini-GBICs 1000BASE-FX
fiber-optic connections and 1000BASE-T copper connections.
Specifications
Refer to page...
SecureStack A2 Installation Guide
A
A-1
A-3
A-4
A-7
A-7
A-1
