SINK DESCRIPTION
• Manufactured of 16 gauge, type 304 nickel-bearing
stainless steel
• The two bowls, the larger bowl is 18" x 18" x 10"
and the smaller bowl is 13" x 18" x 10"
• Has two 3-1/2" diameter recessed drain opening
• SoundShield undercoating maximizes sound
deadening and inhibits condensation.
• The exposed surfaces are polished to a lustrous
satin tone finish
• Silicone sealant not provided. Includes mounting bracket.
Other standard mounting hardware not included
INSTALLATION
• Cut out template included with sink
• Template ordering number 22538
STANDARDS
• Third party certified by IAPMO to meet ASME A112.19.3
and all applicable specifications referenced therein
WARRANTY
• Warranted for fifteen years against material or
manufacturing defects
18"
20"
(457.2mm)
(508mm)
10"
(254mm)
2/06
34"
(863.6mm)
18"
(457mm)
(330mm)
CRITICAL DIMENSIONS
S p e c i f i c a t i o n s
Lancelot
WASHER
(Not Included)
9"
(229mm)
13"
(DO NOT SCALE)
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
®
Professional Undermount
Double Bowl Sink
Model: 22379
(UMTLSR-3218-10-10)
COUNTERTOP
Silicone Sealant
WINGNUT
(Not Included)
BRACKET
#10-32 SCREW
(Not Included)
Installation Detail
www.moen.com
