16 C 1: WX S
HAPTER
WX1200, WX4400,
and WX2200 Status
LEDs
O
WITCH VERVIEW
The WX1200, WX4400, and WX2200 switches have LEDs that indicate
port, power, and CPU status. Table 4 lists the LEDs. (For the location of
each LED, see Figure 3 and Figure 4.)
Table 4 WX1200, WX4400, and WX2200 Status LEDs
LED
Mgmt
(WX4400 and
WX2200 only)
Power supply
status
Gigabit fiber
link activity
(WX4400 and
WX2200 only)
Gigabit copper
link activity
(WX4400 and
WX2200 only)
Link
(WX1200 only)
Appearance
Bright green, then
fade (repeated)
This LED appearance
is sometimes called
breathing.
Blinking green
Quickly blinking
amber
Solid green
Solid amber
Unlit
Solid green
Blinking green
Solid green
Blinking green
Solid green
Solid amber
Blinking green
Blinking amber
Meaning
WX switch is operating normally.
WX switch is booting.
WX switch was unable to boot completely.
DC power output is on.
Power fault has occurred.
AC power is off.
1000-Mbps fiber link is operational.
Traffic is active on the 1000-Mbps fiber
link.
1000-Mbps copper link is operational.
Traffic is active on the 1000-Mbps copper
link.
100-Mbps link is operational.
10-Mbps link is operational.
Traffic is active on the 100-Mbps link.
Traffic is active on the 10-Mbps link.
